The Schneider 170BNO67100 Branch Interface is a specialized INTERBUS communication adapter designed to connect Modicon PLCs, such as the M340 series, to distributed INTERBUS networks. This module enables the integration / remote field devices, sensors, actuators, and I/O modules into a single deterministic and high-speed communication network. By providing a reliable interface between the PLC and INTERBUS, the 170BNO67100 ensures accurate data transmission, synchronized device operation, and efficient network management. It is particularly suitable for industrial environments where modular and scalable automation systems are required, /fering both flexibility and robust communication performance.
Technical Specifications
| Parameter | Details |
|---|---|
| Product Type | Branch Interface for INTERBUS |
| 型号 Number | 170BNO67100 |
| Communication Protocol | INTERBUS |
| Data Rate | Up to 500 kbps, deterministic cycle time |
| Compatible PLC | Modicon M340, M580, and other compatible 施耐德s |
| Maximum Devices per Segment | 256 devices per INTERBUS segment |
| Bus Connection Type | Two-wire bus interface with screw terminals |
| Diagnostic Capabilities | Online//fline status, bus error detection |
| Power Supply | 24 VDC from PLC rack |
| Power Consumption | Approx. 3 W |
| Isolation | Galvanic isolation between interface and PLC backplane |
| Status Indicators | LEDs for communication, error, and device activity |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -25 °C to +70 °C |
| Relative Humidity | 5% to 95% non-condensing |
| Dimensions (H × W × D) | 110 × 40 × 120 mm |
| 重量 | 0.015 kg |
| Mounting | Standard M340 rack mounting |
| Certifications | CE, UL, CSA, RoHS compliant |
Applications
The 170BNO67100 Branch Interface is widely used in industrial automation applications requiring INTERBUS communication:
-
Distributed Factory Automation: Connects remote I/O modules, sensors, and actuators to central PLCs for seamless control / production lines.
-
Process Control: Monitors and controls chemical, pharmaceutical, and food processing equipment with precise data exchange.
-
Material Handling Systems: Facilitates real-time communication with conveyors, robotics, and automated storage/retrieval systems.
-
Building and Infrastructure Automation: Integrates lighting, HVAC, and environmental controls across distributed devices.
-
Modular Machine Control: Provides reliable communication for modular machinery and equipment requiring flexible I/O placement.
Advantages
-
High-Speed Deterministic Communication: 支持s up to 500 kbps for precise, real-time control / devices.
-
Scalable Network Architecture: Accommodates up to 256 devices per segment for large distributed networks.
-
Reliable INTERBUS Integration: Fully compatible with Modicon PLCs, ensuring easy system integration.
-
Built-in Diagnostics: LED indicators and bus error detection simplify troubleshooting and network maintenance.
-
Galvanic Isolation: Protects both the PLC and connected devices from electrical interference and potential faults.
-
Compact Modular Design: Fits neatly into M340 racks, saving space and enabling flexible system expansion.
-
Flexible System Design: 支持s modular and distributed I/O setups, allowing easy network expansion without major reconfiguration.
FAQ
-
Which communication protocol does the 170BNO67100 support?
The module is designed for INTERBUS communication, enabling deterministic and high-speed data exchange between the PLC and remote I/O devices. -
How many devices can be connected per INTERBUS segment?
Up to 256 devices can be connected on a single segment, allowing large and distributed automation networks. -
What is the maximum communication speed / this branch interface?
The 170BNO67100 supports a data rate / up to 500 kbps, ensuring fast and synchronized operation / connected devices. -
Is the module electrically isolated from the PLC?
Yes, galvanic isolation is provided between the interface and the PLC backplane, protecting against voltage spikes and electrical noise. -
How can the status / the connected devices be monitored?
The module has LED indicators for communication, device activity, and error detection, allowing operators to quickly identify issues. -
Does the module provide diagnostics for bus errors?
Yes, it can detect /fline devices, communication errors, and other fault conditions, simplifying troubleshooting and maintenance. -
What power supply is required for operation?
The module requires a 24 VDC supply from the PLC rack, which powers the interface and ensures reliable operation. -
Can it integrate with both Modicon M340 and M580 PLCs?
Yes, the branch interface is compatible with both M340 and M580 PLCs, allowing flexible deployment in different automation systems. -
How is the module physically connected to the INTERBUS network?
Connection is achieved via a two-wire bus interface with screw terminals, providing secure and stable communication with field devices. -
Is this module suitable for modular machine and distributed I/O applications?
Yes, its modular design allows easy addition / remote I/O modules, supporting scalable, flexible, and distributed automation systems.
Related 型号s (Same Series/Family)
| 型号 Number | 描述 | Key Feature |
|---|---|---|
| 170BNO67101 | Branch Interface with enhanced diagnostics | Advanced device monitoring |
| 170BNO67200 | High-speed INTERBUS Branch Interface | Faster communication cycle time |
| 170BNO67300 | Multi-segment Branch Interface | Connects multiple INTERBUS segments |
| 170BNO67400 | Redundant Branch Interface | 支持s network redundancy |
| 170BNO67500 | Fiber-optic Branch Interface | Long-distance communication |
| 170BNO67600 | Advanced INTERBUS Interface | Extended protocol features |
Popular Schneider 型号s
| 型号 Number | 描述 | Application Focus |
|---|---|---|
| 140CPU67360 | Modicon M340 Processor | High-performance PLC core |
| 140DDI35300 | 32-Point Discrete Input Module | Digital input expansion |
| 140DDO36400 | 32-Point Discrete Output Module | Digital output expansion |
| 140ACI04000 | Analog Current Input Module | Precision analog signal acquisition |
| 140DAO84000 | Analog Output Module | Accurate analog output for process control |
| 140NOE77111 | Quantum Ethernet Communication Module | Advanced network integration |
