产品介绍
The Schneider TSXPACC01 Terminal Port Connection Box is a specialized accessory from the Modicon Premium automation platform, designed to facilitate the connection / operator terminals and programming tools to PLC processors. It provides a structured interface for connecting Human-Machine Interfaces (HMI), programming PCs, or other serial communication devices to the Modicon PLC series via RS232 or RS485 communication ports.
Compact, durable, and easy to install, the TSXPACC01 helps streamline communication and system diagnostics in automation environments. Its integration into a control cabinet or on-site machine panel ensures safe and efficient data access without interrupting system operation. Whether used for commissioning, maintenance, or runtime monitoring, this terminal port connection box enhances the accessibility and flexibility / industrial automation systems.
产品规格
| Parameter | Specification |
|---|---|
| 型号 | TSXPACC01 |
| Product Type | Terminal Port Connection Box |
| Communication Type | RS232 / RS485 |
| Number / Ports | 1 (RJ45 serial port) |
| Interface Compatibility | Compatible with TSX series processors (e.g., TSX P57) |
| Cable Type | Used with TSXCRJMD25 and other serial cables |
| Power Supply | Not required (passive device) |
| Mounting | Panel mounting |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -25°C to +85°C |
| Relative Humidity | 5% to 95%, non-condensing |
| Dimensions (W x H x D) | 65 x 195 x 215 mm |
| 重量 | 0.69 kg |
| Material | Flame-retardant thermoplastic |
| Certifications | CE, UL, RoHS compliant |
Product Applications
The TSXPACC01 is used primarily in environments where ease / access to programming or operator interfaces is essential. Its core applications include:
-
Programming Port Extension: Acts as an accessible programming port extension from a controller inside a cabinet to the outside for easy laptop or HMI connection.
-
Industrial Machinery: Installed on machine panels for quick connection / HMIs or diagnostic tools in packaging, CNC, and conveyor systems.
-
Process Control Systems: Used in SCADA systems to connect supervisory terminals to Modicon PLCs without disturbing control wiring.
-
Maintenance and Troubleshooting: Allows quick connection / diagnostic or configuration tools for real-time PLC monitoring and error resolution.
-
Control Cabinets: Installed externally for operator access, while the PLC remains safely mounted inside the panel.
-
Training and Simulation: Useful in educational or simulated environments where frequent controller connections are required.
Product Advantages
-
Simplified Interface Access: Allows connection to controllers without opening control cabinets, improving safety and convenience.
-
Compact Design: Its small footprint makes it suitable for tight spaces on cabinet doors or machine panels.
-
Versatile Compatibility: Works seamlessly with Modicon TSX Premium processors and standard serial tools.
-
No External Power Needed: Passive device that simplifies installation and reduces system complexity.
-
Industrial-Grade Durability: Built using high-quality thermoplastic material that resists heat, vibration, and mechanical wear.
-
Fast Maintenance Turnaround: Enables rapid diagnostics and reprogramming by providing easy access to communication ports.
-
Reduces Wear on PLC Ports: Acts as a buffer, extending port lifespan on expensive PLC hardware.
-
Standardized Connectivity: Uses industry-standard RJ45 port and Schneider serial cables for fast, reliable communication.
-
Clean Panel Design: Helps organize and maintain a clean, pr/essional cabinet layout.
-
Cost-Effective: Provides essential functionality at minimal cost, supporting efficient automation design.
常见问题 (FAQ)
-
What is the primary use / the TSXPACC01?
It provides a convenient external communication port for connecting programming or operator interface devices to a Modicon TSX PLC. -
Is the TSXPACC01 compatible with all 施耐德s?
It is specifically designed for use with TSX Premium processors such as TSX P57 models. -
Does the TSXPACC01 require a separate power supply?
No, it is a passive device and requires no external power source. -
What type / communication does it support?
It supports serial RS232 and RS485 communication. -
Can I use a standard Ethernet cable for this device?
No, although the port looks like an RJ45, it is used for serial communication and requires Schneider serial cables like TSXCRJMD25. -
How is it mounted?
It is panel-mounted and typically installed on cabinet doors or control panels. -
What are the environmental tolerances / this product?
It operates between 0°C and +60°C and can be stored between -25°C and +85°C. -
What is the weight and size / the device?
The module weighs 0.69 kg and measures 65 x 195 x 215 mm. -
Is it safe to use in industrial environments?
Yes, it is CE and UL certified, and built from industrial-grade materials for rugged environments. -
What devices can be connected to the TSXPACC01?
Programming laptops, HMIs, diagnostic tools, and communication adapters using Schneider serial cables.
Recommended Related 型号s (Same Series or Related Use)
| 型号 | 描述 | Application | Dimensions (mm) | 重量 (kg) |
|---|---|---|---|---|
| TSXPACC02 | Terminal Block with Protective Cap | RS232/RS485 external access | 70 x 48 x 28 | 0.09 |
| TSXCRJMD25 | Serial Communication Cable | RJ45 to DB25 cable for TSX PLCs | Cable: 2.5m | 0.18 |
| TSXP57104M | TSX Premium Processor | Main controller 件 | 145 x 160 x 70 | 0.62 |
| TSXDMZ28DR | Digital I/O Module | PLC digital input/output extension | 120 x 105 x 85 | 0.35 |
| TSXDEY64D2K | Digital Input Module (64 pts) | High-density input channel | 180 x 115 x 85 | 0.50 |
| TSXP573634M | Advanced TSX Premium PLC CPU | Enhanced memory and Ethernet support | 160 x 160 x 70 | 0.65 |
Popular Schneider Electric 型号s (Same 品牌)
| 型号 | Product Type | Main Function | 重量 (kg) |
|---|---|---|---|
| Modicon M221 | Compact Logic Controller | Small automation tasks | 0.60 |
| Modicon M340 | Modular PLC | Mid-size control applications | 1.10 |
| Altivar ATV320 | Variable Speed Drive | Motor control and energy savings | 2.10 |
| Harmony XB5 | Signaling and Control 单位s | Push buttons, pilot lights | Varies |
| Lexium 32 Servo | Servo Drive System | Precision motion control | 1.80 |
| TeSys D 联系我们or | 联系我们or and Motor Starter | Motor switching and protection | 0.80 |
