Schneider TM3DI16G Modicon TM3 Discrete Input Module
The Schneider TM3DI16G is a compact and efficient discrete input module from the Modicon TM3 range. Designed to interface with Modicon M221, M241, and M251 controllers, it provides fast and reliable acquisition / 24 VDC digital signals for automation systems.
Product Features
-
16 discrete input channels
-
24 VDC input voltage
-
Sink/source (positive/negative) compatibility
-
Easy integration with Modicon TM3 expansion blocks
-
DIN rail mounting for quick installation
Technical Specifications
| Parameter | Specification |
|---|---|
| 型号 Number | TM3DI16G |
| Product Type | Discrete Input Module |
| Number / Inputs | 16 |
| Input Voltage | 24 VDC |
| Input Type | Sink or Source |
| Isolation | 500 V AC between input and logic |
| Input Current | 3 mA per channel |
| Input Delay | 3 ms |
| Status Indicators | 16 LEDs (1 per channel) |
| Mounting Type | DIN Rail |
| Dimensions (W x H x D) | 90 x 84.6 x 27.4 mm |
| 重量 | 0.1 kg |
Applications
-
Industrial automation
-
Packaging machinery
-
Conveying systems
-
Building management systems
-
Control panel integration
Product Advantages
-
Compact footprint saves panel space
-
Plug-and-play connectivity with TM3 I/O blocks
-
High signal reliability in noisy environments
-
Simplifies wiring and reduces setup time
-
Compatible with multiple Modicon PLC platforms
常见问题 (FAQ)
Q1: What voltage does the TM3DI16G support?
A1: It operates at 24 VDC.
Q2: How many discrete input channels are available?
A2: The module supports 16 digital inputs.
Q3: Is the TM3DI16G compatible with all Modicon PLCs?
A3: It is compatible with Modicon M221, M241, and M251 controllers.
Q4: What type / signals can it receive?
A4: It accepts both sink and source type signals.
Q5: Does it support hot-swap functionality?
A5: No, modules should be powered /f before installation or removal.
Q6: How is the module mounted?
A6: It is designed for DIN rail mounting.
Q7: Are there LED indicators for input status?
A7: Yes, each input has its own LED indicator.
Q8: What is the delay time per input?
A8: The typical input delay is 3 milliseconds.
Q9: What is the isolation level between input and logic?
A9: 500 VAC.
Q10: Can it be used in harsh industrial environments?
A10: Yes, it is built to operate in industrial automation systems.
Related or Similar Schneider TM3 型号s
| 型号 | 描述 | Inputs/Outputs | Voltage | Dimensions (mm) | 重量 |
|---|---|---|---|---|---|
| TM3DI8G | Discrete Input Module | 8 inputs | 24 VDC | 90 x 84.6 x 27.4 | 0.08 kg |
| TM3DQ8G | Discrete Output Module | 8 outputs | 24 VDC | 90 x 84.6 x 27.4 | 0.08 kg |
| TM3DQ16G | Discrete Output Module | 16 outputs | 24 VDC | 90 x 84.6 x 27.4 | 0.1 kg |
| TM3DI16K | Isolated Discrete Input Module | 16 inputs | 24 VDC | 90 x 84.6 x 27.4 | 0.1 kg |
| TM3DQ16K | Isolated Discrete Output Module | 16 outputs | 24 VDC | 90 x 84.6 x 27.4 | 0.1 kg |
| TM3DM24G | Mixed I/O Module | 14 in / 10 out | 24 VDC | 90 x 84.6 x 27.4 | 0.11 kg |
Popular Schneider 型号s
| 型号 | 描述 | Type | Voltage | Dimensions (mm) | 重量 |
|---|---|---|---|---|---|
| TM221CE24T | Modicon M221 Logic Controller | Compact PLC | 24 VDC | 130 x 95 x 70 | 0.5 kg |
| TM241CE40T | Modicon M241 Performance Controller | PLC with Ethernet | 24 VDC | 184 x 100 x 90 | 0.7 kg |
| TM251MESE | Modicon M251 Motion Controller | PLC with dual Ethernet | 24 VDC | 197 x 100 x 90 | 0.75 kg |
| BMXDDI3202K | Modicon X80 Discrete Input Module | 32 inputs | 24 VDC | 100 x 110 x 50 | 0.3 kg |
| BMXDRA1605 | Modicon X80 Discrete Output Module | 16 outputs | 24 VDC | 100 x 110 x 50 | 0.35 kg |
| LXM28AU04M3X | Lexium 28 Servo Drive | Servo Drive | 3-phase 230 VAC | 180 x 150 x 85 | 1.8 kg |
