产品介绍
The ABB RED670 1MRK002810-AC Line Differential Protection Relay is a high-performance solution designed for fast and selective protection / transmission and sub-transmission lines. As part / the ABB Relion® 670 series, the RED670 provides advanced current differential protection, distance protection, and backup functions, making it ideal for critical power transmission networks. It supports single and parallel line configurations with or without transformers and is fully compliant with IEC 61850 for digital substation integration. With high-speed communication and advanced fault detection algorithms, the RED670 ensures maximum system stability and reliability.
产品规格
| Parameter | 描述 |
|---|---|
| 型号 Number | RED670 |
| 零件号 | 1MRK002810-AC |
| Product Type | Line Differential Protection Relay |
| Operating Voltage | 24–250 V DC / 48–240 V AC |
| Frequency Range | 50/60 Hz |
| Communication Protocols | IEC 61850, Modbus, DNP3, IEC 60870-5-103 |
| Protection Functions | Line differential, distance, backup overcurrent, breaker failure |
| CT Inputs | 1 A / 5 A |
| VT Inputs | Standard voltage transformer inputs |
| Trip Outputs | 14 configurable outputs |
| Dimensions (L×W×H) | 177 x 177 x 190 mm |
| 重量 | 3.5 kg |
| Operating Temperature | -25°C to +70°C |
| Mounting | Panel/rack mounting |
| Certifications | CE, UL, IEC 60255 compliant |
Product Applications
-
Transmission Line Protection: Provides high-speed current differential protection for single and parallel lines.
-
Distance Backup Protection: Integrated distance protection /fers an additional layer / system security.
-
Sub-Transmission Systems: Suitable for medium-voltage and sub-transmission networks requiring fast fault isolation.
-
Industrial Power Networks: Protects critical feeder and line segments in heavy industries and utilities.
-
Digital Substations: Fully supports IEC 61850 GOOSE messaging for advanced communication and automation.
-
Breaker Failure Protection: Ensures secure isolation / failed breakers to maintain system stability.
Product Advantages
-
Ultra-Fast Fault Detection: Provides rapid fault clearing to minimize damage and system disturbances.
-
Comprehensive Protection: Combines line differential, distance, and backup protection functions in one device.
-
IEC 61850 Integration: Enables seamless operation in digital substations with advanced communication support.
-
High Reliability: Robust hardware and s/tware design for critical transmission and distribution applications.
-
Flexible Application: Suitable for various line configurations, including those with transformers and series compensation.
-
Advanced Diagnostics: Built-in self-monitoring and event recording for efficient maintenance and troubleshooting.
-
Scalable Design: Can be tailored for small, medium, and large-scale power systems.
FAQ
-
What type / protection does the RED670 primarily provide?
The RED670 /fers high-speed line differential protection as its primary function, ensuring precise fault detection for transmission lines. -
Can the relay be used for parallel line configurations?
Yes, the RED670 supports both single and parallel line protection, making it suitable for complex transmission networks. -
Does the RED670 support distance protection as a backup function?
Absolutely. It integrates distance protection to provide an additional layer / backup security for line faults. -
What type / current transformer inputs are supported?
The relay accepts standard 1 A and 5 A CT inputs for flexible application in various network configurations. -
Is the RED670 compatible with IEC 61850-based systems?
Yes, the device is fully IEC 61850 compliant, supporting GOOSE messaging and sampled values for digital substation environments. -
How fast is the fault detection and clearing process?
The RED670 is designed for ultra-fast fault detection and clearing, minimizing system disturbances and protecting equipment integrity. -
Can the RED670 handle lines with series compensation?
Yes, it includes advanced algorithms to provide stable protection for lines equipped with series compensation. -
What communication protocols are available for integration?
The device supports IEC 61850, Modbus, DNP3, and IEC 60870-5-103, ensuring compatibility with a range / SCADA and automation systems. -
Is breaker failure protection included in the RED670?
Yes, the relay integrates breaker failure protection logic to ensure safe isolation / failed breakers during fault events. -
Does the RED670 provide event recording and disturbance analysis?
Yes, the relay /fers extensive event recording, disturbance analysis, and oscillography to aid in post-fault diagnostics and system studies.
Related 型号s (Same Series)
| 型号 Number | 描述 |
|---|---|
| REL670 | Line Differential Protection Relay |
| REB670 | Busbar Protection Relay |
| RET670 | Transformer Protection Relay |
| REM670 | Motor Protection and Control Relay |
| REC670 | Bay Control and Protection 单位 |
| REU670 | Generator Protection Relay |
Popular ABB 型号s (Same 品牌)
| 型号 Number | 描述 |
|---|---|
| REF615 | Feeder Protection Relay |
| RET615 | Transformer Protection Relay |
| REM615 | Motor Protection Relay |
| REX640 | Modular Protection and Control Relay |
| REF630 | Feeder Protection and Control 单位 |
| REC615 | Bay Control and Protection Relay |
