Product Overview
The Schneider Electric TSXDSY16S5 is a discrete output module designed for use with the Modicon Premium automation platform. It features 16 logic output channels designed for sourcing (positive logic) digital signals, delivering reliable control for a wide range / industrial automation systems.
With a 24 VDC output voltage and short-circuit protection, the TSXDSY16S5 /fers efficient and safe switching / actuators, indicators, and other field devices. It’s particularly valued for its high-density configuration and robust performance in industrial environments.
Key Features
-
16 sourcing (positive logic) discrete outputs
-
Compatible with Modicon Premium PLCs
-
24 VDC output voltage
-
Electronic protection against short-circuits
-
LED channel status indicators
-
Isolated outputs with high electrical noise imm件y
-
DIN rail or rack-mountable (via backplane)
-
Ideal for controlling solenoids, relays, and lamps
Technical Specifications
| Parameter | Specification |
|---|---|
| 型号 | TSXDSY16S5 |
| Product Type | Discrete Output Module |
| Number / Channels | 16 outputs |
| Output Type | Sourcing (positive logic) |
| Output Voltage | 24 VDC |
| Current per Channel | 0.5 A max |
| Max Module Load | 8 A total |
| Isolation | 500 V between groups and system |
| Protection | Electronic (overload and short-circuit protection) |
| Channel Status Display | Individual LED per output |
| Response Time | 0.5 ms on / 0.5 ms /f |
| Backplane Current | 70 mA |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% non-condensing |
| Dimensions | Package size 55 × 180 × 260 mm |
| 重量 | 0.31 kg |
| Certifications | CE, UL, CSA |
Industry Applications
-
Manufacturing Automation – Actuator and indicator control in production lines
-
Food & Beverage – Sanitary machinery automation and bottle/can handling systems
-
Packaging Machinery – Controlling diverters, labeling, and cartonizing equipment
-
Material Handling – Conveyor and sorting automation
-
Building Automation – Lighting, HVAC, and door/gate systems
-
Energy and Utilities – Supervisory control / remote equipment and facilities
Product Advantages
-
High Channel Density – 16 channels in a compact footprint
-
Fast Switching Response – Ensures real-time control precision
-
LED Status Feedback – Immediate diagnostics and troubleshooting
-
Reliable Output Protection – Protects the module and system wiring
-
Industrial-Grade Durability – Operates in harsh environments
-
Direct Rack Integration – No external power supply or adapters required
-
Standardized Wiring – Simplifies installation and maintenance
-
Enhanced Compatibility – Seamless operation with Modicon Premium PLCs
常见问题 (FAQ)
-
What is the voltage rating / TSXDSY16S5 outputs?
Each output is rated for 24 VDC sourcing. -
How many outputs does the module provide?
It /fers 16 discrete sourcing output channels. -
Is the TSXDSY16S5 protected against short circuits?
Yes, it includes internal electronic protection. -
Can this module be hot-swapped?
No, the TSXDSY16S5 should be powered down before replacement. -
What does each LED on the front panel indicate?
Each LED shows the status (ON/OFF) / the corresponding output channel. -
Can it drive inductive loads like solenoids and relays?
Yes, it is suitable for such loads within the 0.5 A/channel limit. -
Is it compatible with TSX Premium racks?
Yes, it is fully compatible with TSX Premium system racks and CPUs. -
Does it support output diagnostics?
It /fers basic LED indication but not advanced diagnostics. -
What is the maximum current load for the entire module?
The total load should not exceed 8 A across all channels. -
Can this module be used in a redundant system?
While not redundant by itself, it can be part / a redundant control system architecture.
