Product Overview
The GE Fanuc IC697ALG230 is a high-performance Analog Input Basic Converter Module designed for use within the Series 90-70 PLC system. This module provides 8 differential or 16 single-ended analog input channels that can measure voltage or current signals from a wide variety / industrial sensors and transmitters.
Key Features
-
8 differential or 16 single-ended inputs for flexible configuration
-
支持s voltage (±10 V) and current (4–20 mA) input types
-
12-bit A/D resolution for precise analog signal conversion
-
Channel-to-channel and channel-to-ground isolation for improved signal integrity
-
S/tware-configurable channels through the PLC programming environment
-
Built-in diagnostics for channel status and module health
-
Cold-junction compensation (CJC) when used with temperature transducers
-
High accuracy and low drift suitable for process automation and control
-
Compact and durable design for industrial environments
Technical Specifications
| Specification | Details |
|---|---|
| 型号 | IC697ALG230 |
| Type | Analog Input Basic Converter Module |
| Number / Channels | 8 differential or 16 single-ended |
| Input Signal Type | Voltage or Current |
| Voltage Range | ±10 V DC |
| Current Range | 4–20 mA (with external resistor) |
| Input Impedance | 10 MΩ (voltage), 250 Ω (current) |
| Resolution | 12 bits |
| Accuracy | ±0.05% / full scale |
| Isolation | 1500 V RMS channel-to-ground |
| Update Rate | 5 ms per channel |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | –40 °C to +85 °C |
| Power Requirements | +5 V DC, 500 mA max |
| Dimensions | 138 × 70 × 25 mm |
| 重量 | 0.36 kg |
常见问题 (FAQ)
1. What input types are supported by the IC697ALG230?
It supports both voltage (±10 V) and current (4–20 mA) analog input signals.
2. How many analog input channels are available?
The module provides 8 differential or 16 single-ended channels, selectable by configuration.
3. What is the resolution / the A/D converter?
It /fers 12-bit resolution, providing fine granularity for accurate analog measurements.
4. Can I configure each channel independently?
Yes, each channel can be configured individually for voltage or current mode using PLC s/tware.
5. What kind / isolation does the module /fer?
It provides 1500 V RMS isolation between channels and between channel and ground, ensuring safe and stable operation.
6. Does the module support cold-junction compensation?
Yes, it includes built-in CJC capability when used with temperature transducers.
7. What is the power requirement / this module?
It requires +5 V DC with a maximum current draw / 500 mA.
8. How does the module handle noise and interference?
It uses differential inputs and internal filtering to suppress electrical noise and maintain measurement accuracy.
