Product Overview
The ABB SMU-03 3HNA013638-001 Spraying Robot is an advanced industrial robot designed for high-precision spraying applications. Engineered for automotive, aerospace, and general manufacturing industries, it provides consistent coating quality, reduced material waste, and high-speed operation. Its compact design and robust construction ensure reliable performance even in demanding production environments.
Key Features
-
High-precision spraying capabilities for uniform coatings
-
Compact and flexible design for tight production spaces
-
Compatible with multiple spray gun types and systems
-
High-speed operation for increased productivity
-
Durable construction for long-term industrial use
-
Easy integration with ABB RobotStudio and PLC systems
-
Advanced safety features for operator protection
-
Optimized for minimal material consumption and overspray
Technical Specifications
| Item | Specification |
|---|---|
| 制造商 | ABB |
| 型号 | SMU-03 |
| 零件号 | 3HNA013638-001 |
| Product Type | Spraying Robot |
| Payload Capacity | Up to 3 kg (spray gun + material) |
| Reach | Approx. 1,500 mm |
| Repeatability | ±0.1 mm |
| Degrees / Freedom | 6 axes |
| Dimensions | 247 x 25.6 x 131 mm |
| 重量 | 1.3 kg |
| Operating Temperature | 0 °C to +45 °C |
| Power Supply | 400 V, 50/60 Hz |
| Applications | Industrial spraying, coating, painting, and finishing |
Industry Applications
-
Automotive painting and coating
-
Aerospace component spraying
-
Furniture and appliance finishing
-
General manufacturing with liquid coating processes
-
Robotics-based automated material application
-
Surface treatment in industrial production
常见问题 (FAQ)
Q1: What is the payload capacity / the SMU-03?
The robot can handle up to 3 kg including the spray gun and material.
Q2: What is the reach / this spraying robot?
It has an approximate reach / 1,500 mm.
Q3: How accurate is the SMU-03?
It has a repeatability / ±0.1 mm.
Q4: How many axes / motion does the robot have?
The robot has 6 axes / freedom for full range movement.
Q5: Which industries typically use this robot?
It is used in automotive, aerospace, furniture, appliance manufacturing, and general coating industries.
Q6: What is the operating temperature range?
The robot operates from 0 °C to +45 °C.
Q7: Can it integrate with ABB control systems?
Yes, it is compatible with ABB RobotStudio and standard PLC systems.
Q8: What are the physical dimensions and weight / the SMU-03?
Dimensions are 247 x 25.6 x 131 mm, and the weight is about 1.3 kg.
