Product Overview
The Schneider TM3DM24R is a discrete input/output (I/O) module designed to provide reliable digital signal interfacing for modular automation systems. It is part / Schneider Electric’s range / TM3 modular I/O 件s, engineered to deliver flexible and efficient signal acquisition and control in industrial environments.
This module supports discrete digital inputs and outputs, allowing it to interface with a wide variety / field devices such as switches, sensors, actuators, and relays. The TM3DM24R is especially suitable for applications requiring compact, modular, and scalable I/O configurations, ensuring easy expansion and maintenance.
Designed with Schneider Electric’s high standards, the TM3DM24R /fers robust electrical and mechanical performance, making it ideal for use in factory automation, process control, and building management systems.
Technical Specifications
| Specification | 描述 |
|---|---|
| 型号 Number | TM3DM24R |
| Module Type | Discrete Input/Output Module |
| Number / Inputs | 12 digital inputs |
| Number / Outputs | 12 digital outputs |
| Input Voltage | 24 V DC nominal |
| Output Voltage | 24 V DC nominal |
| Output Type | Relay or transistor (depending on variant) |
| Input Type | Sinking or sourcing (depending on wiring) |
| Current per Output | Up to 0.5 A per channel |
| Response Time | Typically < 1 ms |
| Operating Temperature | -25°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% non-condensing |
| Dimensions | 90 x 84.6 x 42.9mm |
| 重量 | Package weight 0.281kg |
| Mounting Type | DIN rail mounting |
| Protection Rating | IP20 |
| Communication Interface | Backplane bus connection |
| Certifications | CE, UL, cUL, RoHS compliant |
Industry Applications
-
Factory and Machine Automation
-
Process Control Systems
-
Building Management Systems
-
Packaging and Material Handling
-
HVAC Control
-
Water Treatment Plants
-
Food and Beverage Industry
-
Automotive Manufacturing
Key Advantages
-
Modular Design: Easily integrates into TM3 modular I/O systems for flexible expansion.
-
High Channel Count: 支持s up to 12 digital inputs and 12 digital outputs in one compact 件.
-
Reliable Signal Processing: Fast response time (<1 ms) for time-sensitive applications.
-
Robust Construction: Wide temperature range and humidity tolerance ensure dependable operation.
-
Easy Installation: Standard DIN rail mounting simplifies setup and maintenance.
-
Versatile Input/Output Options: Compatible with both sinking and sourcing inputs; relay or transistor outputs.
-
Safety and Compliance: Meets international safety and environmental standards.
-
Compact Size: Space-saving footprint suitable for control panels with limited space.
常见问题 (FAQ)
-
How many digital inputs and outputs does the TM3DM24R module have?
It provides 12 digital inputs and 12 digital outputs. -
What is the nominal operating voltage for the inputs and outputs?
Both inputs and outputs nominally operate at 24 V DC. -
What types / output configurations are available?
Outputs can be relay-based or transistor-based depending on the module variant. -
What is the typical response time / the module?
The response time is typically less than 1 millisecond. -
What are the mounting options for this module?
The TM3DM24R is designed for standard DIN rail mounting. -
What temperature range can the module operate within?
It operates between -25°C and +60°C. -
Is the module protected against environmental contaminants?
It has an IP20 protection rating, suitable for clean industrial environments. -
Can this module be used in hazardous environments?
Not specifically certified for hazardous locations; check specific certifications if required. -
Is the module compatible with other Schneider TM3 modules?
Yes, it integrates fully with the Schneider TM3 modular I/O system. -
What certifications does the TM3DM24R hold?
It is CE, UL, cUL certified and RoHS compliant.
