The Allen-Bradley 1756-OV16E is a ControlLogix DC fused sinking output module designed to provide reliable and protected switching for 10–30 VDC field devices. With sixteen sinking output points, this module is intended for industrial control systems where load wiring is configured for sourcing field power and the PLC output provides the return path to ground.
Built for the ControlLogix platform, the 1756-OV16E integrates electronic fuse protection on each individual channel. This design enhances operational safety by isolating faults at the point level, preventing a single short circuit or overload from affecting the entire module. The result is improved system uptime and simplified maintenance.
The module is commonly applied in manufacturing systems, material handling equipment, automotive assembly lines, and process automation installations where DC sinking outputs and per-channel protection are required.
产品规格
| Parameter | 描述 |
|---|---|
| 型号 | 1756-OV16E |
| 品牌 | Allen-Bradley |
| Series | ControlLogix |
| Module Type | DC Fused Sinking Output Module |
| Number / Points | 16 Outputs |
| Output Voltage Range | 10–30 VDC |
| Output Type | DC Sinking |
| Electronic Protection | Individual Electronic Fuse per Channel |
| Continuous Current per Channel | Approx. 1 A |
| Backplane Current Draw | Approx. 250 mA @ 5.1V DC |
| Field Wiring Interface | 36-Pin Removable Terminal Block (RTB) |
| Isolation | Field-to-Backplane Isolation |
| Diagnostics | Channel Fault and Status Indication |
| Status Indicators | Individual Output LEDs and Module Status LED |
| Dimensions | 145.2 × 34.6 × 139.6 mm |
| 重量 | 0.181 kg |
Applications
• Control / 24V DC field devices using sinking output configuration
• Automation systems requiring channel-level electronic fuse protection
• Automotive and manufacturing production lines
• Conveyor, material handling, and packaging equipment
• Installations demanding reliable short-circuit and overload isolation
Advantages
• Sixteen individually fused sinking outputs for improved fault isolation
• Wide 10–30 VDC operating range for flexible system integration
• Integrated electronic protection minimizing damage from overload conditions
• Clear per-channel LED diagnostics for faster troubleshooting
• Compact module design suitable for high-density ControlLogix racks
• Reduces downtime by isolating faults to a single output point
