The Bently Nevada 330904-02-20-05-01-00 3300 NSv Proximity Probe is a precision non-contact displacement and vibration sensor engineered for continuous monitoring / critical rotating machinery. Designed for applications where small shaft diameters or limited installation space exist, this probe provides stable and accurate measurements / shaft position and dynamic vibration using proven eddy current technology. Its compact 0.5 m total length and robust stainless-steel construction ensure reliable performance in power generation, petrochemical, and other demanding industrial environments. The probe works seamlessly with Bently Nevada monitoring systems, enabling predictive maintenance and early detection / issues such as misalignment, imbalance, and bearing wear.
产品规格
| Parameter | Details |
|---|---|
| 型号 Number | 330904-02-20-05-01-00 |
| Series | 3300 NSv Proximity Probe |
| Total Length | 0.5 meter |
| 重量 | 0.15 kg |
| Measurement Principle | Eddy current, non-contact |
| Sensing Range | 0–2 mm typical (displacement) |
| Frequency Response | 0–10 kHz |
| Linearity | ±1% / full scale |
| Operating Temperature | –40 °C to +125 °C |
| Housing Material | Stainless steel, corrosion-resistant |
| Mounting Type | Threaded or flanged |
| Output Signal | AC voltage proportional to shaft displacement |
| Cable Type | Low-noise shielded coaxial |
| Connector Type | Industrial-grade or MIL-spec |
Applications
-
Steam and Gas Turbines – Continuous monitoring / rotor vibration and axial position.
-
Compressors and Pumps – Detection / shaft misalignment and imbalance to avoid unplanned downtime.
-
Generators – Real-time vibration analysis to protect bearings and shafts.
-
Industrial Motors – Shaft position feedback for process-critical operations.
-
Gearboxes – Early detection / gear wear or misalignment.
-
Process Equipment – Integration with plant-wide condition monitoring and DCS systems.
Advantages
-
Non-联系我们 Accuracy – Eliminates mechanical wear while maintaining long-term precision.
-
Compact & Lightweight – 0.5 m length and 0.15 kg weight simplify installation in restricted spaces.
-
Wide Temperature Range – Reliable performance from –40 °C to +125 °C.
-
High-Frequency Response – Captures rapid shaft dynamics up to 10 kHz.
-
Durable Build – Stainless-steel housing resists corrosion and industrial contaminants.
-
Flexible Mounting – 支持s threaded and flanged installations for diverse machinery.
-
Stable Output Signal – Low-noise design ensures consistent displacement readings.
-
Proven Reliability – Backed by the globally recognized Bently Nevada brand for critical assets.
FAQ
-
What sensing technology is used in this probe?
The probe uses eddy current technology to measure shaft displacement and vibration without physical contact. -
Can this probe integrate with standard Bently Nevada monitoring systems?
Yes, it is fully compatible with 3300 NSv drivers and other Bently Nevada monitoring equipment. -
What is the typical measurement linearity?
The probe provides ±1% full-scale linearity for high measurement accuracy. -
Does it support high-speed machinery monitoring?
Absolutely, its 0–10 kHz frequency response makes it ideal for high-speed turbines, compressors, and motors. -
How is the probe mounted?
It can be installed using threaded or flanged fittings depending on equipment requirements. -
What type / signal cable is recommended?
A shielded low-noise coaxial cable is recommended to maintain signal integrity and reduce interference. -
Can it operate reliably in extreme temperature environments?
Yes, the probe is designed for operation from –40 °C to +125 °C. -
Is regular recalibration necessary?
After initial setup with its driver, the probe generally maintains calibration for extended periods without frequent adjustments. -
How does it handle industrial contaminants such as oil or dust?
Its stainless-steel sealed housing provides strong resistance to oil, dust, and moisture. -
Can it detect rotor imbalance or misalignment indirectly?
Yes, by continuously tracking shaft displacement and vibration, the probe provides data that helps identify imbalance or misalignment early.
Related 型号s (Same Series)
| 型号 Number | Key Feature / Application |
|---|---|
| 330904-00-24-10-02-05 | General-purpose NSv probe for turbine monitoring |
| 330904-00-25-05-02-05 | Compact 0.5 m probe for confined spaces |
| 330904-00-26-05-02-05 | Extended temperature range for harsh conditions |
| 330904-00-27-05-02-05 | High-sensitivity probe for low-displacement detection |
| 330904-00-28-05-02-05 | Ruggedized probe for heavy-duty industrial environments |
| 330904-00-29-05-02-05 | Integrated connector for simplified installation |
Popular Bently Nevada 型号s
| 型号 Number | Primary Application |
|---|---|
| 330900-70-05 | Proximity sensor for turbine and generator vibration control |
| 330901-00-08-05-02-RU | Standard 3300 NSv probe for displacement monitoring |
| 330901-00-12-05-02-RU | High-precision probe for rotating machinery |
| 330901-22-40-10-01 | Optimized for high-speed shaft measurement |
| 330901-31-54-05-02-00 | Extended-range probe for turbines and compressors |
| 330901-00-32-05-02-CN | Industrial-grade probe for pumps and motors |
