Schneider Electric 140AII33000C Product Overview
The Schneider Electric 140AII33000C is a high-performance Analog Input Module from the Modicon Quantum series. Designed for industrial automation and control systems, this module provides precise analog signal acquisition, making it ideal for applications requiring accurate data monitoring and processing. It is widely used in industries such as manufacturing, energy, and water treatment.
Product Parameters
| Parameter | Specification |
|---|---|
| 型号 Number | 140AII33000C |
| Product Type | Analog Input Module |
| Input Channels | 16 single-ended / 8 differential |
| Input Signal Range | 0-10V, ±10V, 0-20mA, 4-20mA |
| Resolution | 12-bit |
| Accuracy | ±0.1% / full scale |
| Isolation Voltage | 1500V DC |
| Communication | Modbus, TCP/IP (via Quantum PLC) |
| Operating Voltage | 24V DC (±10%) |
| Power Consumption | 5W (typical) |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95% (non-condensing) |
| Dimensions | 50 x 165 x 310 mm |
| 重量 | 0.8 kg |
| Certifications | CE, UL, IEC |
Product Applications
The 140AII33000C is widely used in industrial automation and control systems, including:
-
Process Control: Monitoring temperature, pressure, flow, and level in chemical and oil & gas industries.
-
Manufacturing: Real-time data acquisition for production line automation.
-
Energy Management: Power monitoring in electrical substations and renewable energy systems.
-
Water & Wastewater Treatment: Measuring pH, turbidity, and chemical dosing.
-
HVAC Systems: Monitoring environmental parameters in large-scale heating and cooling systems.
Product Advantages
-
High Precision: 12-bit resolution ensures accurate signal measurement.
-
Versatile Input Ranges: 支持s voltage (0-10V, ±10V) and current (0-20mA, 4-20mA) signals.
-
Robust Isolation: 1500V DC isolation protects against electrical noise and surges.
-
Wide Operating Temperature: Reliable performance in harsh environments (-20°C to +70°C).
-
Modular Design: Easy integration with Modicon Quantum PLC systems.
-
Certified Compliance: Meets CE, UL, and IEC standards for safety and reliability.
常见问题 (FAQ)
-
What is the input signal range / the 140AII33000C?
-
It supports 0-10V, ±10V, 0-20mA, and 4-20mA signals.
-
-
How many channels does this module have?
-
16 single-ended or 8 differential channels.
-
-
What is the resolution / the analog input?
-
12-bit resolution for precise measurement.
-
-
Is the module compatible with Modbus communication?
-
Yes, it supports Modbus and TCP/IP via Quantum PLC.
-
-
What is the isolation voltage rating?
-
1500V DC isolation for noise imm件y.
-
-
Can it operate in high-temperature environments?
-
Yes, it operates in temperatures from -20°C to +70°C.
-
-
What are the dimensions and weight / the module?
-
Dimensions: 120mm x 70mm x 40mm; 重量: 0.5 kg.
-
-
Does it support 4-20mA current loops?
-
Yes, it supports both 0-20mA and 4-20mA inputs.
-
-
What certifications does this product have?
-
CE, UL, and IEC certifications.
-
-
Can this module be used in hazardous areas?
-
No, it is not rated for hazardous locations unless used with additional protective enclosures.
-
