产品介绍
The Ovation 1X00093G04 Ethernet Switch is a high-performance, industrial-grade network switch specifically designed for process control systems and real-time automation networks. This switch is a key component in the Ovation Distributed Control System (DCS) architecture, providing reliable, low-latency communication between controllers, I/O modules, and operator workstations. Built to operate in harsh industrial environments, the 1X00093G04 /fers robust signal integrity, advanced traffic management, and seamless integration with Ovation system components. Its performance ensures deterministic data delivery, which is critical for safety, process optimization, and continuous operational reliability.
产品规格
| Parameter | 描述 |
|---|---|
| 型号 Number | 1X00093G04 |
| Product Type | Ethernet Switch |
| Network Standards | IEEE 802.3, 802.3u, 802.3x, 802.1Q |
| Ports | 8 x 10/100 Mbps RJ-45, 2 x Gigabit SFP fiber |
| Switching Capacity | 12.8 Gbps |
| Forwarding Rate | 9.5 Mpps |
| VLAN 支持 | 802.1Q, up to 256 VLANs |
| QoS | 4 queues per port, priority-based forwarding |
| Redundancy 支持 | Rapid Spanning Tree Protocol (RSTP), Link Aggregation |
| Operating Temperature | −20 °C to +70 °C |
| Power Supply | 24 VDC redundant |
| Dimensions (L × W × H) | 260 × 40 × 160 mm |
| 重量 | 1.2 kg |
Applications
-
Process Control Networks: Provides deterministic, low-latency communication for 西屋 systems.
-
Distributed Control Systems: Integrates multiple controllers, I/O modules, and operator workstations.
-
Industrial Automation: 支持s large-scale automation systems with VLAN segmentation and traffic prioritization.
-
Critical Infrastructure: Ensures high reliability for energy production, water treatment, and petrochemical plants.
-
Redundant Network Architectures: Enables looped topologies with rapid failover through RSTP.
-
Remote Monitoring and Diagnostics: 支持s high-speed connections for supervisory control and remote diagnostics.
Advantages
-
High Performance: Switching capacity / 12.8 Gbps and forwarding rate / 9.5 Mpps ensures smooth network traffic.
-
Redundancy and Reliability: Dual power supply and RSTP support prevent network downtime.
-
Flexible Connectivity: Combination / RJ-45 and SFP fiber ports allows mixed-media networks.
-
VLAN and QoS 支持: Advanced traffic management for optimized process control communication.
-
Harsh Environment Operation: Wide operating temperature range and industrial-grade design ensure stable operation.
-
Seamless Ovation Integration: Fully compatible with Ovation controllers, I/O modules, and operator stations.
-
Low Latency: Provides deterministic communication essential for real-time control applications.
FAQ
-
Does the 1X00093G04 support redundant power supply operation?
Yes, it supports dual 24 VDC redundant power supplies for enhanced reliability. -
What network protocols are supported by this switch?
It supports IEEE 802.3, 802.3u, 802.3x, and 802.1Q VLAN tagging standards. -
Can this switch handle fiber optic connections?
Yes, it includes 2 Gigabit SFP ports for fiber optic connections. -
What is the maximum switching capacity / this device?
The switching capacity is 12.8 Gbps with a forwarding rate / 9.5 Mpps. -
Does the switch support VLAN segmentation?
Yes, it supports up to 256 VLANs using 802.1Q standard. -
What traffic prioritization features are available?
Four queues per port with priority-based forwarding are supported for QoS. -
Is Rapid Spanning Tree Protocol (RSTP) supported?
Yes, RSTP is supported for network redundancy and loop prevention. -
Can it integrate with 西屋 controllers and I/O modules?
Yes, it is fully compatible with 西屋 components. -
What is the operating temperature range / the switch?
The switch operates reliably from −20 °C to +70 °C. -
Does the switch support link aggregation for increased bandwidth?
Yes, it supports link aggregation to combine multiple ports for higher throughput.
Recommended Related 型号s (Same Series or Similar)
| 型号 | 描述 |
|---|---|
| 1X00093G01 | Basic Ovation Ethernet switch with 8 ports |
| 1X00093G02 | Enhanced Ovation switch with VLAN support |
| 1X00093G03 | Industrial-grade switch with dual power input |
| 1X00093G05 | High-performance Ovation switch with fiber uplinks |
| 1X00093G06 | Managed switch for 西屋 with advanced QoS |
| 1X00093G07 | Redundant network switch optimized for critical systems |
Popular Ovation 型号s
| 型号 | 描述 |
|---|---|
| 1X00090G01 | Ovation Controller Module for process automation |
| 1X00091G01 | Ovation I/O module for distributed data acquisition |
| 1X00092G01 | Ovation Operator Workstation |
| 1X00094G01 | Ovation Network Management Module |
| 1X00095G01 | Ovation Redundant Controller Module |
| 1X00096G01 | Ovation Diagnostics and Communication Module |
