System Integration Overview
The GE Bently Nevada 8602-FT-ST Fiber Optic Transmitter Module is designed for high-reliability signal distribution within advanced machine protection and condition monitoring architectures. From a system-integration perspective, the 8602-FT-ST acts as the optical interface that bridges monitoring racks, communication processors, and remote acquisition 件s, providing long-distance, noise-immune connectivity across industrial environments.
The ST-type optical connector /fers mechanical robustness and consistent coupling performance, making the module well-suited for environments where vibration, electromagnetic interference, or extended cable runs would compromise traditional copper-based links.
Technical Specifications
| Parameter | 描述 |
|---|---|
| 型号 Number | 8602-FT-ST |
| 品牌 | GE Bently Nevada |
| Module Type | Fiber Optic Transmitter Module |
| Connector Type | ST (twist-lock multimode optical connector) |
| Transmission Medium | Multimode fiber |
| Nominal Wavelength | 820–850 nm (typical multimode LED transmission) |
| Transmission Distance | Up to 2 km (fiber and installation dependent) |
| Power Supply | 24 VDC nominal |
| Power Consumption | Approx. 80–100 mA |
| Compatible Systems | Bently Nevada 3500 Series, 3300 legacy architectures, remote communication 件s |
| Operating Temperature | –20°C to +65°C |
| Storage Temperature | –40°C to +85°C |
| Dimensions (H × W × D) | 110 mm × 25 mm × 75 mm |
| 重量 | ≈ 0.15 kg |
| Mounting Method | Panel or DIN-rail (via installation kit) |
Applications / Use Scenarios
-
Long-distance communication between distributed Bently Nevada monitoring stations
-
Optical link between 3500/22M communication gateways and remote racks
-
Machine protection systems requiring electrical isolation
-
Turbine, compressor, and rotating machinery diagnostic networks
-
Sites where EMI levels prohibit copper-based communication
-
Expansion / existing condition monitoring infrastructure using fiber pathways
Advantages / Engineering Benefits
-
Strong imm件y to electromagnetic interference, essential for high-power industrial machinery
-
Long-range signal distribution with stable optical output
-
Mechanical reliability due to ST locking mechanism
-
Simplified integration into both legacy and modern Bently Nevada systems
-
Compact design that fits system expansion projects with tight panel space
-
Electrical isolation improving overall system safety and diagnostic quality
