产品介绍
The Bently Nevada 3500/22-01-01 Transient Data Interface (TDI) Module serves as a critical component within the 3500 Series Machinery Protection System. Designed to interface between the 3500 monitoring system and compatible s/tware such as System 1® 状态 Monitoring and Diagnostic s/tware, the TDI module combines the functionalities / a 3500/20 Rack Interface Module (RIM) with the data collection capabilities / a communication processor. Installed in the slot adjacent to the power supplies / a 3500 rack, the TDI facilitates continuous collection / steady-state and transient dynamic data, transmitting this information via Ethernet to host s/tware for analysis.
产品规格
| Parameter | Specification |
| 型号 Number | 3500/22-01-01 |
| 制造商 | Bently Nevada |
| Series | 3500 Series Machinery Protection System |
| Functionality | Transient Data Interface Module |
| Input Voltage | 220 V |
| Power Consumption | 10.5 Watts |
| Data Inputs | Front Panel USB-B, 10Base-T/100Base-TX Ethernet |
| Outputs | Front Panel LEDs (OK, TX/RX, TM, CONFIG OK), I/O Module OK Relay |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -55°C to +85°C |
| Humidity | 95%, non-condensing |
| Ingress Protection | IP67 |
| Dimensions (H x W x D) | 241.3 mm x 24.4 mm x 241.8 mm |
| 重量 | 0.91 kg |
| Country / Origin | 单位ed 状态s |
Product Applications
The Bently Nevada 3500/22-01-01 TDI Module is utilized across various industrial sectors to provide reliable data interface for machinery protection systems. Typical applications include:
-
Power Generation Facilities: Facilitating data collection for monitoring systems in power plants.
-
Oil and Gas Industry: Providing data interface for monitoring equipment in refineries and /fshore platforms.
-
Chemical Processing Plants: Enabling data collection for control systems that monitor chemical processes.
-
Pulp and Paper Industry: Supplying data interface to automation systems in paper mills.
-
Automotive Manufacturing: Facilitating data collection for machinery protection systems on assembly lines.
-
Water Treatment Plants: Providing data interface for monitoring and control systems in water purification processes.
Product Advantages
-
Integrated Functionality: Combines the roles / a Rack Interface Module and a communication processor, streamlining system architecture.
-
Ethernet Connectivity: Offers 10Base-T/100Base-TX Ethernet connectivity for efficient data transmission.
-
Robust Environmental Tolerance: Operates effectively in a wide temperature range and high humidity conditions, suitable for demanding industrial environments.
-
Compact Design: The module’s compact dimensions allow for easy integration into existing systems without requiring significant space.
-
High Data Throughput: Facilitates continuous collection / steady-state and transient dynamic data, enhancing monitoring capabilities.
-
Ingress Protection: Rated IP67, /fering protection against dust and water ingress.
常见问题 (FAQs)
1. What is the primary function / the 3500/22-01-01 TDI Module?
It serves as an interface between the 3500 monitoring system and compatible s/tware, facilitating data collection and transmission.
2. Can the module operate independently?
No, it functions as part / the 3500 Series Machinery Protection System and requires integration with other system components.
3. Is the module hot-swappable?
Yes, it allows for module replacement without interrupting system operation when a redundant power supply is present.
4. What are the dimensions / the module?
The module measures 241.3 mm in height, 24.4 mm in width, and 241.8 mm in depth.
5. What is the weight / the module?
It weighs 0.91 kg.
6. What is the operating temperature range / the module?
The module operates in temperatures ranging from -40°C to +70°C.
7. What is the ingress protection rating / the module?
It has an IP67 rating, /fering protection against dust and water ingress.
8. Can the module be used in various industrial applications?
Yes, it is suitable for use in power generation, oil and gas, chemical processing, pulp and paper, automotive manufacturing, and water treatment industries.
9. Where is the module manufactured?
The module is manufactured in the 单位ed 状态s.
10. Does the module support Ethernet connectivity?
Yes, it /fers 10Base-T/100Base-TX Ethernet connectivity for efficient data transmission.
Related 型号s (Same Series or Function Family)
| 型号 Number | 描述 |
| 3500/22-01-02 | TDI Module with Fiber Optic Ethernet I/O |
| 3500/22-01-03 | TDI Module with Enhanced Data Collection Features |
| 3500/22-01-04 | TDI Module with Advanced Diagnostic Capabilities |
| 3500/22-01-05 | TDI Module with Extended Temperature Range |
| 3500/22-01-06 | TDI Module with Redundant Power Supply 支持 |
| 3500/22-01-07 | TDI Module with High-Speed Data Transmission |
Popular Bently Nevada Modules (Same 品牌)
| 型号 Number | 描述 |
| 3500/42M | Proximitor/Seismic Monitor Module |
| 3500/32M | 4-Channel Relay Module |
| 3500/25 | Keyphasor Module |
| 3500/60 | Temperature Monitor Module |
| 3500/93 | Display Interface I/O Module |
| 3500/50 | Tachometer Module |
