产品介绍
The Bently Nevada 330302-000-050-10-90-01-00 3300 XL High Temperature Probe is an advanced proximity measurement probe engineered for demanding industrial environments. Designed as part / the renowned 3300 XL series, it delivers precise shaft vibration and position monitoring in high-temperature conditions where reliability is critical. The probe works seamlessly with 3300 XL proximitor sensors and extension cables to form a complete non-contact displacement measurement system. With superior mechanical durability and stable performance across a wide thermal range, it is ideal for applications such as power generation, petrochemical operations, and heavy rotating machinery monitoring.
产品规格
| Parameter | 描述 |
|---|---|
| 型号 Number | 330302-000-050-10-90-01-00 |
| Series | 3300 XL High Temperature Probe |
| Measurement Range | 2 mm (80 mils) non-contact displacement |
| Sensitivity | 7.87 mV/µm (typical) |
| Frequency Response | DC to 10 kHz |
| Humidity | 0–95 % non-condensing |
| Vibration Tolerance | Up to 20 g, 10–2000 Hz |
| Insulation Resistance | >100 MΩ at 500 V DC |
| Dielectric Strength | 2.5 kV AC for 1 minute |
| 重量 | 1.053 kg |
| Housing Material | Stainless steel, high-temperature rated enclosure |
| Probe Tip Material | Ceramic tip with abrasion resistance |
| Output Compatibility | Compatible with Bently Nevada 3300 XL Proximitor sensors |
Applications
-
Gas and Steam Turbines: Provides accurate shaft vibration and position data to protect high-value rotating equipment in high-temperature environments.
-
Petrochemical Plants: Operates reliably in refineries and chemical processing facilities where high ambient heat and corrosive conditions are common.
-
Power Generation Systems: Ensures consistent monitoring for turbines, generators, and auxiliary machinery exposed to harsh operating conditions.
-
Compressors and Heavy Pumps: Detects early signs / imbalance, misalignment, and bearing wear, allowing predictive maintenance strategies.
-
Industrial Motors and Drives: 支持s critical vibration measurement where continuous high-heat operation is expected.
Advantages
-
High Temperature Resilience: Performs accurately from −52 °C to +100 °C, with storage capability to +105 °C, maintaining calibration in demanding conditions.
-
Precision Measurement: Ensures consistent sensitivity and linear response for critical vibration monitoring / rotating machinery.
-
Robust Mechanical Design: Built with stainless steel housing and a ceramic probe tip for resistance to mechanical wear and thermal stress.
-
Noise Imm件y: Offers excellent rejection / electromagnetic interference, guaranteeing stable data transmission in electrically noisy environments.
-
Seamless Integration: Fully compatible with Bently Nevada 3300 XL Proximitor sensors and extension cables, simplifying installation and upgrades.
常见问题 (FAQ)
-
Which proximitor sensors are compatible with this probe?
It is designed to operate with Bently Nevada 3300 XL High Temperature Proximitor sensors to maintain system accuracy. -
What is the probe’s frequency response range?
The probe supports a frequency response from DC to 10 kHz, suitable for monitoring a wide spectrum / machinery vibration. -
How is temperature compensation achieved in the probe?
Temperature-compensated materials and precision construction maintain calibration across the specified thermal range. -
Is the probe resistant to electromagnetic interference?
Yes, it is designed with excellent EMI shielding to ensure clean, stable signal output in noisy industrial environments. -
Can the probe be mounted in any orientation?
It can be mounted vertically, horizontally, or at an angle, provided the probe-to-target gap is correctly adjusted. -
What vibration levels can the probe tolerate during operation?
The probe withstands up to 20 g / vibration within a 10–2000 Hz range without performance loss. -
How is the probe calibrated with the proximitor and extension cable?
Calibration is performed as a complete system (probe, proximitor, and extension cable) to ensure accurate measurements. -
Does the probe require special grounding for installation?
Standard grounding procedures recommended for Bently Nevada systems are sufficient; no additional shielding is typically necessary. -
Can the probe function reliably in high-humidity environments?
Yes, it is rated for up to 95% non-condensing humidity, ensuring dependable operation in humid conditions. -
What type / target material is optimal for accurate measurement?
The probe is optimized for use with standard conductive shaft materials such as steel, ensuring precise non-contact displacement readings.
Related 型号s in the Same Series
| 型号 Number | 描述 |
|---|---|
| 330302-000-020-10 | 3300 XL High Temperature Probe, short length variant |
| 330302-000-030-10 | 3300 XL High Temperature Probe, medium length variant |
| 330302-000-060-10 | 3300 XL High Temperature Probe, extended range |
| 330302-000-070-10 | 3300 XL High Temperature Probe, reinforced design |
| 330302-000-080-10 | 3300 XL High Temperature Probe, high-sensitivity version |
| 330302-000-090-10 | 3300 XL High Temperature Probe, rugged industrial configuration |
Popular Bently Nevada 型号s
| 型号 Number | 描述 |
|---|---|
| 330103-00-12-10-02-00 | 3300 XL 8 mm Proximity Probe |
| 3500/22M | Transient Data Interface for 3500 Series Monitors |
| 3300/16 | 16-Channel Machinery Protection Monitor |
| 3500/42M | Proximitor/Seismic Monitor |
| 330130-040-00 | Extension Cable for Proximity Probe Systems |
| 330104-00-05-10-02-05 | 3300 XL 11 mm Proximity Probe |
