Product Overview
The Bently Nevada 3500/65 172109-01 RTD/Isolated Tip TC I/O Module is an advanced temperature input solution for the Bently Nevada 3500 Machinery Protection System. 支持ing both RTD and isolated tip thermocouple sensors, it ensures accurate and continuous monitoring / critical machine components such as bearings, shafts, and windings. With configurable alarm setpoints and seamless rack integration, this module plays a crucial role in early fault detection, predictive maintenance, and machinery protection in demanding industrial environments.
Key Features
-
Dual input channels for monitoring RTDs and isolated tip thermocouples
-
High accuracy temperature measurement for reliable diagnostics
-
支持s multiple RTD types (Pt100, Ni RTD) and isolated tip thermocouples
-
Two alarm setpoints per channel (Alert and Danger) for proactive protection
-
Seamless integration with the Bently Nevada 3500 rack system
-
Online diagnostics for predictive maintenance and condition monitoring
-
Rugged design suitable for harsh industrial applications
Technical Specifications
| Item | Specification |
|---|---|
| Module Type | RTD / Isolated Tip Thermocouple I/O Module |
| 型号 Number | 3500/65 172109-01 |
| Channels | 2 independent temperature input channels |
| 支持ed Sensors | RTDs (Pt100, Ni RTD) and isolated tip thermocouples |
| Measurement Range | Sensor-dependent |
| Accuracy | High accuracy for protection-grade monitoring |
| Alarm Setpoints | 2 per channel (Alert and Danger) |
| System Compatibility | Bently Nevada 3500 rack system |
| Power Supply | Via rack backplane |
| Operating Temperature | -30°C to +65°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 95% non-condensing |
| Dimensions | 241.3 x 24.4 x 99.1 mm |
| 重量 | 0.45 kg |
Industry Applications
-
Steam and gas turbines – bearing and winding temperature monitoring
-
Compressors and pumps – detection / overheating or lubrication issues
-
Generators and motors – protection / windings and rotating components
-
Oil & gas facilities – continuous monitoring in critical operations
-
Petrochemical and refining plants – safety and reliability assurance
常见问题 (FAQ)
Q1: What is the function / the 3500/65 172109-01 module?
It provides temperature monitoring using RTDs and isolated tip thermocouples for machinery protection.
Q2: How many channels does this module have?
It has 2 temperature input channels.
Q3: What sensor types are supported?
It supports RTDs (e.g., Pt100, Ni RTD) and isolated tip thermocouples.
Q4: What alarm setpoints does it /fer?
Each channel has two configurable alarms (Alert and Danger).
Q5: How does this module integrate with the system?
It installs into the Bently Nevada 3500 rack and interfaces with other monitoring modules.
Q6: Is it suitable for harsh industrial environments?
Yes, it is ruggedly designed for high-reliability applications.
Q7: What power supply does it use?
It is powered directly through the rack backplane.
Q8: Can it support predictive maintenance strategies?
Yes, it provides continuous online monitoring and diagnostics for condition-based maintenance.
Q9: What industries typically use this module?
It is widely used in power generation, petrochemical, refining, and heavy industrial sectors.
Q10: What is the operating temperature range?
The module operates between -30°C and +65°C.
