Product Overview
The Bently Nevada 330101-00-25-10-02-05 is a high-performance 8 mm proximity probe from the 3300 XL series, engineered for reliable and precise non-contact vibration and position measurements in rotating machinery. It /fers excellent resistance to harsh environments and ensures long-term stability and accuracy in industrial monitoring systems.
Product Features
-
8 mm probe tip for standard applications
-
Compatible with 3300 XL Proximitor sensors
-
Designed for hazardous environments
-
Long-term reliability with robust cable and connector design
Technical Specifications
| Parameter | Value |
|---|---|
| Probe Series | 3300 XL |
| 型号 Number | 330101-00-25-10-02-05 |
| Tip Diameter | 8 mm |
| Total Length | 1.0 meter |
| 重量 | 0.323 kg |
| Thread Size | 3/8-24 UNF |
| Cable Length | 25 feet (7.62 meters) |
| Connector Type | Miniature coaxial connector |
| Material | Stainless steel |
| Operating Temperature | -35°C to +177°C |
| Compatibility | 3300 XL Extension Cable & Proximitor |
Application Areas
-
Steam and gas turbines
-
Compressors
-
Motors and generators
-
Pumps
-
Gearboxes
-
Fans and blowers
Product Advantages
-
Rugged Build: Withstands extreme temperatures and industrial environments
-
High Accuracy: Reliable and repeatable displacement measurements
-
Wide Compatibility: Integrates seamlessly with other 3300 XL system components
-
Flexible Installation: Multiple thread and cable length options
-
Long Lifespan: Designed for years / maintenance-free operation
常见问题 (FAQ)
1. What does the model number 330101-00-25-10-02-05 represent?
Each segment indicates specifications like cable length, thread type, and connector options tailored to specific applications.
2. Is this probe suitable for high-temperature environments?
Yes, it operates reliably in temperatures up to +177°C.
3. Can it be used with non-Bently Nevada systems?
It is optimized for use with Bently Nevada 3300 XL Proximitor sensors, but may work with compatible third-party systems depending on configuration.
4. What type / output does this probe provide?
It provides a voltage output proportional to the distance between the probe tip and the observed surface.
5. Is the probe tip replaceable?
No, the tip is fixed and designed for long-term use without replacement.
6. Can the cable be extended beyond 25 feet?
No, the system is calibrated for specific cable lengths. Extending beyond factory configuration may affect accuracy.
7. What is the probe’s protection rating?
It features robust environmental sealing but does not have a specific IP rating. It is suitable for industrial-grade environments.
8. Is this probe intrinsically safe?
Some variants / the 3300 XL series are available in intrinsically safe versions. Check the specific configuration.
9. Does it require regular maintenance?
No routine maintenance is required under normal conditions.
10. What is the main difference between the 3300 XL and older series?
Improved cable design, enhanced environmental durability, and better EMI resistance.
Recommended Related 型号s (Same Series or Similar)
| 型号 Number | Probe Tip | Cable Length | Total Length | 重量 |
|---|---|---|---|---|
| 330101-00-10-10-02-00 | 8 mm | 10 ft | 1.0 m | 0.323 kg |
| 330101-00-15-10-02-00 | 8 mm | 15 ft | 1.0 m | 0.323 kg |
| 330101-00-20-10-02-00 | 8 mm | 20 ft | 1.0 m | 0.323 kg |
| 330104-00-06-10-11-00 | 8 mm | 6 ft | 1.0 m | 0.320 kg |
| 330104-00-10-10-11-00 | 8 mm | 10 ft | 1.0 m | 0.320 kg |
| 330105-02-12-10-02-00 | 5 mm | 12 ft | 1.0 m | 0.310 kg |
Popular 型号s from Bently Nevada
| 型号 Number | Product Type | Probe Tip | Cable Length | Total Length | 重量 |
|---|---|---|---|---|---|
| 330103-00-05-10-02-00 | 3300 XL 8 mm Probe | 8 mm | 5 ft | 1.0 m | 0.323 kg |
| 330104-00-06-10-11-00 | 3300 XL 8 mm Probe | 8 mm | 6 ft | 1.0 m | 0.320 kg |
| 330180-91-CN | 3300 XL Proximitor | — | — | — | 0.400 kg |
| 330106-05-30-10-02-00 | 3300 XL 5 mm Probe | 5 mm | 30 ft | 1.0 m | 0.310 kg |
| 330850-50-05 | 3300 XL Extension Cable | — | 5 m | — | 0.150 kg |
| 330130-040-00-00 | 3300 XL Extension Cable | — | 4 m | — | 0.150 kg |
