Product Overview
The Schneider TSXAEY414 is a 4-channel analog input module belonging to the Modicon Premium automation platform. This module is specifically designed to interface with analog signals from sensors and transmitters in industrial environments. 支持ing high-resolution 16-bit analog-to-digital conversion, it provides precise data collection essential for accurate process control. Built with robustness in mind, the TSXAEY414 is engineered to operate reliably in demanding industrial conditions, ensuring consistent system performance.
Technical Specifications
| Parameter | Details |
|---|---|
| Product Type | Analog Input Module |
| Series | Modicon Premium |
| 型号 Number | TSXAEY414 |
| Input Channels | 4 Channels |
| Input Signal Types | Voltage (0–10 VDC), Current (4–20 mA) |
| Input Range | 0–10 VDC or 4–20 mA |
| Resolution | 16-bit |
| Conversion Method | Analog-to-Digital (A/D) |
| Accuracy | High precision with low drift |
| Isolation | Channel-to-bus and channel-to-channel isolation |
| Power Supply | 5 VDC from system backplane |
| Current Consumption | 660 mA |
| Mounting | DIN rail or rack mount (Modicon Premium rack) |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Relative Humidity | 5% to 95% non-condensing |
| Dimensions (H x W x D) | 55 x 180 x 260 mm |
| 重量 | 0.32 kg |
| Certifications | CE, UL, RoHS |
Applications
The TSXAEY414 is ideal for industries that rely on precise analog signal processing:
-
Manufacturing Plants: For monitoring temperature, pressure, or fluid levels.
-
Pharmaceutical and Food Processing: Where precision in measurements is critical to safety and compliance.
-
Water Treatment Facilities: Monitoring flow and chemical concentrations.
-
HVAC and Building Automation: To ensure accurate climate control.
-
Energy and Utility Monitoring: In power generation and distribution environments.
Advantages
-
High Accuracy: Delivers 16-bit resolution for superior signal fidelity.
-
Robust Isolation: Reduces the risk / interference between input channels.
-
Wide Compatibility: Accepts both voltage and current input types.
-
Modular Integration: Easily fits into existing Modicon Premium PLC setups.
-
Durable Design: Built for high-performance operation in harsh industrial environments.
-
Ease / Use: Plug-and-play integration within Schneider’s ecosystem.
常见问题 (FAQ)
-
What types / input signals are supported by TSXAEY414?
-
The module supports both 0–10 VDC and 4–20 mA analog signals.
-
-
Can this module be used with sensors requiring high resolution?
-
Yes, it provides 16-bit resolution suitable for precision applications.
-
-
Is the TSXAEY414 compatible with Modicon M340 or M580?
-
No, it is specifically designed for the Modicon Premium series.
-
-
Does this module provide electrical isolation?
-
Yes, channel-to-bus and channel-to-channel isolation is included.
-
-
What is the main use / TSXAEY414?
-
It is primarily used for measuring and digitizing analog process signals.
-
-
What is the power consumption / the module?
-
It consumes approximately 660 mA at 5 VDC.
-
-
Is the TSXAEY414 hot-swappable?
-
No, modules should only be inserted or removed when the system is powered down.
-
-
What certifications does it hold?
-
It is CE marked, UL listed, and RoHS compliant.
-
-
Can it function in high humidity environments?
-
Yes, it is designed to operate in environments with up to 95% non-condensing humidity.
-
-
Is there a recommended replacement for this module?
-
For new systems, Schneider recommends using analog modules from the Modicon M340 or M580 series.
Recommended Related 型号s (Same Series)
| 型号 Number | 描述 |
|---|---|
| TSXAEY1600 | 16-channel analog input module, voltage/current capable |
| TSXAEY800 | 8-channel analog input module with wide signal support |
| TSXAEY4141 | Advanced 4-channel analog input with diagnostic features |
| TSXAEY4142 | Enhanced version with temperature compensation |
| TSXDEY64D2K | 64-channel digital input module, Premium series |
| TSXASY410 | Serial communication module for Modicon Premium PLCs |
Popular Schneider Modules (Same 品牌)
| 型号 Number | 描述 |
|---|---|
| BMXAMI0810 | 8-channel analog input module for Modicon M340 |
| BMXART0414 | RTD analog input module for temperature measurement |
| TM5SAI2H | 2-channel analog input module for Modicon TM5 series |
| BMXDDI3202K | 32-channel digital input module |
| TM3AI8 | Compact 8-channel analog input module |
| BMXNOE0110 | Ethernet communication module for remote I/O and networking |
