Product Introduction
The Schneider Electric 171CCC96030 is a high-performance M1/M1E Processor Adapter, designed to integrate and optimize Modicon M1/M1E controllers into your automation environment. This adapter plays a vital role in connecting the M1/M1E processors to various network and I/O modules, providing a smooth interface for communication and control within complex automation systems.
The 171CCC96030 processor adapter is typically used in combination with the Modicon M1 or M1E series / controllers, enabling users to extend functionality across industrial networks. With its robust design and reliable connectivity, the adapter ensures seamless operation in real-time applications that demand high-speed processing and accuracy.
产品规格
| Parameter | Specification |
|---|---|
| 制造商 | Schneider Electric |
| Product 型号 | 171CCC96030 |
| Series | Modicon M1/M1E |
| Processor Compatibility | Modicon M1, M1E Controllers |
| Interface Type | Ethernet, Serial, or Proprietary (depends on configuration) |
| Data Rate | High-speed processing, network communication up to 1 Gbps |
| Communication Protocol | Modbus TCP/IP, Ethernet/IP, or Custom Schneider Protocol |
| Power Supply | 24 V DC |
| Mounting Type | DIN Rail Mountable |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Relative Humidity | 5% to 95% non-condensing |
| Protection Rating | IP20 |
| Dimensions (H x W x D) | 60 x 180 x 260 mm |
| 重量 | 0.042 kg |
| Status Indicators | LED indicators for operational status and error monitoring |
| Certification | CE, UL, RoHS Compliance |
Product Applications
The 171CCC96030 M1/M1E Processor Adapter is widely used across various industrial automation systems, including:
-
Manufacturing Automation
Used in controlling robotic arms, conveyors, and assembly lines, ensuring precision and real-time performance. -
Building Management Systems
Integrating HVAC, lighting, and security systems to enable centralized monitoring and control. -
Energy Management Systems
Facilitates the collection and analysis / data from various energy sources to optimize energy consumption. -
Process Control Systems
Ensures smooth, real-time control over manufacturing processes in industries like chemicals, pharmaceuticals, and food production. -
Material Handling
Integrates with conveyor systems and warehouses for efficient inventory management and distribution. -
Renewable Energy
Helps in managing solar or wind energy systems by collecting real-time data and controlling inverters and storage.
Product Advantages
-
Seamless Integration
This adapter provides easy integration with Modicon M1/M1E processors, enabling enhanced communication with various field devices, including I/O modules, sensors, and actuators. -
Flexible Communication
The 171CCC96030 supports multiple communication protocols such as Modbus TCP/IP, Ethernet/IP, and other proprietary protocols, making it versatile for different network environments. -
High-Speed Data Processing
It ensures efficient data exchange between networked devices, processing data at high speeds to support demanding industrial automation applications. -
Compact and Robust
The compact size makes it suitable for installation in environments where space is limited. Its robust design ensures reliable performance even in harsh industrial settings. -
Enhanced Diagnostics
It provides detailed LED indicators for diagnostics, simplifying troubleshooting and maintenance. -
Energy Efficient
Consumes low power while providing high-performance capabilities, making it an energy-efficient choice for industrial applications.
常见问题 (FAQ)
-
What is the main purpose / the Schneider 171CCC96030 Processor Adapter?
It is used to connect the Modicon M1/M1E processors to various network and I/O modules, enabling real-time communication and data exchange. -
Is the adapter compatible with all Modicon processors?
No, it is specifically designed for use with Modicon M1 and M1E controllers. -
What are the supported communication protocols?
It supports Modbus TCP/IP, Ethernet/IP, and Schneider Electric’s proprietary protocols. -
What power supply does the adapter require?
The adapter operates on a 24 V DC power supply. -
Can the 171CCC96030 be used with other brands / PLCs?
No, it is tailored for use with Modicon M1/M1E controllers from Schneider Electric. -
What is the maximum data processing rate?
The adapter supports high-speed data transfer up to 1 Gbps, depending on the configuration. -
What is the operating temperature range / the module?
It can operate within a temperature range / 0°C to 60°C. -
How is the adapter mounted?
The 171CCC96030 can be easily mounted on a DIN rail. -
Is the module IP-rated for industrial environments?
Yes, it has an IP20 rating, suitable for indoor use in typical industrial environments. -
Is the adapter energy-efficient?
Yes, the adapter is designed to consume low power while /fering high performance for automation systems.
Related 型号s (Same Series or Function)
| 型号 Number | 描述 |
|---|---|
| 171CCC96000 | Modicon M1E Processor Module |
| 171CCC96010 | Modicon M1E Communication Module |
| 171CCC96020 | M1E Ethernet Communication Interface |
| 171CCC96040 | M1/M1E I/O Processor Interface |
| 171CCC96050 | M1E I/O Network Adapter |
| 171CCC96100 | Modicon M1 Communication Processor Interface |
Popular Schneider Electric 型号s
| 型号 Number | 描述 |
|---|---|
| BMXP342020 | Modicon Premium PLC CPU Module |
| TM241CEC24T | Modicon M241 Logic Controller with Ethernet |
| BMEP580040 | Modicon M580 PAC CPU with high-speed processing |
| HMISTU855 | HMI Touchscreen Panel – 5.7” TFT, Ethernet-enabled |
| ATV630U22N4 | Altivar Process Drive, 2.2kW, 3-phase, 380–480V |
| SEPAM S20 | SEPAM Protection Relay for Electrical Distribution |
