Product Overview
The Honeywell CC-PAOH51 51410070-275 is a high-performance HART Analog Output Module designed for seamless integration into industrial control systems. It facilitates precise conversion / digital signals to analog outputs, enabling accurate control / various field devices such as actuators, valves, and other instrumentation.
This module is an integral component / Honeywell’s Experion® Process Knowledge System (PKS) and the C300 controller family, ensuring reliable and efficient process automation across diverse industrial applications.
产品规格
| Parameter | Details |
|---|---|
| 制造商 | Honeywell |
| 零件号 | CC-PAOH51 |
| Catalog Number | 51410070-275 |
| Module Type | HART Analog Output Module |
| Output Channels | 16 |
| Output Signal Range | 4-20 mA, 0-20 mA, 0-10 V (user configurable) |
| HART Protocol 支持 | Yes |
| Accuracy | ±0.1% / full scale |
| Resolution | 16-bit |
| Isolation | Channel-to-channel: 500V; Channel-to-system: 1500V |
| Response Time | <20 ms |
| Output Ripple | <100 mV peak-to-peak at power line frequency, across 250 Ω load |
| Output Temperature Drift | 0.005% / Full Scale/°C |
| Output Readback Accuracy | ±4% / Full Scale |
| Output Current Linearity | ±0.05% / Full Scale nominal |
| Calibrated Accuracy | ±0.35% / Full Scale (25°C) including linearity |
| Directly Settable Output Current Range | 0 mA, 2.9 mA to 21.1 mA |
| Maximum Resistive Load | 800 ohms (with 24 V supply) |
| Power Supply | 24 VDC (18-30 VDC) |
| Power Consumption | 4W max |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% non-condensing |
| Dimensions (H × W × D) | 63.5 x 124.46 x 307.34 mm |
| 重量 | 0.299 kg |
| Mounting | DIN rail or Honeywell Series C rack mounting |
| Certifications | CE, TUV, UL508, CSA |
Applications
The Honeywell CC-PAOH51 Analog Output Module is designed for a wide range / industrial applications requiring precise analog signal output and HART communication capabilities. Common applications include:
-
Process Control Systems: Regulating actuators, valves, and other control elements in industries such as oil and gas, chemical processing, and power generation.
-
Manufacturing Automation: Providing accurate control signals to machinery and production equipment.
-
Environmental Monitoring: Controlling devices in systems that monitor environmental parameters.
-
Utilities and Energy Management: Managing equipment in water treatment plants, electrical grids, and renewable energy installations.
-
Pharmaceutical Production: Ensuring precise control in sensitive manufacturing processes.
-
Food and Beverage Industry: Maintaining consistent quality through accurate process control.
Product Advantages
-
High Precision and Accuracy: Offers ±0.1% full-scale accuracy and 16-bit resolution for precise control.
-
HART Protocol 支持: Enables enhanced communication with field devices, allowing for diagnostics and configuration over the same wiring.
-
Multiple Output Ranges: Configurable for 4-20 mA, 0-20 mA, and 0-10 V signals to accommodate various devices.
-
Robust Isolation: Provides 500V channel-to-channel and 1500V channel-to-system isolation, ensuring signal integrity and safety.
-
Fast Response Time: Less than 20 ms response time for timely control actions.
-
Wide Operating Temperature Range: Suitable for extreme environments, operating reliably from -40°C to +70°C.
-
Compact and Modular Design: Facilitates easy integration into existing systems with minimal space requirements.
-
Low Power Consumption: Efficient operation with a maximum power consumption / 4W, reducing overall energy costs.
-
Reliable Performance: Designed for high availability and durability in industrial settings.
-
Seamless Integration: Fully compatible with Honeywell’s Experion® PKS and C300 controller systems, ensuring smooth system integration.
Recent News Headlines Featuring CC-PAOH51 or Related Honeywell Automation 产品
-
Honeywell Enhances Process Control with Advanced HART Analog Output Modules – Automation Today, March 2025
-
Case Study: Optimizing Chemical Plant Operations Using Honeywell CC-PAOH51 Modules – Industrial Automation News, February 2025
-
Honeywell’s Commitment to Precision: The Role / CC-PAOH51 in Modern Manufacturing – Control Engineering Review, January 2025
-
Integrating HART Protocol in Process Automation: Insights from Honeywell’s CC-PAOH51 Module – Process Control Weekly, December 2024
-
Energy Sector Adopts Honeywell’s CC-PAOH51 for Enhanced Control Capabilities – Energy Automation Journal, November 2024
-
Honeywell Introduces New Features in Series C Analog Output Modules – Industrial Tech Update, October 2024
-
Automation Evolution: Leveraging HART Communication with Honeywell’s CC-PAOH51 – Automation World, September 2024
-
Ensuring Signal Integrity in Harsh Environments: The Honeywell CC-PAOH51 Advantage – Control Systems Magazine, August 2024
-
Pharmaceutical Industry Benefits from High-Precision Analog Outputs with Honeywell Modules – PharmaTech News, July 2024
-
Honeywell’s CC-PAOH51: A Game-Changer in Process Automation – Manufacturing Insights, June 2024
FAQ
-
Q: What type / analog output signals does the CC-PAOH51 support?
A: The CC-PAOH51 supports standard output signal ranges including 4–20 mA, 0–20 mA, and 0–10 V, which can be configured based on system requirements. -
Q: Can the CC-PAOH51 module communicate using the HART protocol?
A: Yes, it fully supports HART communication, allowing two-way digital communication over the analog signal for device diagnostics and configuration. -
Q: How many output channels are available on the CC-PAOH51 module?
A: It provides 16 isolated analog output channels, each independently configurable. -
Q: Is the module hot-swappable? Can I replace it without shutting down the system?
A: Yes, the module is designed to be hot-swappable within Honeywell’s C300 controller platform, minimizing downtime during maintenance. -
Q: What type / isolation does the module provide?
A: The module /fers channel-to-channel isolation / 500 V and channel-to-system isolation / 1500 V, ensuring electrical safety and signal integrity. -
Q: What kind / accuracy and resolution can I expect?
A: It delivers a high-resolution 16-bit output with a calibrated accuracy / ±0.35% / full scale at 25°C. -
Q: What is the maximum load the analog outputs can drive?
A: Each channel can drive up to 800 ohms resistive load when supplied with 24 VDC. -
Q: What kind / environmental conditions can the CC-PAOH51 withstand?
A: It operates reliably in harsh industrial environments, withstanding temperatures from -40°C to +70°C and humidity up to 95% non-condensing. -
Q: How is the module mounted in the system?
A: It is typically mounted in Honeywell’s Series C racks or can be DIN rail mounted, /fering flexible installation options. -
Q: Is this module suitable for safety-critical or SIL-rated systems?
A: While it is designed for high reliability in industrial control systems, its usage in SIL-rated systems should be confirmed with Honeywell’s safety documentation.
Related 型号s – Same Series or Analog I/O Modules
| 型号 Number | 描述 |
|---|---|
| CC-PAIH01 | Analog Input Module, HART-enabled |
| CC-PDIL01 | Digital Input Module, 24 VDC |
| CC-PDOB01 | Digital Output Module, 24 VDC |
| CC-PAIN01 | Non-HART Analog Input Module |
| CC-PDOR01 | Relay Output Module |
| CC-PUIO01 | Universal I/O Module (Analog + Digital) |
| CC-TDIL01 | Redundant Digital Input Module |
| CC-TAOX01 | Thermocouple Analog Output Module |
Popular Honeywell 型号s – 其他 Categories
| 型号 Number | 描述 |
|---|---|
| 51401491-100 | Field Termination Assembly (FTA) |
| 51204172-175 | MC-PAOY22 Analog Output Module |
| 51304485-150 | C300 Controller Processor Module |
| 51403870-275 | MC-TAIH14 Analog Input Module |
| 51304493-100 | PMIO Power Management Module |
| 51402573-150 | FC-TPSU-2430 Power Supply Module |
| 51202329-112 | IOTA Mounting Base |
| 51400997-100 | Digital Input/Output Assembly |
