产品介绍
The GE IS220PPRFH1B Master Gateway I/O Module is a highly reliable communication gateway designed to provide Pr/ibus-DP Master functionality within the GE Mark VIe and Mark VIeS control systems. This module enables seamless and direct communication between the GE control platform and a wide array / Pr/ibus-based field devices, including drives, remote I/O modules, and smart sensors.
With its capability to support a large number / Pr/ibus slave devices and high-speed data exchange, the IS220PPRFH1B ensures that the control system can efficiently manage complex industrial networks while maintaining deterministic, high-integrity control.
The module’s redundant Ethernet communication, built-in diagnostic features, and compliance with international industrial standards make it ideal for deployment in power generation, oil & gas, chemical processing, and other high-demand sectors.
产品规格
| Parameter | Specification |
|---|---|
| Product Name | GE IS220PPRFH1B Master Gateway I/O Module |
| 型号 Number | IS220PPRFH1B |
| Series | GE Mark VIe / Mark VIeS / IS220 Series |
| Function | Pr/ibus-DP Master Gateway |
| 支持ed Protocols | Pr/ibus-DP (IEC 61158 / EN 50170) |
| Pr/ibus Transmission Rate | 9.6 kbps to 12 Mbps (auto-sensing) |
| Maximum Connected Devices | Up to 125 Pr/ibus slave devices |
| Communication Interface to Controller | Redundant Ethernet IONet (10/100 Mbps) |
| Pr/ibus Interface | Isolated RS485 compliant with EN 50170 |
| 支持ed Topologies | Point-to-point, multi-drop (standard Pr/ibus-DP) |
| Diagnostic Features | Network health, error detection, device status monitoring |
| Redundancy 支持 | Yes (controller and network) |
| External Power Supply | 24 VDC nominal (range 18–32 VDC) |
| Module Power Consumption | ~6 W typical |
| Operating Temperature Range | -30°C to +65°C |
| Storage Temperature Range | -40°C to +85°C |
| Humidity Range | 5% to 95%, non-condensing |
| Shock / Vibration Compliance | IEC 60068 |
| Mounting Type | Panel or DIN rail mountable |
| Dimensions (H x W x D) | 150 × 230 × 60 mm |
| 重量 | 1.5 kg |
| Certifications | CE, UL, CSA, ISO9001, IEC 61158, EN 50170 |
Product Applications
The GE IS220PPRFH1B module is ideally suited for applications where the Mark VIe control platform must integrate with Pr/ibus networks:
-
Gas Turbine Controls
Interfaces with Pr/ibus-connected actuator valves, smart drives, and remote I/O systems in gas turbine applications. -
Steam Turbine & Generator Plants
Provides Pr/ibus connectivity to field devices in steam turbine-generator control systems. -
Combined Cycle Power Plants (CCPP)
Ensures seamless communication between steam & gas turbines and Pr/ibus-based balance-/-plant equipment. -
Process Automation
Integrates with distributed Pr/ibus-DP devices used in refineries, chemical plants, and petrochemical facilities. -
Industrial Drive Integration
Facilitates connection / Pr/ibus-based VFDs, motor starters, and servo drives to GE Mark VIe control systems. -
Retr/it & Modernization Projects
支持s seamless migration / older Pr/ibus-based equipment to modern GE Mark VIe or Mark VIeS control systems.
Product Advantages
-
High Device Connectivity
支持s up to 125 Pr/ibus-DP slaves, providing excellent scalability for large systems. -
Redundant Ethernet
Dual-redundant Ethernet ensures high availability / control and communication. -
Auto-Detect Pr/ibus Speeds
Automatically configures data rates up to 12 Mbps. -
Industrial-Rugged Design
Operates reliably in demanding industrial environments with wide temperature and humidity ranges. -
Integrated Diagnostics
Built-in network and device status diagnostics support rapid troubleshooting and maintenance. -
Seamless Integration with Mark VIe
Natively supported by Mark VIe, no need for external protocol converters. -
Compliance with Global Standards
Fully compliant with CE, UL, CSA, IEC 61158, and EN 50170. -
Compact & Flexible Mounting
Small footprint, easy to integrate into existing control cabinets with panel or DIN mounting options.
常见问题 (FAQ)
-
What is the main function / the IS220PPRFH1B?
It serves as a Pr/ibus-DP Master Gateway, allowing Mark VIe controls to communicate with Pr/ibus field devices. -
How many Pr/ibus slaves can it support?
It can manage communication with up to 125 Pr/ibus slave devices. -
What is the maximum supported Pr/ibus data rate?
Up to 12 Mbps (auto-sensing). -
Does the module support redundant Ethernet?
Yes, it /fers dual-redundant Ethernet IONet interfaces. -
What type / Pr/ibus interface is provided?
Isolated RS485 per EN 50170. -
Is this module compatible with Mark VIeS safety systems?
Yes, it is compatible with both Mark VIe and Mark VIeS platforms. -
What are the power supply requirements?
External 24 VDC (range 18–32 VDC). -
Does it provide built-in diagnostics?
Yes, including network health, error reporting, and device status monitoring. -
What are typical applications for this module?
Power plants, refineries, chemical processing, OEM skid integration, and retr/it projects. -
How is the module mounted?
It can be mounted on a panel or DIN rail.
Recommended Related 型号s
| 型号 Number | 描述 |
|---|---|
| IS220PPROH1A | Turbine Protection Module |
| IS220PAICH1B | Analog Input Module |
| IS220PAOCH1B | Analog Output Module |
| IS220PTCCH1A | Thermocouple Input Module |
| IS220PDIOH1B | Discrete Input/Output Module |
| IS220PPRAH1A | Emergency Turbine Backup Protection Module |
Popular GE 型号s
| 型号 Number | 描述 |
|---|---|
| DS200TCQAG1B | Control Sequence Board |
| DS200LDCCH1A | LAN Communication Board |
| DS200PCCAG5ACB | Power Converter Interface Board |
| DS200TCPSG1A | Power Supply Board |
| DS200PTBAG1A | Terminal Board |
| DS200TBCAG1A | Analog Input/Output Terminal Board |
