Product Overview
The Allen Bradley 1756-OX81 is a digital output module designed for use in ControlLogix systems. As part / the 1756 series, it provides a compact and efficient solution for controlling large numbers / discrete output devices. This module is equipped with 16 output channels and is suitable for industrial automation applications where precise control / machinery and processes is required. The 1756-OX81 supports 24 VDC outputs and is designed to work with the ControlLogix platform for seamless integration with other system components.
Technical Specifications
| Parameter | Specification | Notes |
|---|---|---|
| Output Channels | 16 | Digital output points. |
| Nominal Output Voltage | 24 VDC | Standard DC output voltage. |
| Output Current per Channel | 0.5 A | Max current per output. |
| Total Output Current | 8 A | Maximum current for all channels. |
| Output Type | Sourcing (DC) | For controlling external devices. |
| ControlLogix System Compatible | Yes | Compatible with 1756 chassis. |
| EtherNet/IP Device Limit | N/A | Does not support direct Ethernet connection. |
| Current Draw @24 VDC | ~0.25 A | Typical power draw at full load. |
| Power Dissipation | ~6.2 W | Typical power dissipation. |
| Operating Temperature | 0°C to +60°C | Suitable for industrial environments. |
| Storage Temperature | -40°C to +85°C | Suitable for storage. |
| Dimensions (H × W × D) | 145 mm × 50 mm × 35 mm | Approx. 5.7″ × 2.0″ × 1.4″. |
| 重量 | 0.4 kg (0.88 lbs) | Approximate weight. |
Applications
The 1756-OX81 is ideal for applications requiring robust and reliable control / digital output devices, including:
-
Automated Manufacturing: Controlling motors, lights, valves, and other machines in assembly lines or packaging systems.
-
Industrial Control Systems: Used in facilities for controlling signals to actuators, relays, and other output devices.
-
Process Automation: Managing outputs for processes in chemical plants, food processing, and utilities.
-
Building Automation: Operating equipment like HVAC 件s, security systems, and lighting in commercial buildings.
-
Machine Builders: Providing control outputs for OEM machines, /ten in safety-critical or high-speed environments.
-
Energy Systems: Controlling actuators in renewable energy installations or power stations.
Key Advantages
-
High Output Density: With 16 output points per module, it optimizes space in control panels and reduces the need for multiple modules.
-
Wide Operating Temperature Range: Designed to perform reliably in environments ranging from 0°C to +60°C, making it suitable for a variety / industrial settings.
-
Ease / Integration: Fully compatible with ControlLogix systems, it integrates seamlessly with other Allen Bradley components, simplifying installation and maintenance.
-
Sourcing Outputs: The 1756-OX81 uses sourcing outputs, ideal for driving external DC-powered devices.
-
Cost-Effective Solution: Offers a compact, reliable, and cost-efficient solution for controlling a large number / outputs in automation applications.
-
Robust Design: Built to withstand typical industrial environments, the module can operate under challenging conditions without sacrificing performance or reliability.
