产品介绍
The ABB DSPP4LQ / DSPP4LQA System Module (part number HENF209736R0003) is a vital component within ABB’s range / distributed control and protection systems. Designed for high reliability and performance, this system module serves as a core processing and communication 件 that integrates multiple control and protection functionalities within electrical grids or industrial automation networks.
Specifically engineered for use in ABB’s DSP (Digital System Protection and Control) series, the DSPP4LQ module /fers enhanced processing power and flexible interface options, making it suitable for complex protection schemes and critical control applications. It ensures robust data acquisition, precise logic control, and seamless communication with other system components.
With its modular design, the DSPP4LQ series simplifies system upgrades and maintenance, enabling utilities and industrial users to maintain optimal operational efficiency with minimal downtime.
Technical Specifications
| Parameter | Details |
|---|---|
| Product Name | DSPP4LQ / DSPP4LQA System Module |
| 零件号 | HENF209736R0003 |
| 制造商 | ABB |
| Series | DSP Protection and Control System |
| Function | Core processing and communication module |
| Processor Type | High-performance embedded processor |
| Communication Interfaces | Multiple ports supporting Ethernet, serial links |
| Power Supply | 24 V DC (typical industrial standard) |
| Power Consumption | Approx. 10 W |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions (W x H x D) | 160 x 120 x 90 mm |
| 重量 | 1.2 kg |
| Protection Class | IP20 |
| Certifications | CE, UL, RoHS |
Product Applications
The DSPP4LQ system module is designed for critical applications where reliable control and protection are essential:
-
Electrical Power Distribution
支持s protective relaying and control in substations and distribution networks. -
Industrial Automation
Enables high-speed data processing and protection in manufacturing plants and process industries. -
Renewable Energy Systems
Facilitates grid integration and protection / wind farms and solar power plants. -
Transmission System Protection
Used in high-voltage transmission lines to monitor, control, and isolate faults. -
Critical Infrastructure
Ensures operational continuity in water treatment, transportation, and smart grid systems. -
Energy Management Systems
Provides data handling and control for energy optimization and load balancing.
Product Advantages
-
High Processing Capability
Equipped with a powerful embedded processor for fast and reliable operation. -
Flexible Communication
Multiple interface options allow seamless integration into various network architectures. -
Modular Design
Facilitates easy upgrades, replacements, and system expansions without significant downtime. -
Robust Build Quality
Designed to withstand harsh industrial environments and temperature fluctuations. -
Comprehensive Compatibility
Fully compatible with ABB DSP series hardware and s/tware platforms. -
Low Power Consumption
Energy-efficient design reduces operational costs and thermal stress.
常见问题 (FAQ)
-
Q: What is the primary function / the DSPP4LQ module?
A: It serves as a core system processing and communication 件 within ABB’s DSP protection and control systems. -
Q: What types / communication interfaces does the module support?
A: It supports Ethernet and serial communication ports to connect with various network devices. -
Q: What is the operating temperature range for this module?
A: The module operates reliably between -20°C and +70°C. -
Q: Can the DSPP4LQ module be used in harsh industrial environments?
A: Yes, it is designed with robust housing and IP20 protection suitable for industrial conditions. -
Q: What power supply voltage is required?
A: It operates typically on a 24 V DC power supply. -
Q: How heavy is the module?
A: The weight is 1.2 kg. -
Q: Is this module compatible with other ABB DSP series products?
A: Yes, it is fully compatible within the DSP family, allowing seamless integration. -
Q: What kind / maintenance does the DSPP4LQ require?
A: Regular visual inspections and firmware updates via ABB’s engineering tools are recommended. -
Q: What certifications does this module hold?
A: The product is certified for CE, UL, and RoHS standards. -
Q: How does the module contribute to system reliability?
A: By providing fast processing, fault detection, and reliable communication, it enhances overall system uptime and protection accuracy.
Related or Compatible 型号s
| 型号 Number | 描述 | Application | Notes |
|---|---|---|---|
| DSPP4LQB | Variant / DSPP4LQ with enhanced communication | DSP Protection Systems | Expanded interface options |
| DSPP4LQF | System module with additional processing power | Protection & Control | For demanding control tasks |
| HENF209737R0004 | Complementary I/O module for DSP systems | Input/output interface | Works alongside DSPP4LQ |
| DSPC2000 | DSP series Central Controller | Centralized control 件 | Integrates with DSPP4LQ modules |
| DSPC2100 | High-end DSP system controller | Advanced control and protection | 支持s DSPP4LQ module |
| HENF209735R0002 | Communication interface module | Network communication | Compatible with DSPP4LQ |
Popular ABB 型号s in Protection and Control
| 型号 Number | 描述 | 分类 | Typical Use Case |
|---|---|---|---|
| REF615 | Feeder protection relay | Protection Relay | Electrical distribution |
| RET670 | Protection and control relay | High-end protection system | Transmission and distribution |
| CM400 | Motor management relay | Motor protection | Industrial motor control |
| PCD3000 | Programmable automation controller | PLC | Industrial automation |
| CP600 | Advanced operator interface | HMI | User interface in automation |
| S203 | Miniature circuit breaker | Circuit protection | Power distribution panels |
