产品介绍
The Bently Nevada 31000-00-00-00-00-00 Proximity Probe Housing Assembly is a precision-engineered protective enclosure designed to house and secure proximity probes used in vibration monitoring and machinery protection systems. As part / Bently Nevada’s industry-leading condition monitoring portfolio, this housing assembly ensures proper probe alignment, environmental protection, and mechanical stability for accurate vibration measurement on rotating equipment.
This assembly is constructed from high-grade stainless steel and features a rugged, sealed design to protect probes and connectors from contamination, moisture, and mechanical impact. The housing is compatible with standard Bently Nevada 3300, 3309, and 3500 proximity probe systems, providing flexible installation for a wide variety / machinery types including turbines, compressors, pumps, and motors.
Technical Specifications
| Parameter | Specification |
|---|---|
| 型号 Number | 31000-00-00-00-00-00 |
| Product Type | Proximity Probe Housing Assembly |
| Compatible Probe Systems | Bently Nevada 3300, 3309, 3500 Series |
| Material | Stainless steel (AISI 316) |
| Environmental Protection | IP67-rated sealed housing |
| Mounting Configuration | Threaded and flange mount options |
| Cable Entry | Standard ¼” NPT cable port |
| Probe Cable Length | Not required for this configuration |
| Vibration Tolerance | Up to 50 g peak, 10–2000 Hz |
| Operating Temperature | –30 °C to +120 °C |
| Corrosion Resistance | Suitable for chemical and /fshore environments |
| Electrical Isolation | Full mechanical and electrical isolation from machine surface |
| Maintenance Access | Removable cap with O-ring seal |
| 重量 | 1.2 kg |
| Dimensions | 91.4 x 144.8 mm |
| Certification | CE, ATEX Zone 2, RoHS compliant |
| Typical Probe Type | 3300 XL, 3309 XL, or 3500 XL proximity probes |
Applications
The Bently Nevada 31000-00-00-00-00-00 Proximity Probe Housing Assembly is designed for demanding industrial environments where accurate vibration monitoring and probe protection are critical. Typical applications include:
-
Steam and Gas Turbines: Ensures stable probe mounting for shaft vibration measurement and thrust position monitoring.
-
Compressors: Provides secure and isolated probe installation in high-vibration and oil-contaminated environments.
-
Pumps and Motors: Protects probes from ingress / liquids and dust while maintaining precise probe positioning.
-
Gearboxes: Ensures alignment accuracy for gear mesh monitoring and early fault detection.
-
Fans and Blowers: Facilitates easy probe access for balance and bearing condition assessment.
-
Industrial Process Equipment: Provides reliable and repeatable probe installation across diverse mechanical systems.
Advantages
-
High Mechanical Stability: Rigid housing minimizes probe movement, ensuring measurement accuracy even in high-vibration conditions.
-
Environmental Protection: IP67-rated sealing protects probes from dust, oil, and moisture intrusion.
-
Corrosion Resistant: Stainless-steel construction guarantees long-term durability in /fshore, petrochemical, and power plant environments.
-
Universal Compatibility: Works seamlessly with multiple Bently Nevada proximity probe systems, reducing inventory complexity.
-
Easy Maintenance: The removable cap design allows quick access for probe replacement or inspection without removing the entire housing.
-
Electrical Isolation: Prevents ground loops and ensures signal integrity between probe and monitoring system.
-
Flexible Mounting Options: 可用 in threaded or flange configurations to suit various machinery installations.
-
Precision Alignment: Internal guide structure ensures consistent probe-to-target spacing and angular orientation.
-
Field Proven Reliability: Designed and tested to meet the rigorous standards / Bently Nevada condition monitoring equipment.
-
Compact Form Factor: 保存s space while providing robust protection for critical measurement points.
FAQ
-
What probe series are compatible with the 31000-00-00-00-00-00 housing?
It is compatible with Bently Nevada 3300, 3309, and 3500 XL proximity probe systems. -
Does this model require a specific probe cable length?
No, this configuration does not require a specific probe cable length, /fering installation flexibility. -
What is the ingress protection rating / the housing?
It is rated IP67, ensuring full protection against dust and immersion in water up to 1 meter. -
What materials are used in the construction / the housing?
The housing is made / AISI 316 stainless steel for superior corrosion and mechanical resistance. -
Can the housing be used in hazardous environments?
Yes, it is ATEX Zone 2 certified for use in hazardous industrial areas. -
Does the housing provide electrical isolation for the probe?
Yes, it ensures full electrical and mechanical isolation from the machine casing. -
What is the operating temperature range / this model?
It operates between –30 °C and +120 °C, suitable for most industrial applications. -
Is the housing suitable for high-vibration applications?
Yes, it withstands up to 50 g peak vibration levels from 10 to 2000 Hz. -
What type / maintenance is required for this assembly?
Only periodic inspection and O-ring seal replacement are recommended for continued performance. -
Can the housing be mounted in both vertical and horizontal orientations?
Yes, it supports flexible mounting orientations to match various machine geometries.
Related 型号s (Same Series / Similar Function)
| 型号 | 描述 |
|---|---|
| 31000-01-00-00-00-00 | Standard proximity probe housing with cable port |
| 31000-02-00-00-00-00 | Compact probe housing for limited-space installations |
| 31000-03-00-00-00-00 | Extended depth housing for larger machinery |
| 31000-04-00-00-00-00 | Dual-probe housing for redundant vibration monitoring |
| 31000-05-00-00-00-00 | Flanged mounting type probe housing |
| 31000-06-00-00-00-00 | High-temperature rated probe housing assembly |
Popular Bently Nevada 型号s (Same 品牌)
| 型号 | 描述 |
|---|---|
| 330103-00-07-10-02-05 | 3300 XL 8 mm proximity probe |
| 330130-040-00 | Extension cable for 3300 XL probes |
| 330180-91-05 | 3300 XL Proximitor sensor |
| 3500/22M | Transient Data Interface module |
| 3500/42M | Proximitor/Seismic monitor |
| 3500/25 | Keyphasor module for speed and phase measurement |
