Product Overview
The Bently Nevada 3500/62-03-00 136294-01 is a highly reliable Process Variable Monitor Input/Output (I/O) Module designed to function within the Bently Nevada 3500 Series Machinery Protection System. This module enables accurate measurement and monitoring / various process variables critical to machinery health, including temperature, pressure, flow, and other analog signals. It interfaces seamlessly with other 3500 system modules to provide comprehensive condition monitoring and protection.
Engineered for industrial robustness, the 3500/62-03-00 module supports multiple sensor types and analog inputs with precise data acquisition and transmission capabilities. Its compact size and low weight allow easy integration within 3500 racks while maintaining full compatibility with the system’s communication and power architecture. This module is essential for applications requiring the monitoring / process parameters alongside vibration and temperature data, /fering a holistic machinery protection solution.
Technical Specifications
| Parameter | Value |
|---|---|
| 型号 | 3500/62-03-00 136294-01 |
| Module Type | Process Variable Monitor I/O Module |
| 支持ed Inputs | Analog signals including temperature, pressure, flow |
| Input Channels | Multiple (configuration dependent) |
| Signal Types | 4-20 mA, 0-10 V, RTD, Thermocouple |
| Accuracy | ±0.1% / full scale |
| Dimensions (L x W x H) | 241.3 x 24.4 x 99.1 mm |
| 重量 | 0.2 kg |
| Mounting | 3500 Series rack mount |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -55°C to +85°C |
| Humidity | 0% to 95% non-condensing |
| Communication | Integrated backplane interface |
| Diagnostics | Signal integrity monitoring, fault detection |
| Certifications | CE, UL, CSA |
Applications
The 3500/62-03-00 module is widely used in industries where monitoring process variables alongside machinery condition is critical. Common applications include:
-
Power Generation – Monitoring temperature, pressure, and flow in turbines and auxiliary equipment.
-
Oil & Gas – Supervising pumps, compressors, and process vessels to ensure safe operation.
-
Chemical Processing – Tracking process variables in reactors, heat exchangers, and distillation columns.
-
Mining and Metals – Monitoring lubrication oil pressure and temperature in heavy machinery.
-
Water and Wastewater Treatment – Supervising pump pressures, flow rates, and motor temperatures.
-
Marine and Offshore – Monitoring process variables in engine rooms and safety-critical systems.
Key Advantages
-
Multi-Parameter Monitoring: 支持s various analog signals including 4-20 mA, 0-10 V, RTD, and thermocouples for broad application.
-
High Accuracy and Reliability: Ensures precise data acquisition critical for accurate process monitoring and protection.
-
Seamless System Integration: Designed for plug-and-play integration into the 3500 series rack with common backplane communication.
-
Advanced Diagnostics: Provides signal integrity and fault detection to ensure sensor and signal reliability.
-
Compact and Lightweight: Its small footprint and 0.2 kg weight make it ideal for tight rack spaces.
-
Wide Operating Range: Reliable operation in extreme temperatures and humidity conditions.
-
Industrial-Grade Build: Designed to withstand harsh vibration, shock, and electromagnetic interference.
-
Certified for Safety and Compliance: Complies with global industrial standards.
常见问题 (FAQ)
-
What types / signals does the 3500/62-03-00 module support?
It supports analog inputs including 4-20 mA, 0-10 V, RTD, and thermocouple signals. -
How many input channels does this module provide?
The number / input channels varies based on configuration, supporting multiple analog inputs. -
Is the module compatible with other Bently Nevada 3500 Series equipment?
Yes, it is fully compatible and integrates seamlessly within the 3500 rack system. -
What is the accuracy / the module’s measurements?
It /fers ±0.1% accuracy / full scale, ensuring precise data monitoring. -
Can the module detect signal faults or sensor failures?
Yes, it has built-in diagnostics to detect signal integrity issues and sensor faults. -
What are the physical dimensions / this module?
The dimensions are 241.3 mm (L) × 24.4 mm (W) × 99.1 mm (H). -
How much does the module weigh?
Approximately 0.2 kg. -
What is the operating temperature range for this module?
It operates reliably between -40°C and +70°C. -
Does this module require active cooling?
No, it uses passive cooling through ventilation. -
Is the module certified for use in industrial environments?
Yes, it meets CE, UL, and CSA industrial certification standards.
Recommended Related or Series 型号s
| 型号 | 描述 |
|---|---|
| 3500/62-01-00 | Temperature monitoring module |
| 3500/62-02-00 | Extended temperature monitoring module |
| 3500/50 | Vibration and position monitoring module |
| 3500/22 | Proximitor sensor module for shaft vibration |
| 3500/33 | Speed and phase monitoring |
| 3500/92 | Relay driver module |
Popular Bently Nevada 型号s
| 型号 | 描述 |
|---|---|
| 3500/91-01-01-02 | 3500 Series display module, standard version |
| 3500/91-01-01-BR | 3500 Series display module, bright screen option |
| 3500/91-01-02-00 | 3500 Series alarm relay module |
| 3500/91-01-02-01 | 3500 Series alarm relay module with test feature |
| 3500/91-01-03-00 | 3500 Series communication interface module |
| 3500/91-01-03-01 | 3500 Series communication module with redundancy |
