Product Overview
The ABB TK212A (3BSC630197R1) is a high-quality communication cable designed for use in ABB’s System 800xA, Advant OCS, and related industrial automation environments. This cable provides a robust, shielded connection between interface modules, I/O modules, and controller hardware—ensuring reliable data transmission in electrically noisy or high-vibration industrial settings.
The TK212A is factory-terminated and tested for plug-and-play compatibility with ABB systems. It features industrial-grade connectors, twisted-pair conductors, and full-length shielding, making it ideal for real-time signal transmission and system synchronization across control cabinets or between field devices and centralized systems.
Key Features
-
Pre-terminated signal/communication cable for ABB automation systems
-
Designed for data transmission and synchronization
-
High EMI shielding with twisted-pair design
-
Factory-tested for compatibility with ABB 800xA and Advant OCS platforms
-
Reliable and secure signal integrity over extended lengths
-
Industrial-grade durability for harsh environments
-
Compact and flexible construction for easy routing
-
Halogen-free, flame-retardant cable sheath
-
Precision-engineered connectors with secure locking
Technical Specifications
| Specification | Details |
|---|---|
| Product Name | Communication Cable |
| 型号 Number | TK212A |
| Ordering Code | 3BSC630197R1 |
| Cable Type | Twisted-pair, shielded signal cable |
| Cable Length | Standard lengths available (typically 1.5 m to 5 m) |
| Conductor Material | Tinned copper |
| Shielding | Overall braid or foil shield + twisted pair |
| Voltage Rating | 30 V DC (typical signal voltage class) |
| Temperature Range | -20°C to +80°C |
| Jacket Material | Flame-retardant, halogen-free PVC or TPU |
| Connector Type | Factory-mounted ABB proprietary connectors |
| Connector Orientation | Straight or angled (model-specific) |
| Compatibility | ABB System 800xA, Advant Controller Series, I/O modules |
| Standards Compliance | RoHS, CE, IEC 60332-1, EN 50267 |
| Insulation Resistance | ≥ 20 MΩ·km |
| Capacitance | < 100 nF/km (typical) |
| Dimensions | 15 ×3000× 30 mm |
| 重量 | 0.2 kg |
| Mounting | Plug-and-play, no tools required |
| Durability | Resistant to oil, abrasion, and industrial contaminants |
Industry Applications
The ABB TK212A cable is widely applied in process and factory automation systems for reliable inter-module connectivity:
-
Power Generation: Connects controller to I/O and monitoring 件s in turbine/generator control
-
Oil & Gas: Signal wiring for remote and hazardous location equipment
-
Metals & Mining: High-vibration environments with sensitive I/O signal transmission
-
Chemical Processing: Reliable field-to-controller signal transmission in aggressive environments
-
Pulp & Paper: Controller–I/O synchronization over long distances in processing lines
-
Pharmaceuticals: Cleanroom and validated environments where certified components are required
Product Advantages
-
Plug-and-play solution with tested ABB system compatibility
-
High shielding efficiency for EMC protection in industrial environments
-
Flexible routing in tight control panel spaces
-
Minimal signal loss across long lengths
-
Industrial-grade connectors ensure long-term performance under vibration and thermal cycling
-
Time-saving installation without crimping or field termination
-
Flame-retardant and halogen-free sheath meets environmental and safety requirements
-
Backed by ABB’s documentation and support
-
支持s both legacy and current ABB systems
-
Ready-to-use in ABB-certified system installations
常见问题 (FAQ)
1. What is the TK212A cable used for?
It connects ABB control and I/O modules, transmitting high-integrity signals across systems.
2. Is the cable shielded?
Yes, it includes braided or foil shielding and twisted pairs to resist EMI.
3. What ABB systems does it support?
It supports System 800xA, Advant OCS, and related I/O hardware.
4. Can I use it in hazardous or outdoor environments?
Yes, if enclosed in rated conduit or junction boxes—it is resistant to oil and abrasion.
5. Does the cable come with connectors?
Yes, it is factory-terminated with ABB-specific connectors for plug-and-play use.
6. What is the maximum length available?
Common lengths range from 1.5 m to 5 m; longer custom options may be available.
7. Is the cable compliant with CE or RoHS?
Yes, it complies with RoHS, CE, and applicable IEC/EN safety standards.
8. Can it be reused after disconnection?
Yes, it is reusable if no mechanical damage has occurred.
9. Is the cable halogen-free?
Yes, it uses halogen-free jacket materials suitable for sensitive environments.
10. Is this cable required for ABB I/O modules?
In many ABB installations, it is the recommended or required cable for reliable signal transmission.
