产品介绍
The Schneider Electric 170PNT16020 is a Modbus Plus communication adapter module designed for use with the Modicon Momentum PLC platform. This module provides seamless connectivity between Modicon Momentum I/O bases and the Modbus Plus network, ensuring real-time communication and data exchange across industrial automation systems.
It supports peer-to-peer communication, deterministic data transfer, and diagnostic capabilities, making it an ideal choice for distributed control architectures. With its compact footprint, robust reliability, and easy configuration, the 170PNT16020 helps bridge the gap between field devices and centralized control systems using the proven Modbus Plus protocol.
产品规格
| Parameter | Specification |
|---|---|
| 制造商 | Schneider Electric |
| Product Series | Modicon Momentum |
| 型号 Number | 170PNT16020 |
| Communication Protocol | Modbus Plus |
| Connector Type | 9-pin D-sub connector (female) |
| Baud Rate | 1 Mbps (Modbus Plus standard) |
| Addressing Range | 1–64 nodes |
| Node Access | Peer-to-peer or master-slave |
| Status Indicators | LED indicators for module and network status |
| Isolation | Optical isolation between logic and network interface |
| Backplane Interface | Momentum I/O base connection |
| Power Consumption | 200 mA at 5 VDC |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Relative Humidity | 5% to 95% non-condensing |
| Mounting | DIN rail or panel mounting (through I/O base) |
| Certifications | CE, UL, CSA, C-Tick |
| Protection Rating | IP20 (when mounted in enclosure) |
| Compliance | RoHS, EN/IEC 61131-2 |
| Dimensions (H x W x D) | 55 ×180 × 260 mm |
| 重量 | 0.091 kg |
Product Applications
The 170PNT16020 module plays a key role in connecting automation systems with field-level devices using the Modbus Plus protocol. Its common applications include:
-
Industrial Automation Systems
Enabling communication between remote I/O, PLCs, HMIs, and SCADA systems. -
Process Control in Manufacturing Plants
Used in industries such as food processing, oil and gas, and chemical production to facilitate real-time control. -
Infrastructure Management
Integration into water treatment plants, power generation facilities, and building management systems. -
Automotive Assembly Lines
For synchronized control / robotic stations, conveyors, and safety interlocks. -
Distributed Control Systems (DCS)
Provides reliable communication for redundant architectures and remote I/O applications. -
Energy and Utilities
Ensures seamless Modbus Plus integration for smart grid and power distribution monitoring.
Product Advantages
-
Seamless Modbus Plus Integration
Simplifies communication with existing Schneider Modbus Plus networks, ensuring backward compatibility. -
Compact and Lightweight Design
Its small size allows installation in tight control panel spaces without compromising performance. -
Real-Time Performance
Enables deterministic communication, ideal for time-sensitive industrial control applications. -
Plug-and-Play Installation
Easily mounts to any Modicon Momentum I/O base without special tools or complex setup. -
Diagnostic Indicators
LED status indicators for rapid troubleshooting and network monitoring. -
Rugged Build
Designed to operate in demanding industrial environments with high imm件y to electrical noise. -
Peer-to-Peer 支持
Facilitates advanced networking capabilities between controllers without a master-slave hierarchy.
常见问题 (FAQ)
-
What is the primary function / the 170PNT16020 module?
It acts as a communication adapter that connects Modicon Momentum PLCs to Modbus Plus networks. -
Is this module compatible with non-Momentum platforms?
No, it is specifically designed for use with the Momentum I/O base and is not compatible with other platforms. -
Does the module support peer-to-peer communication?
Yes, it supports both peer-to-peer and master-slave network topologies. -
What is the maximum number / nodes supported on the network?
The Modbus Plus network supports up to 64 nodes, including the 170PNT16020. -
Can the module be hot-swapped?
No, for safety and integrity, the system should be powered down before replacing the module. -
What type / cable is used for the Modbus Plus connection?
Shielded twisted-pair cables with 9-pin D-sub connectors are recommended. -
Is it possible to monitor module status remotely?
Yes, through diagnostic s/tware or PLC programming interfaces. -
What environmental conditions can the module withstand?
It operates within a 0°C to 60°C range and can tolerate up to 95% non-condensing humidity. -
Does it require external power supply?
No, it draws power from the I/O base it’s mounted to. -
Is firmware upgradeable for this module?
Firmware upgrades are generally not required, but check with Schneider support for version updates.
Related 型号s (Same Series or Function)
| 型号 Number | 描述 |
|---|---|
| 170ENT11002 | Ethernet TCP/IP Communication Adapter for Momentum |
| 170ADM35010 | Momentum I/O Base with Integrated Power Supply |
| 170AAI52000 | 8-Channel Analog Input Module |
| 170ADO34000 | 16-Channel Digital Output Module |
| 170ANR12091 | Momentum Adapter for Remote I/O via Fiber Optic |
| 170XTS00100 | Terminal Strip for Momentum I/O Modules |
Popular 型号s from Schneider Electric (Same 品牌)
| 型号 Number | 描述 |
|---|---|
| BMXP342020 | Modicon Premium PLC CPU Module |
| TSXDEY32D2K | 32-Channel Digital Input Module |
| TM241CEC24T | Modicon M241 Logic Controller with Ethernet |
| BMEP582040 | Modicon M580 PAC CPU with 4 MB memory |
| HMISTU855 | HMI Touchscreen Panel – 5.7” TFT, Ethernet-enabled |
| ATV630U22N4 | Altivar Process Drive, 2.2kW, 3-phase, 380–480V |
