产品介绍
The Bently Nevada 330103-00‑06‑10‑02‑R0 is an 8 mm proximity probe from the 3300 XL series, designed for precise, non-contact measurement / shaft vibration and displacement in rotating machinery. Its 1.0-meter cable with a miniature coaxial ClickLoc™ connector allows flexible installation. The probe tip is made / PPS (Polyphenylene Sulfide), and the housing is stainless steel, ensuring durability in industrial environments with high temperature, humidity, or contamination.
For any technical guidance or selection advice, please contact our experts.
产品规格
| Parameter | Specification |
|---|---|
| 型号 | 330103-00-06-10-02-R0 |
| Measurement Range | 8 mm |
| Total Length | 1.0 meter |
| 重量 | 0.323 kg |
| Probe Tip Material | Polyphenylene Sulfide (PPS) |
| Housing Material | Stainless Steel (AISI 303/304) |
| Connector Type | Miniature Coaxial ClickLoc™ |
| Cable Type | Standard Industrial Cable |
| Thread Type | M10 × 1.0 |
| Operating Temperature | –40 °C to +120 °C |
| Target Material | AISI 4140 Steel |
| Compliance | API 670 4th Edition |
Applications
-
Vibration Monitoring: Detect radial and axial shaft vibrations for predictive maintenance.
-
Shaft Position Measurement: Provides precise displacement data for alignment and balance optimization.
-
Keyphasor® Pulse Output: Supplies synchronization signals for machinery protection and control systems.
-
Harsh Environment Operation: Reliable performance in high temperature, humid, or dusty conditions.
For installation, configuration, or model selection guidance, please contact us.
Product Advantages
-
High Accuracy: Non-contact measurement with excellent repeatability.
-
Robust Construction: PPS tip and stainless steel housing withstand harsh conditions.
-
Compatibility: Fully integrates with 3300 XL monitoring systems.
-
Standards Compliance: Meets API 670 machinery protection requirements.
-
Flexible Installation: 1-meter cable allows versatile positioning.
FAQ
Q1: How should I set the probe-to-shaft clearance?
A1: Use a feeler gauge to establish the recommended gap for accurate measurement.
Q2: Can the probe handle variable rotational speeds?
A2: Yes, the probe maintains accuracy throughout the rated speed range.
Q3: How to prevent electrical interference?
A3: Route cables away from electrical noise, ensure proper shielding, and maintain secure connections.
Q4: How do I verify probe function after installation?
A4: Perform a system self-test and check Keyphasor® pulse and vibration signals.
Q5: Is the PPS tip suitable for all shaft materials?
A5: Yes, it is compatible with standard target alloys.
Q6: How do I confirm Keyphasor® signal timing?
A6: Compare the output with a reference pulse under stable conditions.
Q7: Can I extend the cable beyond 1 m?
A7: Signal may degrade; please contact us for guidance.
Q8: What indicates probe wear or malfunction?
A8: Irregular pulses, dropouts, or noise spikes suggest probe or cable issues.
Q9: Does replacing the probe require recalibration?
A9: No, 3300 XL probes are plug-and-play.
Q10: How to troubleshoot probe signal issues?
A10: Check mounting gap, cable integrity, and grounding. For expert advice, please contact us.
Recommended 型号s (Same Series / Related)
| 型号 | 描述 |
|---|---|
| 330101-00-06-10-02-R0 | 8 mm probe, 1 m standard cable |
| 330102-00-06-10-02-R0 | 8 mm armored probe, 1 m cable |
| 330103-00-06-10-02-R0 | Standard 8 mm probe, 1 m cable |
| 330104-00-06-10-02-R0 | Smooth case 8 mm probe, 1 m cable |
| 330191-00-06-10-02-R0 | Low-temperature variant, 8 mm probe, 1 m cable |
| 330106-00-06-10-02-R0 | Reverse mount 8 mm probe, 1 m armored cable |
Popular Bently Nevada 型号s
| 型号 | 描述 |
|---|---|
| 330101-00-03-50-02-IN | 8 mm probe, 1 m standard cable |
| 330102-00-03-50-02-IN | 8 mm armored probe, 1 m cable |
| 330103-00-03-10-02-IN | 10 mm probe, 1 m cable |
| 330140-00-03-05-02-IN | Smooth case 8 mm probe, 1 m cable |
| 330191-00-03-05-02-IN | Extended temperature 8 mm probe, 1 m cable |
| 330105-02-12-05-02-IN | Reverse mount 8 mm probe, 0.5 m armored cable |
