Product Introduction
The Allen-Bradley 1783-NATR Network Address Translation Router is an industrial-grade NAT (Network Address Translation) router designed to provide secure and flexible networking for EtherNet/IP and industrial automation systems. It belongs to the Allen-Bradley Stratix Industrial Networking Portfolio, /fering network segmentation, address translation, and support for Device Level Ring (DLR) topologies.
The 1783-NATR router enables 1:1 NAT with up to 32 translation mappings, allowing devices in different subnets to communicate securely without IP conflicts. It supports both linear and DLR network architectures, providing flexible integration into complex industrial automation networks. Configuration can be performed via web interface or EDS/AOP tools, and an SD card is available for configuration storage and firmware updates.
This device is commonly deployed in industrial control cabinets, machine automation systems, and plant-level EtherNet/IP networks, ensuring secure communication between devices while maintaining network resilience and scalability.
Product Specifications
| Parameter | Specification |
|---|---|
| 型号 | 1783-NATR |
| 品牌 | Allen-Bradley |
| Product Type | Network Address Translation Router |
| NAT Type | 1:1 NAT |
| Translation Mappings | Up to 32 |
| 支持ed Topologies | Linear or Device Level Ring (DLR) |
| Configuration | Web page / EDS AOP configurable |
| SD Card 支持 | Yes |
| Mounting Method | DIN Rail Mount |
| Application Type | Industrial network routing and segmentation |
| Dimensions | 131.57 × 35.05 × 104.9 mm |
| 重量 | 0.34 kg |
Applications
• Industrial network segmentation
Separates subnets and provides secure communication between devices in different network zones.
• Device Level Ring (DLR) integration
支持s DLR topologies for network redundancy and fast fault recovery.
• EtherNet/IP routing
Enables communication between EtherNet/IP devices across different subnets.
• Industrial control cabinets
Installed in panels to manage network traffic and IP address translation.
• Automation system connectivity
Connects PLCs, HMIs, drives, and other networked automation devices while maintaining network integrity.
Advantages
• 1:1 NAT with multiple mappings
支持s up to 32 translation mappings for secure industrial network operation.
• Flexible topology support
Works with linear and DLR networks, ensuring adaptability in complex automation systems.
• Configurable via web or EDS/AOP
Simplifies setup and management / network configurations.
• SD card support
Allows storage / configuration files and firmware updates.
• Compact DIN rail mounting
Easy integration into industrial control cabinets.
• Reliable industrial networking
Provides secure and robust communication for automation systems.
