Product Overview
The Honeywell MU-TPIX12 51304084-100 Pulse Input Field Termination Assembly is an industrial-grade component designed to interface pulse signals from field devices to Honeywell’s process control and safety systems. It ensures high-integrity signal transmission for accurate, real-time data acquisition essential to critical industrial operations.
This assembly efficiently collects pulse inputs from devices such as flow meters, speed sensors, or tachometers. Its reliable design enhances system performance, signal protection, and simplifies installation within Honeywell’s Experion PKS and Safety Manager platforms.
Key Features
-
Dedicated termination assembly for pulse signal inputs.
-
支持s high-speed pulse signal acquisition up to 20 kHz.
-
Galvanic isolation for signal and equipment protection.
-
Optimized for seamless integration with Honeywell control systems.
-
Robust, durable design suitable for demanding environments.
-
Compact form factor for efficient use / panel space.
-
Reliable screw terminals for secure field wiring.
-
Low-maintenance with extended operational life.
-
High noise imm件y ensuring signal integrity.
-
Suitable for diverse pulse signal applications across industries.
Technical Specifications
| Parameter | 描述 |
|---|---|
| 型号 | MU-TPIX12 |
| 零件号 | 51304084-100 |
| Signal Type | Pulse Input |
| Input Channels | 12 Channels |
| 支持ed Frequency Range | Up to 20 kHz |
| Input Voltage Range | 5 VDC to 24 VDC |
| Isolation | Channel-to-channel and channel-to-ground |
| Power Supply | 24 VDC Nominal |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% Non-condensing |
| Terminal Type | Screw Terminal |
| Dimensions | 100 × 150 × 30 mm |
| 重量 | 0.5 kg |
| System Compatibility | Honeywell Experion PKS, Safety Manager |
| Certification | CE, UL, FM Approved |
Industry Applications
-
Oil & Gas: Interfaces with flow meters and speed sensors in pipelines and processing facilities.
-
Chemical Processing: Pulse input acquisition for precise flow measurement and rotating equipment monitoring.
-
Power Generation: Pulse signal reception from turbines, motors, and speed monitoring devices.
-
Water & Wastewater: Integration with flow and dosing equipment for accurate process control.
-
Pharmaceutical Production: 支持s batching, dispensing, and flow verification systems.
-
Food & Beverage: Enables real-time pulse signal collection from production line measurement devices.
Product Advantages
-
Accurate Signal Acquisition: Provides reliable pulse input processing for improved measurement and control.
-
Durable Industrial Design: Engineered to withstand harsh environments with high durability.
-
Seamless System Integration: Fully compatible with 霍尼韦尔 and SIS platforms.
-
Enhanced Electrical Isolation: Galvanic isolation safeguards equipment and personnel.
-
Compact, Space-Saving Assembly: Easy installation even within constrained control cabinets.
-
Minimal Maintenance: Long lifecycle and robust construction reduce service requirements.
-
Broad Application Flexibility: Accommodates a wide variety / pulse-generating devices.
-
Improved System Reliability: Ensures uninterrupted signal transmission critical to operations.
常见问题 (FAQ)
-
What does the MU-TPIX12 51304084-100 do?
It functions as a pulse input field termination assembly, transmitting pulse signals from field devices to control systems. -
Which Honeywell systems work with MU-TPIX12?
It integrates with Honeywell Experion PKS and Safety Manager systems. -
What pulse frequency range does it support?
It can handle pulse signals up to 20 kHz. -
Is there channel isolation?
Yes, it features channel-to-channel and channel-to-ground galvanic isolation. -
What type / field devices connect to it?
Compatible with pulse-generating devices such as flow meters, speed sensors, and tachometers. -
Can it withstand harsh environments?
Yes, it operates reliably between -20°C to +60°C and up to 95% humidity. -
Is installation complicated?
No, its compact design and screw terminals allow straightforward installation. -
Does it require regular maintenance?
Minimal maintenance is needed due to its robust, durable construction. -
Are there certifications?
Yes, it is CE, UL, and FM certified for industrial use. -
Can it be replaced without significant downtime?
Yes, it can be replaced during scheduled maintenance with minimal operational disruption.
Related 型号s
| 型号 | 描述 |
|---|---|
| MU-TDID72 51303928-100 | Digital Input Field Termination Assembly |
| MU-TDOD32 51303929-100 | Digital Output Field Termination Assembly |
| MU-TLPA02 51304084-200 | Loop Power Adapter Field Termination Assembly |
| MU-TPIX03 51304485-100 | 3-Channel Pulse Input Field Termination Assembly |
| MU-TSRI02 51303932-100 | Relay Output Field Termination Assembly |
| MU-TSTX13 51304485-200 | Pulse Signal 状态ing Module |
Popular Honeywell 型号s
| 型号 | 描述 |
|---|---|
| FC-PDIO01 51454927-176 | Safety Digital I/O Module |
| FC-PSU-240516 136-011194D | Power Supply 单位 |
| FC-QPP-0001 | Quad Processor Cluster Module |
| FS-TSGAS-1624 | Safety Fire Detector Input FTA |
| TK-IOLI01 51403427-175 | Experion LS I/O Link Interface Module |
| FS-USI-0001 | Universal Safety Interface Module |
