产品介绍
The Allen-Bradley 20-750-ENETR PowerFlex 750 Dual Port EtherNet/IP Module is a high-performance communication option module designed for PowerFlex 750 series drives. It enables direct integration / drive systems into industrial EtherNet/IP networks, supporting advanced control, monitoring, and diagnostics functions.
This module is specifically engineered to provide flexible network architecture support, including star, linear, and Device-Level Ring (DLR) topologies. It enhances system scalability and reliability in modern industrial Ethernet-based automation environments.
Equipped with dual Ethernet ports, ENET1 and ENET2, the module also functions as an embedded industrial Ethernet switch, allowing seamless data routing between network nodes. Additionally, the ENET3 (TAP) port is dedicated to PowerFlex 755 drives, supporting Integrated Motion over EtherNet/IP for high-performance motion control applications.
The 20-750-ENETR is designed for direct installation into the drive control pod, ensuring tight integration with PowerFlex 750 architecture and maintaining high-speed deterministic communication.
产品规格
| Parameter | 描述 |
|---|---|
| Product 型号 | 20-750-ENETR |
| 制造商 | Rockwell Automation (Allen-Bradley) |
| Product Type | EtherNet/IP communication module |
| Compatible Drives | PowerFlex 750 series (including 753 and 755) |
| Communication Protocol | EtherNet/IP |
| Ports | ENET1, ENET2, ENET3 (TAP) |
| Network Function | Embedded industrial Ethernet switch |
| Network Topologies | Star, Linear, Device-Level Ring (DLR) |
| Special Function | Integrated Motion on EtherNet/IP (PowerFlex 755 via ENET3) |
| Operating Mode | Adapter or Tap mode |
| Mounting Type | Drive control pod mount |
| Function | Drive-to-EtherNet/IP network communication |
| Dimensions | 150 × 26 × 68 mm |
| 重量 | 0.062 kg |
