产品介绍
The Allen Bradley 1769-OW8 CompactLogix 8 Point Relay Output Module is a relay-based digital output module designed for the CompactLogix control platform. It provides 8 relay output channels that allow PLC systems to control both AC and DC loads, making it highly flexible for various industrial automation applications.
Unlike transistor-based output modules, the 1769-OW8 uses electromechanical relay contacts, enabling it to switch a wide range / voltages. It supports an operating voltage range / 5–265 VAC or 5–125 VDC, allowing it to control devices such as contactors, motors, lamps, alarms, and solenoid valves.
The module /fers reliable switching performance with a 10 ms signal delay when turning on, ensuring stable operation in automation systems. Its compact design and compatibility with the 1769 I/O platform make it a practical choice for applications requiring versatile output switching capabilities.
产品规格
| Parameter | Specification |
|---|---|
| Product 型号 | 1769-OW8 |
| Product Type | CompactLogix Relay Output Module |
| Output Channels | 8 |
| Output Type | Relay |
| Operating Voltage Range | 5–265 VAC, 5–125 VDC |
| Bus Current Draw @ 5.1 V | 125 mA |
| Bus Current Draw @ 24 V | 100 mA |
| Signal Delay (On) | 10 ms |
| Heat Dissipation | 2.83 W |
| Wire Type | Copper, 90 °C |
| Wire Size (Solid) | 22–14 AWG |
| Wire Size (Stranded) | 22–16 AWG |
| Mounting Method | DIN Rail / Panel Mount |
| Dimensions | 118 × 35 × 87 mm |
| 重量 | 0.28 kg |
Applications
• Industrial machine control
Used to switch motors, relays, and other electrical devices within automated machinery.
• Process control systems
Controls alarms, pumps, and control relays used in process automation.
• Factory automation equipment
Suitable for switching AC or DC loads in manufacturing lines and automated production systems.
• Building and facility automation
Used for controlling lighting systems, warning signals, and auxiliary equipment.
• OEM machinery
Frequently used by equipment manufacturers requiring flexible relay-based switching outputs.
Advantages
• Relay-based switching
Allows the module to control both AC and DC loads with a wide voltage range.
• Flexible voltage compatibility
支持s loads from 5 V up to 265 VAC or 125 VDC.
• Reliable electromechanical design
Relay outputs provide strong isolation and dependable switching performance.
• Compact module structure
保存s panel space while providing multiple output channels.
• Seamless CompactLogix integration
Fully compatible with other 1769 I/O modules for scalable automation systems.
