The Allen Bradley 2198-KITCON-D057 Kinetix 5700 Connector Kit is an accessory kit designed for the Kinetix 5700 servo drive platform, providing the necessary connector interfaces for reliable drive integration in industrial motion control systems. It is used to ensure proper electrical connection between the servo drive and external system wiring, supporting safe and structured installation.
This connector kit is intended to simplify field wiring while maintaining high signal integrity and secure mechanical fastening. It includes dedicated interface provisions for motor power, feedback, I/O signals, and safety functions such as STO (Safe Torque Off), making it a key component in achieving a complete servo system configuration.
By standardizing connection interfaces, the 2198-KITCON-D057 helps reduce wiring errors, improve installation efficiency, and ensure consistent system performance in demanding automation environments.
产品规格
| Parameter | 描述 |
|---|---|
| 型号 | 2198-KITCON-D057 |
| 品牌 | Allen-Bradley |
| Series | Kinetix 5700 |
| Product Type | Connector Kit |
| Application | Servo Drive Wiring Interface |
| Connector Functions | 2x MP (Motor Power) |
| 2x BC (Brake Control) | |
| 2x I/O (Input/Output Signals) | |
| STO (Safe Torque Off) | |
| Compatibility | Kinetix 5700 Servo Drives |
| Mechanical Design | Industrial Connector Assembly |
| Installation Role | Drive Wiring Termination Interface |
| Diameter | 85 mm |
| 重量 | 0.28 kg |
Applications
• Used in servo drive installation systems to provide standardized wiring connections between Kinetix 5700 drives and external components
• Applicable in motion control systems such as robotics, packaging machines, and high-speed automation lines
• 支持s motor power and feedback wiring ensuring stable and reliable servo motor operation
• Integrates safety functions (STO) for secure torque-/f control in emergency or maintenance conditions
• Used in OEM machine builds where consistent and modular servo wiring is required
Advantages
• Simplifies servo drive wiring by providing pre-defined connection interfaces for key signal groups
• Improves installation reliability by reducing wiring errors and ensuring correct pin configuration
• 支持s safety integration (STO function) for enhanced machine protection
• Enhances system organization with clearly separated connection groups for power, I/O, and control
• Reduces commissioning time by standardizing connection structure across Kinetix 5700 systems
• Robust industrial design ensures stable performance in vibration and harsh environments
