The ABB SYN 5202a-Z,V211 3BHB006715R0211 Synchronizing Device is a high-precision industrial device designed to synchronize electrical generators, motors, and power grids safely and efficiently. It plays a critical role in power generation and distribution systems, ensuring smooth connection between multiple power sources by accurately matching phase, frequency, and voltage. Equipped with ABB’s advanced control algorithms and robust electronic components, the SYN5202a-Z,V211 delivers rapid response, real-time monitoring, and fault detection to prevent system instability or equipment damage. Its compact and modular design allows easy integration into control panels, substations, and power plant automation systems. This device is widely used in hydro, thermal, and renewable energy plants, as well as in industrial microgrids and backup power systems, ensuring safe power transfer, reduced mechanical stress, and optimized energy efficiency.
Technical Specifications
| Parameter | 描述 |
|---|---|
| 型号 | ABB SYN 5202a-Z,V211 3BHB006715R0211 Synchronizing Device |
| Input Voltage | 3-phase 400–480 VAC, 50/60 Hz |
| Control Voltage | 24–48 V DC |
| Frequency Range | 45–65 Hz |
| Synchronizing Accuracy | ±0.1° phase, ±0.5% voltage, ±0.1 Hz frequency |
| Response Time | ≤ 50 ms |
| Communication Protocols | Modbus RTU, Pr/ibus DP, Ethernet/IP |
| Protection Features | Over/under voltage, over/under frequency, phase loss, short-circuit protection |
| Operating Temperature Range | -10 °C to +50 °C |
| Storage Temperature Range | -25 °C to +70 °C |
| Humidity Tolerance | 5–95% non-condensing |
| Monitoring & Diagnostics | Real-time voltage, frequency, and phase display; alarm and event logging |
| Mounting Type | Panel or rack mount |
| Dimensions (W × H × D) | 226 × 171 × 163 mm |
| 重量 | 4 kg |
| Certification | CE, UL, IEC 61850 compliant |
| Firmware Upgrade | Field-upgradeable via Ethernet or USB |
Applications
The ABB SYN 5202a-Z,V211 Synchronizing Device is suitable for a wide range / industrial and power generation scenarios:
-
Power Plants: Synchronization / multiple generators in hydro, thermal, and combined-cycle plants.
-
Industrial Substations: Safe parallel operation / transformers and generators.
-
Renewable Energy Systems: Synchronization / wind, solar, and hybrid power sources to the grid.
-
Motor Synchronization: Coordinated operation / large motors in industrial processes.
-
Microgrid Control: Maintaining phase, voltage, and frequency balance in microgrid or islanded operation.
-
Emergency Backup Systems: Smooth transfer between main supply and standby generators.
Product Advantages
-
High Precision: Phase, voltage, and frequency matching ensures stable operation / parallel power sources.
-
Fast Response: Response time ≤ 50 ms reduces mechanical and electrical stress.
-
Robust Protection: Prevents over/under voltage, over/under frequency, and phase loss.
-
Flexible Connectivity: 支持s Modbus, Pr/ibus, and Ethernet protocols for system integration.
-
Real-Time Monitoring: Live display / voltage, frequency, and phase for operational awareness.
-
Easy Maintenance: Firmware can be updated in the field to keep the system current.
-
Durable Design: Capable / operating in harsh industrial environments with wide temperature and humidity ranges.
-
Optimized System Efficiency: Minimizes energy losses during synchronization and reduces mechanical wear on generators.
FAQ
-
What types / power systems can the SYN 5202a-Z,V211 synchronize?
It can synchronize generators, motors, and multiple power grids including hydro, thermal, renewable, and industrial systems. -
What is the phase accuracy / this device?
The synchronizer maintains phase accuracy within ±0.1°, ensuring smooth parallel operation. -
Can it handle variable frequency inputs?
Yes, it operates across a 45–65 Hz frequency range, allowing synchronization under different grid conditions. -
How is monitoring and diagnostics handled?
Real-time display / voltage, phase, and frequency is provided along with alarm logging and event history. -
Does it provide protection against voltage or frequency deviations?
Yes, over/under voltage, over/under frequency, and phase loss protections are integrated. -
Which communication protocols are supported?
Modbus RTU, Pr/ibus DP, and Ethernet/IP are supported for integration with control and automation systems. -
Can the firmware be updated on-site?
Yes, firmware upgrades can be performed via Ethernet or USB without removing the device. -
What is the typical response time for synchronization?
Response is ≤ 50 ms, allowing rapid and stable connection / power sources. -
Is it suitable for harsh environmental conditions?
Yes, the device operates from -10 °C to +50 °C and tolerates 5–95% non-condensing humidity. -
Can it be installed in panel and rack configurations?
Yes, the device supports both panel and rack mounting for flexible deployment.
