Schneider ATV630D37N4 Variable Speed Drive
The Schneider ATV630D37N4 is a robust and efficient variable speed drive designed for industrial motor control. It ensures optimized performance, energy savings, and reliability in demanding applications.
Product 描述
The ATV630D37N4 is part / the Altivar Process ATV600 series, tailored for controlling 3-phase asynchronous and synchronous motors. With advanced energy monitoring and process optimization features, it is ideal for pumping, ventilation, and industrial processes.
Technical Specifications
| Parameter | Value |
|---|---|
| 型号 | ATV630D37N4 |
| Power Rating | 37 kW (50 HP) |
| Supply Voltage | 380…480 V AC (3-phase) |
| Frequency Range | 0.1…500 Hz |
| Output Current | 72 A |
| Control Type | V/F, Vector Control |
| Protection Degree | IP21 |
| Operating Temperature | -15°C to +50°C |
| Dimensions (W x H x D) | 226 x 673 x 271 mm |
| 重量 | 28.2 kg |
Applications
-
Water and wastewater treatment systems
-
HVAC (Heating, Ventilation, Air 状态ing)
-
Pumping stations
-
Material handling
-
Industrial process control
-
Energy management systems
Advantages
-
High energy efficiency with real-time monitoring
-
Advanced motor protection and diagnostics
-
Easy integration with industrial networks
-
Compact design for space-saving installations
-
Reduced maintenance due to robust design
-
User-friendly interface with intuitive display
常见问题
Q1: What is the input voltage range for the ATV630D37N4?
A1: It operates on 380–480 V AC, 3-phase.
Q2: Can it control both asynchronous and synchronous motors?
A2: Yes, it supports both motor types effectively.
Q3: Is it suitable for high humidity environments?
A3: Yes, with proper installation and optional conformal coating for extreme conditions.
Q4: What communication protocols are supported?
A4: It supports Modbus, Ethernet, CANopen, and more via optional cards.
Q5: Does it feature energy consumption monitoring?
A5: Yes, it provides real-time energy monitoring and diagnostics.
Q6: Can the drive be used for HVAC applications?
A6: Absolutely, it is optimized for HVAC fans, pumps, and compressors.
Q7: What is the maximum output frequency?
A7: The drive can output up to 500 Hz.
Q8: Is there an option for remote monitoring?
A8: Yes, remote monitoring is possible through network connectivity.
Q9: Does it have any safety certifications?
A9: Yes, it meets international standards like CE and UL.
Q10: How is the cooling / the drive managed?
A10: It uses forced air cooling with integrated fans.
Recommended Related 型号s (Same Series or Similar)
| 型号 | Power Rating | Voltage | Dimensions (mm) | 重量 |
|---|---|---|---|---|
| ATV630D22N4 | 22 kW | 380–480V | 226 x 550 x 271 | 22.3 kg |
| ATV630D30N4 | 30 kW | 380–480V | 226 x 673 x 271 | 27.1 kg |
| ATV630D45N4 | 45 kW | 380–480V | 226 x 853 x 271 | 36.4 kg |
| ATV630D55N4 | 55 kW | 380–480V | 226 x 853 x 271 | 39.2 kg |
| ATV630D75N4 | 75 kW | 380–480V | 276 x 1033 x 328 | 60.2 kg |
| ATV630D90N4 | 90 kW | 380–480V | 276 x 1033 x 328 | 64.8 kg |
Popular Schneider 型号s
| 型号 | Power Rating | Voltage | Dimensions (mm) | 重量 |
|---|---|---|---|---|
| ATV320U07M2C | 0.75 kW | 200–240V | 72 x 143 x 148 | 1.2 kg |
| ATV320U15N4C | 1.5 kW | 380–480V | 72 x 143 x 148 | 1.3 kg |
| ATV340D22N4E | 22 kW | 380–480V | 180 x 502 x 232 | 19.5 kg |
| ATV71HD11N4 | 11 kW | 380–480V | 142 x 380 x 232 | 9.8 kg |
| ATV71HD45N4 | 45 kW | 380–480V | 226 x 853 x 271 | 36.4 kg |
| ATV71HU30N4 | 30 kW | 380–480V | 226 x 673 x 271 | 27.1 kg |
