Product Overview
The Honeywell TC-ODK161 is a 16-channel isolated AC digital output module designed for use within the Experion LS control system. It provides reliable switching / 120/220 VAC loads and ensures electrical isolation between channels and the system bus, enhancing protection and signal integrity in industrial control environments.
Technical Specifications
| Parameter | Specification |
|---|---|
| 型号 Number | TC-ODK161 |
| Output Type | AC Digital Output |
| Number / Channels | 16 isolated channels |
| Voltage Rating | 120/220 VAC |
| Output Current per Channel | Up to 2 A per channel |
| Isolation | Channel-to-channel and channel-to-bus |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95% non-condensing |
| Mounting | DIN rail or chassis |
| Dimensions (W×H×D) | 100 × 120 × 30 mm |
| 重量 | 0.25 kg |
Applications
-
Distributed process control systems
-
Batch processing and sequential control
-
On//f control / AC solenoids, relays, and actuators
-
Factory automation and building management systems
-
Motor starters and industrial lighting control
Product Advantages
-
Channel Isolation: Each output is electrically isolated, reducing fault propagation.
-
High Voltage Tolerance: 支持s both 120 VAC and 220 VAC applications.
-
Compact Design: 保存s space in control cabinets.
-
Reliable Switching: Optimized for long operational life in harsh industrial environments.
-
Experion LS Compatibility: Seamless integration into Honeywell’s Experion LS system.
常见问题 (FAQ)
Q1: What types / loads can the TC-ODK161 drive?
A1: It can drive resistive and inductive AC loads such as solenoids, contactors, and indicators.
Q2: Are the outputs isolated?
A2: Yes, all 16 outputs are individually isolated from each other and the system bus.
Q3: Is the module compatible with 220 VAC systems?
A3: Yes, it supports both 120 VAC and 220 VAC operation.
Q4: Can the module be mounted on a DIN rail?
A4: Yes, it supports DIN rail as well as chassis mounting.
Q5: What is the maximum current per channel?
A5: Each output can deliver up to 2 amps.
Q6: Does this module support diagnostics?
A6: No, the TC-ODK161 does not include diagnostic feedback channels.
Q7: Can the module operate in high humidity environments?
A7: Yes, it supports up to 95% non-condensing humidity.
Q8: What control systems is it designed for?
A8: It is designed for use in Honeywell’s Experion LS control platform.
Q9: Are there any coated versions available?
A9: Yes, the TK-ODK161 is the conformally coated variant for harsh environments.
Q10: What is the physical size / the module?
A10: It measures 100 × 120 × 30 mm and weighs 0.25 kg.
Related or Same Series 型号s
| 型号 | 描述 | Channels | Voltage | Dimensions (mm) | 重量 |
|---|---|---|---|---|---|
| TC-ODA161 | AC Output Module | 16 | 120/220 VAC | 100×120×30 | 0.25 kg |
| TC-ODD161 | DC Output Module (E-Fused) | 16 | 24 VDC | 100×120×30 | 0.25 kg |
| TC-ODX081 | AC Output Diagnostic Module | 8 | 120 VAC | 100×120×30 | 0.25 kg |
| TC-ODD321 | DC Output Module | 32 | 24 VDC | 100×120×30 | 0.25 kg |
| TC-OAV081 | Analog Output Module (Non-Isolated) | 8 | 4-20mA / 10V | 100×120×30 | 0.25 kg |
| TC-OAH061 | Analog Output Module | 6 | 4-20mA | 100×120×30 | 0.25 kg |
Popular Honeywell 型号s
| 型号 | 描述 | Type | Dimensions (mm) | 重量 |
|---|---|---|---|---|
| 8C-PCNT02 | C300 Controller Series 8 | Controller | 190×250×50 | 0.60 kg |
| 8C-PAOHA1 | AO Module with HART | Analog Output | 120×130×30 | 0.30 kg |
| 8C-PDILA1 | Digital Input Module | Digital Input | 120×130×30 | 0.30 kg |
| 8C-PDODA1 | Digital Output Module | Digital Output | 120×130×30 | 0.30 kg |
| 900SP1-0300 | HC900 Expansion CPU | Processor | 150×100×40 | 0.40 kg |
| FC-IO-0001 | I/O Expansion Module | I/O Module | 100×120×30 | 0.25 kg |
