Product Overview
The Honeywell MU-TPIX12 51304084-125 Pulse Input Field Termination Assembly is a high-performance industrial interface solution, designed to reliably terminate and transmit pulse input signals from field instruments to Honeywell control and safety systems. As part / Honeywell’s advanced field termination series, the MU-TPIX12 51304084-125 ensures precise, high-frequency signal handling with maximum reliability, making it ideal for demanding industrial environments where real-time data and system integrity are paramount.
This assembly is suitable for a wide range / pulse-generating devices such as flow meters, turbine meters, and tachometers. The 件 enhances system diagnostics, signal protection, and overall operational performance while providing a compact, user-friendly installation process.
Key Features
-
Dedicated field termination assembly for pulse inputs.
-
12 isolated input channels for high-density signal termination.
-
支持s high-frequency pulse signals up to 20 kHz.
-
Wide input voltage range for compatibility with diverse field devices.
-
Galvanic isolation between channels and ground to enhance safety.
-
Seamless integration with Honeywell Experion PKS and Safety Manager systems.
-
Robust industrial-grade construction for harsh environments.
-
Secure screw terminal connections for reliable field wiring.
-
Compact footprint for space-efficient installation.
-
Long lifecycle with minimal maintenance requirements.
-
High imm件y to electrical noise and external interference.
Technical Specifications
| Parameter | 描述 |
|---|---|
| 型号 | MU-TPIX12 |
| 零件号 | 51304084-125 |
| Signal Type | Pulse Input |
| Input Channels | 12 Channels |
| 支持ed Frequency Range | Up to 20 kHz |
| Input Voltage Range | 5 VDC to 24 VDC |
| Isolation | Channel-to-channel and channel-to-ground |
| Power Supply | 24 VDC Nominal |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% Non-condensing |
| Terminal Type | Screw Terminal |
| Dimensions | 100 × 150 × 30 mm |
| 重量 | 0.5 kg |
| System Compatibility | Honeywell Experion PKS, Safety Manager |
| Certification | CE, UL, FM Approved |
Industry Applications
-
Oil & Gas: For accurate pulse acquisition from flow meters and speed sensors in pipelines, refineries, and storage facilities.
-
Chemical Industry: Provides reliable pulse signal input for precise flow monitoring and rotating machinery control.
-
Power Generation: Suitable for turbine speed detection, motor monitoring, and pulse-based instrumentation.
-
Water & Wastewater: Integrates with dosing and flow measurement systems for process optimization.
-
Pharmaceuticals: 支持s batching, flow verification, and dispensing processes requiring high signal accuracy.
-
Food & Beverage: Ensures consistent, accurate data acquisition from pulse-driven metering devices on production lines.
Product Advantages
-
High Signal Integrity: Guarantees accurate pulse signal processing, enhancing system control and measurement precision.
-
Industrial Durability: Built to withstand vibration, temperature fluctuations, and electrical disturbances common in industrial settings.
-
System Compatibility: Designed for seamless integration with Honeywell’s safety and control platforms.
-
Electrical Isolation: Galvanic isolation minimizes signal interference and protects connected equipment.
-
Space-Efficient Design: Compact form factor ideal for crowded control cabinets.
-
Minimal Maintenance: Durable construction reduces operational downtime and servicing needs.
-
Versatile Application: Compatible with various pulse signal sources across multiple industries.
-
Improved Operational Reliability: Ensures stable, uninterrupted signal transmission critical for process safety and efficiency.
常见问题 (FAQ)
-
What is the function / MU-TPIX12 51304084-125?
It acts as a pulse input field termination assembly, reliably transmitting pulse signals to Honeywell control systems. -
Which systems are compatible with this model?
The assembly is compatible with Honeywell Experion PKS and Safety Manager systems. -
What is the supported pulse frequency range?
It supports pulse signals up to 20 kHz for high-speed applications. -
Does this assembly provide channel isolation?
Yes, galvanic isolation is provided between input channels and ground for safety and signal integrity. -
What field devices can connect to it?
Compatible with flow meters, turbine meters, tachometers, and other pulse-generating instruments. -
Can it operate in harsh conditions?
Yes, with an operating temperature range / -20°C to +60°C and up to 95% relative humidity tolerance. -
How is the wiring connected?
Secure screw terminals allow for straightforward and reliable field wiring. -
Is frequent maintenance required?
No, the 件 is designed for long-term, low-maintenance operation. -
What certifications does it carry?
It is CE, UL, and FM certified, ensuring compliance with industrial safety standards. -
Can the assembly be replaced without system shutdown?
Typically, it can be replaced during scheduled maintenance with minimal process interruption.
Related 型号s
| 型号 | 描述 |
|---|---|
| MU-TDID72 51303928-100 | Digital Input Field Termination Assembly |
| MU-TDOD32 51303929-100 | Digital Output Field Termination Assembly |
| MU-TLPA02 51304084-200 | Loop Power Adapter Field Termination Assembly |
| MU-TPIX03 51304485-100 | 3-Channel Pulse Input Field Termination Assembly |
| MU-TSRI02 51303932-100 | Relay Output Field Termination Assembly |
| MU-TSTX13 51304485-200 | Pulse Signal 状态ing Module |
Popular Honeywell 型号s
| 型号 | 描述 |
|---|---|
| FC-PDIO01 51454927-176 | Safety Digital I/O Module |
| FC-PSU-240516 136-011194D | Power Supply 单位 |
| FC-QPP-0001 | Quad Processor Cluster Module |
| FS-TSGAS-1624 | Safety Fire Detector Input FTA |
| TK-IOLI01 51403427-175 | Experion LS I/O Link Interface Module |
| FS-USI-0001 | Universal Safety Interface Module |
