Product Overview
The ABB DSQC609 3HAC14178-1 is a robust and reliable power supply module engineered specifically for ABB’s IRC5 robot controller systems. This 件 plays a critical role in converting and distributing power to internal control boards, servo drives, feedback 件s, and communication modules in robotic automation environments.
Known for its stability, durability, and safety, the DSQC609 ensures continuous, regulated power delivery in high-demand industrial applications. Its compatibility with a wide range / ABB IRB-series robots makes it an essential component for maintaining controller functionality and minimizing system downtime.
Key Features
-
High-efficiency power conversion for IRC5 control systems
-
支持s continuous operation in harsh industrial environments
-
Delivers regulated power to multiple internal subsystems
-
Built-in overvoltage and short-circuit protection
-
Passive and active thermal management system
-
CE and RoHS certified industrial-grade electronics
-
Hot-swappable in select controller configurations
-
Compatible with global voltage standards (via IRC5 configuration)
Technical Specifications
| Item | Specification |
|---|---|
| 制造商 | ABB |
| 型号 Number | DSQC609 (3HAC14178-1) |
| Product Type | Robot Power Supply Module |
| Application | ABB IRC5 robot controllers (IRB 2400, IRB 4400, IRB 4600, etc.) |
| Input Voltage | 3-phase, 200–480 V AC (system-dependent) |
| Output Voltage | Multiple regulated DC outputs (typically 24 VDC, 5 VDC, etc.) |
| Output Power | Up to 1 kW (depending on configuration) |
| Efficiency | ≥ 90% under nominal load |
| Protection Features | Overvoltage, overcurrent, thermal shutdown |
| Cooling Method | Passive heat sinks with airflow support from controller fan |
| Mounting Type | Slot-in module within IRC5 power compartment |
| Operating Temperature | 0°C to +55°C (32°F to 131°F) |
| Storage Temperature | –25°C to +70°C (–13°F to 158°F) |
| Dimensions | 125x 115x 47mm |
| 重量 | 0.46 kg |
| Environmental Rating | IP20 (enclosed within cabinet) |
| Certifications | CE, RoHS, EMC compliant, ISO 9001 manufactured |
Industry Applications
-
Automotive Manufacturing – Powers robot controllers in welding, painting, and assembly lines
-
Packaging and Logistics – Provides reliable control power to sorting and packing robots
-
Electronics Production – Ensures uninterrupted operation / pick-and-place robotic arms
-
Metalworking and CNC – 支持s robots in high-precision machining environments
-
Plastics and Molding – Maintains stable controller function for robotic injection processes
-
General Industrial Automation – Powers ABB robots in smart factories and high-speed automation cells
Product Advantages
-
Optimized for ABB IRC5 – Full compatibility ensures plug-and-play performance
-
High Power Stability – Maintains consistent voltage even under fluctuating load conditions
-
Rugged Design – Engineered to endure vibration, temperature shifts, and electrical noise
-
Safe Operation – Comprehensive built-in protections guard against system faults
-
Low Maintenance – Designed for extended operating life with minimal intervention
-
Global Readiness – Compatible with a wide range / factory voltage standards
-
Serviceable – Easily replaceable in the field; ABB /fers support and spare parts
-
Proven Reliability – Deployed worldwide in thousands / robot controller installations
常见问题 (FAQ)
-
Q: What is the primary function / the DSQC609 power supply?
A: It converts incoming AC voltage to regulated DC power for use by internal IRC5 components. -
Q: Is the DSQC609 compatible with all ABB robot models?
A: It is compatible with many ABB IRB series robots using the IRC5 controller, including IRB 2400, 4400, 4600, and others. -
Q: Can the DSQC609 be replaced in the field?
A: Yes, it is a field-replaceable 件 when following ABB’s standard service procedures. -
Q: Does this 件 support hot-swapping?
A: In some configurations with power interlocks, it may support live swap with proper safety precautions. -
Q: What protections are built into the DSQC609?
A: It includes overvoltage, overcurrent, and thermal shutdown protection. -
Q: Does this power supply require external cooling?
A: No, it is passively cooled with support from the controller’s integrated fan system. -
Q: What certifications does it meet?
A: CE, RoHS, and it complies with international EMC and safety standards. -
Q: How can I check if my DSQC609 is functioning properly?
A: Use ABB’s RobotWare s/tware or monitor system diagnostics through the controller display. -
Q: Can this 件 be refurbished or repaired?
A: Yes, ABB /fers factory refurbishment and certified repair options. -
Q: Where can I source this 件?
A: Through ABB’s global distribution network or authorized service partners.
Related ABB Power Modules and Robot Components
| 型号 Number | 描述 |
|---|---|
| DSQC608 (3HAC12928-1) | Power Distribution 单位 for ABB robots |
| DSQC539 | Drive Supply 单位 for IRC5 servo modules |
| DSQC354 (3HAC1292-1) | Auxiliary Power Board for robot controller systems |
| 3HAC025338-001 | Servo Drive Power Input Module for ABB robots |
| DSQC504 | Power Interface Board for controller integration |
| 3HAC14549-3 | Compact Drive Supply Module for robotic motion |
Popular ABB Robotic Automation 产品
| 型号 Number | 描述 |
|---|---|
| IRB 6700 | Heavy-duty robot for high-payload industrial operations |
| IRB 1200 | Compact 6-axis robot for precision assembly |
| IRC5 Controller | ABB’s main robot control platform |
| DSQC652 | Pr/ibus communication interface for robot controllers |
| IRB 2600 | High-speed robot for handling and machining |
| RobotWare 6.13+ | ABB robot programming and configuration s/tware platform |
