产品介绍
The Allen Bradley 22D-D2P3N104 PowerFlex 40P AC Drive is a compact and reliable medium-power drive designed for precise control / three-phase AC motors. It provides 0.75 kW / 1 HP output from a 480V AC supply, making it suitable for light industrial applications, conveyors, small pumps, and fans.
The drive features a panel-mount design with IP20 (NEMA Type Open) protection, allowing easy installation in control panels while ensuring safe operation. Its reset-only display enables operators to perform essential resets and monitor the drive without complex setup. Standard protections include overload, overvoltage, undervoltage, and short-circuit protection, providing safe and reliable motor operation.
With a Frame Size B, this drive combines compactness with robust performance, making it an ideal solution for applications that require simple and efficient motor control.
产品规格
| Parameter | Specification |
|---|---|
| Input Voltage | 480V AC, 3-Phase |
| Output Current | 2.3 A |
| Output Power | 0.75 kW / 1 HP |
| Frame Size | B |
| Control Type | V/Hz Open Loop Control |
| Display | Reset Only |
| Mounting Type | Panel Mount |
| Environmental Rating | IP20, NEMA Type Open |
| Protection | Overload, Overvoltage, Undervoltage, Short-Circuit Protection |
| Communication | Local control via keypad |
| CE Compliant Filter | Not included |
| Operating Temperature | 0–50°C |
| Storage Temperature | -20–70°C |
| Certifications | UL |
| Dimensions | 180 × 100 × 136 mm |
| 重量 | 2.2 kg |
Applications
• Conveyors and Material Handling: Precise speed control for conveyors, hoists, and small cranes.
• Small Industrial Machinery: Ideal for mixers, drills, and other light equipment.
• Pumps and Fans: Controls HVAC systems, water pumps, and fluid handling.
• Packaging Lines: Provides smooth operation for automated packaging machinery.
• Water Treatment Systems: Maintains consistent motor speeds for energy-efficient pumping.
Advantages
• Compact Design: Fits easily into control panels with Frame Size B.
• Energy Efficient: Reduces energy consumption through accurate V/Hz control.
• Easy Operation: Reset-only display allows simple monitoring and reset functions.
• Robust Protection: Built-in protections prevent motor and drive damage.
• Simple Installation: Panel-mount design ensures easy setup and integration.
• Reliable Performance: Suitable for light industrial applications requiring consistent operation.
