Product Overview
The Schneider TSXPSY2600M is an industrial-grade power supply module engineered to provide regulated and reliable power to the Modicon Premium range / PLCs. Operating with a wide AC input range / 100–240 VAC, this module outputs a steady 5 VDC at up to 6 A, making it suitable for high-demand automation applications requiring a stable power backbone.
Designed for rack-mounted installation within the Premium PLC chassis, the TSXPSY2600M integrates seamlessly into Schneider Electric’s modular automation ecosystem. With built-in protections against short-circuit, overload, and overvoltage conditions, it ensures long-term operational safety. The module features LED indicators for easy monitoring and a rugged construction suited to challenging industrial environments.
Key Features
-
Wide AC input voltage range: 100–240 VAC
-
Regulated 5 VDC output with up to 6 A current
-
Compatible with Schneider Modicon Premium PLCs
-
Full protection: short-circuit, overload, overvoltage
-
LED indicators for power and fault status
-
Rack-mountable design for easy system integration
-
支持s extended PLC configurations with high I/O counts
-
High efficiency and minimal heat generation
Technical Specifications
| Parameter | Specification |
|---|---|
| Input Voltage Range | 100–240 VAC ±10%, 50/60 Hz |
| Output Voltage | 5 VDC |
| Maximum Output Current | 6 A |
| Maximum Output Power | 30 W |
| Inrush Current | ≤ 30 A |
| Efficiency | ≥ 70% |
| Protection Functions | Short-circuit, overload, overvoltage |
| LED Status Indicators | Power ON (green), Fault (red) |
| Operating Temperature | 0°C to +60°C (32°F to 140°F) |
| Storage Temperature | -25°C to +85°C (-13°F to 185°F) |
| Humidity Tolerance | 5% to 95% RH, non-condensing |
| Dimensions (L × W × H) | Package size: 60 × 180 × 260 mm |
| 重量 | 0.51 kg |
| Mounting Type | Rack-mounted (Modicon Premium backplane) |
| Certification Standards | CE, UL, CSA, RoHS |
Product Advantages
-
High Output Capacity: Supplies up to 6 A / 5 VDC for expanded PLC configurations and large I/O loads.
-
Optimized for Modicon Premium: Purpose-built for seamless integration with Premium PLC racks and CPUs.
-
Comprehensive Protection: Internal circuits prevent damage due to electrical faults.
-
Visual Diagnostics: Equipped with LED indicators for operational and fault monitoring.
-
Reliable in Harsh Environments: Performs consistently in industrial temperature and humidity ranges.
-
Energy Efficient: Reduces power loss and thermal buildup through efficient voltage regulation.
-
Simple Installation: Modular plug-in format ensures quick integration and system upgrades.
-
Compact Footprint: 保存s valuable cabinet space while delivering high power density.
Industry Applications
-
Manufacturing automation and production lines
-
Process industries (chemical, pharmaceutical, food & beverage)
-
Building management systems
-
Water treatment and pumping stations
-
Energy and power generation control
-
Transportation and infrastructure control systems
-
SCADA-based industrial networks
常见问题 (FAQ)
-
Q: What PLCs are compatible with the TSXPSY2600M?
A: It is designed for use with Schneider Modicon Premium series PLCs. -
Q: What is the maximum power output / this module?
A: It delivers up to 30 W (5 VDC at 6 A). -
Q: Can this power module be hot-swapped?
A: No, power must be turned /f before installing or removing the module. -
Q: Is this module suitable for redundant power systems?
A: It can be used in systems with power redundancy architecture, but not as an active redundant 件. -
Q: What kind / protection does it include?
A: It has protection against short-circuit, overload, and overvoltage conditions. -
Q: Does it require additional cooling?
A: No, passive cooling is sufficient under standard operating conditions. -
Q: Are there any status indicators?
A: Yes, it includes LEDs for Power ON (green) and Fault (red) conditions. -
Q: Can it be used in high-vibration environments?
A: Yes, provided it is properly installed in a secure rack, as per Schneider specifications. -
Q: Is the TSXPSY2600M RoHS compliant?
A: Yes, it meets RoHS environmental compliance standards. -
Q: What certifications does it carry?
A: CE, UL, CSA, and RoHS certifications are supported.
