The Schneider BMXDDO6402K is a high-density discrete output module designed for use within the Modicon M340 programmable logic controller (PLC) system. It features 64 transistor output channels, delivering a powerful and flexible solution for controlling a large number / discrete actuators, indicators, and switching devices in complex industrial automation environments.
This module is engineered to provide reliable, fast, and efficient switching performance. It integrates seamlessly with the Modicon M340 series, allowing users to scale their control systems with ease. The BMXDDO6402K /fers excellent electrical isolation, rugged construction, and straightforward installation, making it a preferred choice for demanding industrial applications.
Technical Specifications
| Parameter | Specification |
|---|---|
| Number / Outputs | 64 Discrete Outputs |
| Output Type | Transistor (NPN, sinking type) |
| Rated Voltage | 24 V DC |
| Maximum Current per Channel | 0.5 A |
| Total Current (max) | 32 A (aggregate) |
| Response Time | < 0.5 ms |
| Isolation | Optical isolation between outputs and logic |
| Operating Temperature | 0 °C to 60 °C |
| Storage Temperature | -40 °C to +85 °C |
| Humidity | 5% to 95% non-condensing |
| Mounting | DIN Rail |
| Dimensions (HxWxD) | 160 x 100 x 35 mm |
| 重量 | 0.15 kg |
| Certifications | CE, UL, CSA |
| Communication Interface | Backplane bus for Modicon M340 PLC |
| Status LEDs | Per output channel status indication |
Applications
The BMXDDO6402K module is suitable for extensive and complex control applications in various industrial sectors, such as:
-
Large-scale manufacturing lines requiring simultaneous control / numerous actuators and indicators.
-
Process control industries where rapid and reliable switching / valves, pumps, and motors is necessary.
-
Building automation for controlling lighting, alarms, and HVAC equipment.
-
Energy management systems where discrete switching controls are integrated with energy-saving strategies.
-
Infrastructure projects such as water treatment plants, sewage systems, and transportation networks.
-
Packaging and material handling systems requiring high channel counts with reliable discrete outputs.
Advantages
-
High Channel Density: Provides 64 discrete outputs in a compact form factor, enabling efficient use / panel space.
-
Fast Switching Speed: With response times under 0.5 ms, the module supports precise and timely control actions.
-
Optical Isolation: Ensures robust protection against electrical noise, transients, and ground loops.
-
Durable Build: Designed for industrial environments, capable / withstanding temperature variations and humidity.
-
Modular Integration: Perfectly compatible with the Modicon M340 PLC, allowing easy system expansion and maintenance.
-
Clear Diagnostics: Each channel has an LED indicator for straightforward troubleshooting.
-
Energy Efficient: Low power consumption reduces heat dissipation and energy costs.
-
Safety Certifications: Meets international safety and quality standards for industrial applications.
常见问题 (FAQ)
-
What type / output does the BMXDDO6402K module provide?
It provides 64 transistor outputs / NPN sinking type, rated at 24 V DC. -
Can this module be used with Modicon M340 PLCs only?
Yes, the BMXDDO6402K is designed specifically for Modicon M340 series PLCs. -
What is the maximum current per output channel?
Each channel supports a maximum current / 0.5 A. -
What is the total maximum current for all channels combined?
The total aggregate current is limited to 32 A. -
How is the module mounted?
It is mounted on a standard DIN rail. -
What are the operating temperature limits?
The module operates reliably between 0 °C and 60 °C. -
Is there any protection against electrical noise?
Yes, the outputs are optically isolated to protect against noise and interference. -
How can I identify if an output channel is active?
Each output has an LED status indicator on the module. -
Can I control AC loads directly with this module?
No, this module is intended for DC loads only. -
What certifications does the BMXDDO6402K have?
It holds CE, UL, and CSA certifications.
Recommended Related 型号s (Same Series or Functionality)
| 型号 | 描述 | Number / Outputs | Output Type | Voltage | Dimensions (HxWxD) | 重量 (g) |
|---|---|---|---|---|---|---|
| BMXDDO3202 | 32-Channel Discrete Output | 32 | Transistor (NPN) | 24 V DC | 90 x 70 x 60 mm | 200 |
| BMXDDO1612 | 16-Channel Discrete Output | 16 | Transistor (NPN) | 24 V DC | 90 x 35 x 60 mm | 120 |
| BMXDDO6404 | 64-Channel Discrete Output | 64 | Transistor (PNP) | 24 V DC | 170 x 90 x 60 mm | 460 |
| BMXDDO3204 | 32-Channel Discrete Output | 32 | Transistor (PNP) | 24 V DC | 90 x 70 x 60 mm | 210 |
| BMXDDO0802 | 8-Channel Discrete Output | 8 | Transistor (NPN) | 24 V DC | 90 x 35 x 45 mm | 90 |
| BMXDDO1602 | 16-Channel Discrete Output | 16 | Transistor (NPN) | 24 V DC | 90 x 35 x 60 mm | 120 |
Popular Schneider Electric PLC Modules (Same 品牌)
| 型号 | 描述 | Type | Number / Channels | Voltage | Dimensions (HxWxD) | 重量 (g) |
|---|---|---|---|---|---|---|
| BMXP342020 | 8-Channel Analog Input Module | Analog Input | 8 | 0-10 V | 90 x 35 x 60 mm | 120 |
| BMXDIA1602 | 16-Channel Analog Output Module | Analog Output | 16 | 0-20 mA | 90 x 35 x 60 mm | 125 |
| BMXNOE0100 | Ethernet Communication Module | Network Module | N/A | N/A | 90 x 35 x 60 mm | 110 |
| BMXAMO0200 | Analog Output Module | Analog Output | 2 | 0-10 V | 90 x 35 x 45 mm | 95 |
| BMXP342030 | 16-Channel Analog Input Module | Analog Input | 16 | 0-10 V | 90 x 35 x 60 mm | 130 |
| BMXDDO3200 | 32-Channel Discrete Output Module | Discrete Output | 32 | 24 V DC | 90 x 70 x 60 mm | 200 |
