产品介绍:
The HIMA Z7138/3331/C5/P2 Cable Plug is a precision industrial connector developed for safety-critical control systems. Designed for use in environments requiring robust, reliable, and interference-free connections, this 5-pole plug is a key component for wiring HIMA’s HIMax and HIMatrix safety PLC systems.
Equipped with P2 coding to prevent misconnection, and crafted with a rugged metallic housing and full EMC shielding, the Z7138/3331/C5/P2 provides secure signal and low-voltage power transmission even under harsh industrial conditions. Its compact form factor and mechanical locking mechanism make it ideal for modular automation panels, where durability, secure contact, and fast maintenance are essential.
产品规格:
| Parameter | Details |
|---|---|
| 型号 | Z7138/3331/C5/P2 |
| 制造商 | HIMA |
| Connector Type | Industrial cable plug, multipole, coded |
| Number / 联系我们s | 5 |
| Keying / Coding | P2 (prevents mis-mating with other plug types) |
| 联系我们 Type | Screw terminal or crimp version available |
| Rated Current | Up to 10 A per contact |
| Rated Voltage | 250 V AC/DC |
| Insulation Resistance | >10⁹ Ohms |
| Dielectric Strength | 2.5 kV (AC, 1 min) |
| Shielding | Yes, 360° EMC shielded |
| Cable Entry Size | PG11 (for 6–12 mm cable diameter) |
| Ingress Protection (mated) | IP65 (dust-tight, water spray-resistant) |
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | -55°C to +90°C |
| Mechanical Locking | Yes, metal locking lever |
| Durability | ≥500 mating cycles |
| Housing Material | Zinc die-cast, nickel-plated |
| Insert Material | Flame-retardant thermoplastic (UL94 V-0) |
| Cable Length | 5 meters |
| 重量 | 0.18 kg |
| Certifications | CE, RoHS compliant, UL recognized, IEC 61984 conformant |
Product Applications:
-
Safety Instrumented Systems (SIS): Connects to I/O modules in critical safety loops such as ESD, BMS, and F&G systems.
-
Modular Control Cabinets: Ideal for use in compact, multi-signal junctions within HIMA HIMax/HIMatrix panels.
-
Machine & Plant Automation: Ensures secure signal transmission for sensors, actuators, and safety modules.
-
Oil & Gas Facilities: Used in harsh zone environments for safe, corrosion-resistant cable terminations.
-
Rail and Airport Automation: 支持s safety signal distribution in rolling stock, signaling cabinets, and terminals.
-
Energy and Utility Systems: Handles relay controls, field feedback, and monitoring signals in substations and switchgear.
Product Advantages:
-
Industrial Grade Build: Durable zinc-alloy housing ensures high resistance to physical and environmental stress.
-
Signal Integrity: Full 360° EMC shielding prevents signal loss or cross-talk, even in high-interference areas.
-
Safety Keying (P2): Prevents connector mismatches during field installation, avoiding downtime or faults.
-
Quick Assembly: 支持s tool-free screw or crimp terminal types for fast and secure field wiring.
-
Environmentally Robust: Performs reliably across wide temperature ranges with IP65 protection.
-
Modular Compatibility: Seamlessly integrates with HIMA’s modular control infrastructure.
-
Low Maintenance: Designed for high mating cycle life and long-term stability.
-
Compact Size: 保存s valuable space in dense control panel layouts.
-
UL & CE Certified: Suitable for both European and global deployments.
常见问题 (FAQ):
-
What type / connection does this plug support—crimp or screw terminal?
It supports both, depending on the variant. The most common is the screw terminal version for ease / maintenance. -
Is the P2 coding necessary if I already label my cables?
Yes. The coding provides mechanical protection against mismating, which cannot be guaranteed by labeling alone. -
Can this plug handle analog signal transmission?
Yes, it can transmit analog signals such as 4–20 mA or ±10V cleanly due to its shielding and contact design. -
How do I maintain EMC integrity during installation?
Ensure the cable shield is properly grounded and clamped to the metal housing using EMC glands or clamps. -
Is this product replaceable in the field without rewiring the system?
Yes, the modular nature allows quick disconnection and replacement with minimal downtime. -
Can I use this connector for outdoor panels?
It can be used in outdoor panels if mounted inside weatherpro/ enclosures due to its IP65 rating when mated. -
How does it differ from the Z7138/3330 series?
The Z7138/3331 series /fers design refinements, better shielding options, and alternative mechanical locking formats. -
Is this plug suitable for ATEX or explosive environments?
The plug itself is not ATEX-certified, but it can be used as part / a certified system when installed within approved enclosures. -
Is this plug resistant to industrial noise and EMI?
Absolutely. It includes a 360° EMC shielding system, which protects the signal lines from electromagnetic interference, an essential feature in environments with VFDs or heavy electrical machinery. -
Can I install it without removing power to the cabinet?
For safety, power should always be isolated before connecting or disconnecting the plug, even if the system supports hot-swapping.
Related 型号s from the Same Series:
| 型号 | 描述 | Poles | Coding | Key Feature |
|---|---|---|---|---|
| Z7138/3331/C5 | 5-pole variant without coding | 5 | None | General-purpose field connection |
| Z7138/3331/C6/P2 | 6-pole with P2 coding | 6 | P2 | Higher contact count, same format |
| Z7138/3331/C5/P1 | 5-pole with P1 coding | 5 | P1 | Alternate coded version for signal safety |
| Z7138/3331/C9 | 9-pole version | 9 | None | For multiple I/O signal lines |
| Z7138/3331/C6 | 6-pole, no coding | 6 | None | Larger circuit capacity without keying |
| Z7138/3330/C5/P2 | Similar 5-pole plug with different shell | 5 | P2 | Similar functionality in Z7138/3330 series |
Popular HIMA 型号s (Same 品牌):
| 型号 | 描述 | Type | Main Use | Compatible Systems |
|---|---|---|---|---|
| F8650E | Redundant CPU for HIMax | Safety Controller | SIL3 logic processing | HIMax |
| F7126 | 16-channel digital input module | I/O Module | Discrete signal monitoring | HIMax / HIMatrix |
| Z7116/C5 | Prewired 5-pin cable plug | Cable Plug | Fast plug-in wiring | HIMax |
| F8652X | Compact safety processor | CPU Module | High-speed safety control | HIMatrix / HIMax |
| F6705 | Digital output module | Output Module | Relay/actuator control | HIMax |
| HIMatrix F35 | Compact SIL3 controller with Ethernet | Safety PLC | Decentralized small system control | HIMatrix |
