产品介绍
The Honeywell DC-TDOD51 51307611-176 Digital Output Module is a high-performance, isolated digital output (DO) module, purpose-built for use in Honeywell Experion PKS, C300 Controllers, and Series C I/O environments. It /fers 16 channels / isolated, high-reliability digital output for controlling a wide variety / field devices such as motor starters, solenoids, interposing relays, alarm annunciators, lighting circuits, and safety interlocks.
Each / the 16 channels is individually isolated, ensuring maximum protection against electrical transients and cross-talk. The module provides fast switching performance, extensive channel diagnostics, and LED indication to ensure high availability and easy maintenance — all vital in demanding process industries where uptime, reliability, and safety are critical.
Widely deployed across industries such as oil & gas, chemicals, power generation, water treatment, mining, pulp & paper, and life sciences, the DC-TDOD51 enables Honeywell control systems to deliver precise and robust on//f control in even the harshest operating environments.
产品规格
| Parameter | Specification |
|---|---|
| Product Name | Honeywell DC-TDOD51 Digital Output Module |
| 零件号 | 51307611-176 |
| System Compatibility | Honeywell Experion PKS / C300 Controllers / Series C I/O |
| Output Type | Digital DC (Isolated Sourcing, Positive Logic) |
| Number / Output Channels | 16 channels (individually isolated) |
| Output Voltage Range | 18–30 VDC (nominal 24 VDC) |
| Maximum Output Current (per channel) | 0.5 A (continuous) |
| Total Module Output Current | 8 A maximum (total for all channels) |
| Switching Time (ON/OFF) | < 1 ms |
| Isolation | Channel-to-channel and logic-to-field isolation |
| Diagnostics | Advanced per-channel fault detection and reporting |
| Status Indication | LED per channel (ON/OFF/fault) |
| Communication Interface | FTE (Fault-Tolerant Ethernet), ControlNet |
| 支持ed Power Supply | 24 VDC (redundant supported) |
| Operating Temperature Range | -20°C to +60°C (-4°F to +140°F) |
| Storage Temperature Range | -40°C to +85°C (-40°F to +185°F) |
| Relative Humidity | 5% to 95% RH (non-condensing) |
| Shock/Vibration Resistance | IEC 60068 compliant |
| Dimensions (H x W x D) | 115 x 85 x 40 mm |
| 重量 | 0.25 kg |
| Mounting Method | DIN rail or panel mount |
| Flame Rating | UL 94V-0 |
| Certifications | CE, UL, CSA, ATEX Zone 2, IECEx |
Applications
-
Digital control / solenoid valves, interposing relays, motor contactors, audible alarms, lighted annunciators
-
Activation / safety interlocks and emergency shutdown circuits
-
Batch automation in chemical and pharmaceutical industries
-
Process and utility equipment control in oil & gas upstream, midstream, refining
-
Power plant process control — steam turbines, generators, and auxiliaries
-
Water and wastewater treatment facility automation
-
Continuous and batch control in food & beverage plants
-
Mining and minerals processing equipment control
-
Building automation and emergency management systems
-
Pulp & paper mills automation and drive control
Product Advantages
-
High Isolation: Each output channel is individually isolated to prevent cross-channel interference and protect against voltage spikes
-
Fast Switching: < 1 ms switching performance supports time-critical processes
-
Advanced Diagnostics: Provides detailed per-channel diagnostics for predictive maintenance and fault detection
-
Compact, High Density: 16 isolated outputs in a compact module save space and panel wiring
-
Visual Status Indication: LED per channel enables fast visual verification / channel status
-
Certified for Harsh Environments: ATEX Zone 2, IECEx certified for hazardous areas
-
Flexible Mounting: DIN rail or panel mount supports easy installation and retr/it upgrades
-
支持s Redundant Power: Ensures high availability and system reliability
-
Designed for Process Industries: Meets stringent environmental, vibration, and EMC requirements for industrial applications
-
Fully 支持ed by Honeywell Lifecycle Programs: Ensures long-term serviceability and upgrade paths
常见问题 (FAQ)
-
What is the primary function / the DC-TDOD51 module?
The DC-TDOD51 provides 16 isolated digital DC outputs for controlling field devices in process automation systems. -
Which control systems is this module compatible with?
It is fully compatible with Experion PKS, C300 Controllers, and Series C I/O. -
How fast does the module switch outputs?
It /fers ON/OFF switching in less than 1 millisecond. -
What is the isolation type on this module?
Each channel is individually isolated with additional logic-to-field isolation. -
What type / field devices can this module control?
It is suitable for solenoids, relays, contactors, alarms, lighting circuits, and interlocks. -
What is the output voltage range?
The module operates between 18–30 VDC, with 24 VDC nominal. -
What is the current capacity per channel?
Each channel can continuously supply 0.5 A / current. -
Does this module support diagnostics?
Yes — it /fers per-channel diagnostics and visual LED status. -
Is it suitable for hazardous areas?
Yes — certified for ATEX Zone 2 and IECEx environments. -
Is redundant power supported?
Yes — the module supports redundant 24 VDC power supply inputs.
