Product Overview
The Schneider ATV312H055N4 is a member / the Altivar 312 series / variable speed drives (VSDs) designed to provide efficient and reliable control / three-phase asynchronous motors. This compact, user-friendly drive is ideal for a wide range / industrial and commercial applications requiring precise speed and torque regulation. It features integrated motor control functions, energy-saving capabilities, and robust protection features.
With easy installation, programming, and maintenance, the ATV312H055N4 is engineered to optimize motor performance, extend equipment life, and reduce operating costs.
Key Features
-
Power rating: 5.5 kW (7.5 HP)
-
Compact design with IP20 enclosure
-
Integrated PID controller for process control
-
Built-in EMC filter compliant with EN 61800-3 category C2
-
Multiple communication options (Modbus, CANopen) available via optional modules
-
Dynamic braking resistor support
-
Safe torque /f (STO) functionality for enhanced safety
-
Adjustable acceleration and deceleration ramps
-
Built-in fault diagnostics and protection functions
-
Easy-to-use interface with LCD display and keypad
Technical Specifications
| Parameter | Specification |
|---|---|
| 型号 Number | ATV312H055N4 |
| Output Voltage | 0 to input voltage |
| Output Frequency | 0 to 500 Hz |
| Output Current (Nominal) | 13 A |
| Control Method | V/F (Volts per Hertz) with sensorless vector control option |
| Degree / Protection | IP20 |
| Dimensions | 143 x 107 x 152mm |
| 重量 | 1.8 kg |
| Operating Temperature | -10°C to +50°C |
| Storage Temperature | -40°C to +70°C |
| Communication Protocols | Optional Modbus, CANopen via communication modules |
| Safety Features | Safe Torque Off (STO), motor thermal protection |
| Certifications | CE, UL, cUL, RoHS |
Industry Applications
The ATV312H055N4 is suitable for various industrial sectors requiring variable speed motor control:
-
HVAC systems: Fans, pumps, compressors
-
Water and wastewater treatment: Pumps, mixers
-
Material handling: Conveyors, cranes
-
Food and beverage: Mixers, packaging machines
-
Textile industry: Spinners, looms
-
General manufacturing: Machine tools, extruders
Product Advantages
-
Energy Efficiency: Optimizes motor operation to reduce energy consumption.
-
Compact Size: Fits easily into control panels with limited space.
-
User-Friendly Interface: Intuitive LCD and keypad simplify setup and monitoring.
-
Advanced Motor Control: 支持s sensorless vector control for improved torque and speed precision.
-
Enhanced Safety: Integrated Safe Torque Off (STO) for operator protection.
-
Robust Construction: Durable components designed for reliable industrial use.
-
Flexible Communication: 支持s multiple protocols for seamless integration.
-
Built-In Diagnostics: Enables quick troubleshooting and reduces downtime.
-
Wide Operating Range: Suitable for diverse environmental conditions.
-
Cost-Effective Maintenance: Easy to service and maintain.
常见问题 (FAQ)
-
Q: What motors are compatible with the ATV312H055N4?
A: It is compatible with three-phase asynchronous motors rated for 380–480 V. -
Q: Can this drive control motor speed without an encoder?
A: Yes, it /fers sensorless vector control to regulate speed and torque without feedback devices. -
Q: Does the drive support communication protocols?
A: Yes, with optional modules, it supports Modbus and CANopen. -
Q: What safety features does this drive include?
A: It includes Safe Torque Off (STO) and motor thermal protection. -
Q: What is the ambient temperature range for operation?
A: The drive operates between -10°C and +50°C. -
Q: Can this drive be used in hazardous environments?
A: This model does not have hazardous location certifications. -
Q: Is dynamic braking supported?
A: Yes, it supports dynamic braking resistors for rapid deceleration. -
Q: What kind / user interface does the drive have?
A: It has an LCD display with keypad for easy programming and monitoring. -
Q: What is the degree / protection / this drive?
A: It has an IP20 protection rating, suitable for indoor installations. -
Q: How does this drive contribute to energy savings?
A: By adjusting motor speed to process demands, it reduces energy consumption and operating costs.
