The Schneider Electric VW3A1112 Door Mounting Kit is a dedicated installation accessory designed for Altivar series variable speed drives, specifically for mounting graphic display terminals on enclosure doors. This kit enables operators to relocate the terminal interface to the cabinet front, improving accessibility, safety, and operational efficiency.
Engineered to maintain a high protection level, the VW3A1112 is suitable for installation on cabinet doors with IP65 / UL Type 12 protection requirements. It ensures that the graphic terminal remains fully protected against dust, moisture, and industrial contaminants even when mounted remotely.
The kit is supplied as a complete solution, including all mechanical, sealing, grounding, and communication components required for installation. By providing a reliable and standardized mounting method, the VW3A1112 simplifies system integration and supports pr/essional-grade panel design in industrial automation environments.
产品规格
| Parameter | 描述 |
|---|---|
| Product Type | Door Mounting Kit |
| Accessory 分类 | Installation accessory |
| Compatible Series | Altivar |
| 支持ed Device | Graphic display terminals |
| Mounting Location | Enclosure / cabinet door |
| Protection Level | IP65 / UL Type 12 |
| Installation Purpose | Remote mounting / graphic terminals |
| Included Components | Mounting plate, sealing elements, fixing hardware |
| RJ45 Interface | Dedicated connector for graphic terminal |
| RJ45 Cable Length | Up to 10 m |
| Grounding 支持 | Integrated grounding connector |
| Installation Tool | Supplied tightening tool |
| Environmental Suitability | Industrial control cabinets |
| Dimensions | 120 × 55 × 100 mm |
| 重量 | 0.068 kg |
Applications
• Remote mounting / graphic terminals, enabling front-door operation
• Altivar drive control cabinets, improving ergonomics and accessibility
• Industrial automation panels, requiring sealed operator interfaces
• Harsh industrial environments, where IP65 protection is mandatory
• Machine and process control systems, supporting safe operator interaction
• Commissioning and maintenance setups, reducing cabinet access frequency
Advantages
• Maintains IP65 / UL Type 12 protection, even when terminals are door-mounted
• Complete installation kit, eliminating the need for additional accessories
• Optimized for Altivar graphic terminals, ensuring mechanical compatibility
• Integrated sealing and grounding, enhancing safety and reliability
• Long RJ45 connection capability, supporting flexible cabinet layouts
• Pr/essional panel finish, improving overall system appearance
• Simplified installation process, reducing setup time and errors
