Product Overview
The GE IC694MDL753 is a high-density DC voltage output module designed for use with the PACSystems RX3i programmable automation controllers. This output module provides 32 discrete outputs and operates on 12/24V DC positive logic. The outputs are arranged in four isolated groups / eight points each, which allows for enhanced electrical isolation and flexibility in wiring and control applications.
Designed to meet the needs / modern industrial automation, the IC694MDL753 is well-suited for environments requiring fast switching speeds, reliable signal control, and modular scalability. It integrates seamlessly into the RX3i control system, /fering compact size, robust build, and advanced diagnostic features.
Technical Specifications
| Parameter | Details |
| Product 型号 | GE IC694MDL753 |
| Module Type | DC Voltage Output Module |
| Output Type | Positive logic (sourcing) |
| Number / Output Points | 32 total (organized into 4 groups / 8) |
| Output Voltage Range | 10.2 VDC to 28.8 VDC |
| Nominal Voltage | 12 VDC / 24 VDC |
| Output Current | 0.5 A per point, 4.0 A maximum per group |
| Inrush Current | 5.4 A for 10 ms |
| Output Leakage (OFF) | < 0.1 mA |
| Voltage Drop (ON) | ≤ 0.3 VDC |
| Turn On/Off Time | ≤ 0.5 ms |
| Group Isolation | Yes – 4 groups electrically isolated from each other |
| Backplane Power Draw | 260 mA @ 5 VDC |
| Short Circuit Protection | Yes (electronic) |
| Field to Backplane Isolation | 250 VAC continuous, 1500 VAC for 1 minute |
| Mounting | DIN rail or panel mount |
| Dimensions (W x H x D) | 34 x 145 x 140 mm |
| 重量 | 0.249 kg |
| Certifications | UL, CE, ATEX Zone 2, UL HAZLOC, DNV, ABS, GL, KRS, LR |
Applications
The IC694MDL753 module is commonly applied in various industrial and process automation environments where reliable digital output control is essential:
-
Discrete control systems in factory automation
-
Material handling systems such as conveyors, sorters, and stackers
-
Packaging equipment requiring high-speed outputs
-
Batch processing plants (chemical, food & beverage, pharmaceuticals)
-
Energy management and smart grid substations
-
OEM control panels for machine builders
-
Remote terminal 件s (RTUs) in SCADA applications
-
Building automation and lighting control systems
Product Advantages
-
High Output Density: 32 outputs reduce system footprint and improve cost-efficiency.
-
Isolated Output Groups: Each / the 4 groups is electrically isolated, improving fault tolerance and system safety.
-
Fast Switching: 优秀 0.5 ms turn-on//f speed ensures real-time response.
-
Flexible Logic Control: Positive logic is ideal for sourcing devices like solenoids and indicators.
-
Electronic Protection: Built-in protection prevents module damage due to overload or short circuits.
-
Rugged Design: Designed to withstand industrial environments and certified for hazardous zones.
-
Easy Integration: Seamlessly integrates into PACSystems RX3i platforms with user-friendly configuration.
-
Reduced Wiring Complexity: Grouped commons and outputs streamline field wiring.
Latest Industry Update
Emerson Completes Acquisition / GE Intelligent Platforms
Date: February 1, 2019
As part / Emerson’s acquisition / GE Intelligent Platforms, the PACSystems RX3i product line—including the IC694MDL753—is now integrated into Emerson’s broader portfolio / automation solutions, ensuring continued support and innovation for industrial control systems.
常见问题 (FAQ)
-
What is the IC694MDL753 primarily used for?
It is used to control up to 32 DC-powered devices like actuators, lamps, or solenoids in industrial automation. -
Can the outputs be mixed across different voltages?
No, all outputs within the module must operate within the specified 12/24V DC range. -
Does this module support output diagnostics?
Yes, it supports diagnostics such as short circuit detection and power status per group. -
Can I use the IC694MDL753 with third-party PLCs?
No, it is designed to work specifically with the GE Fanuc PACSystems RX3i series. -
Is field wiring required for each group?
Yes, each group has its own common, and field wiring is done accordingly per group / 8 outputs. -
What happens to outputs if the controller is in STOP mode?
All outputs default to OFF when the controller is not actively running. -
What type / devices can be connected?
You can connect sourcing-compatible devices such as DC contactors, pilot lights, and small motors. -
Is it suitable for mission-critical environments?
Yes, the module is certified for use in high-reliability and hazardous zones. -
What’s the power consumption from the backplane?
The module draws 260 mA at 5 VDC from the RX3i backplane. -
Can it be installed vertically or horizontally?
Yes, it can be installed in either orientation, following GE’s installation guidelines.
