Product Overview
The ABB CMIB-11C 3AUA0000041488 MC Interface Board is a versatile and highly reliable interface module designed to provide communication between ABB industrial drives and various control systems. Specifically engineered for ABB ACS800, ACS880, and other compatible drives, the CMIB-11C enables seamless exchange / control signals, status updates, and monitoring data between the drive and higher-level automation systems.
This board acts as a bridge between the motor control (MC) section / the drive and other system components, supporting a range / industrial applications where precision control, robust communication, and system reliability are paramount. Featuring multiple I/O options, fast response times, and a compact, rugged design, the CMIB-11C contributes to optimized performance and efficiency in demanding industrial environments.
As part / ABB’s extensive portfolio / drive accessories and system modules, the CMIB-11C reflects the brand’s global reputation for quality, reliability, and engineering excellence.
产品规格
| Parameter | Value |
|---|---|
| 型号 | CMIB-11C |
| ABB Code | 3AUA0000041488 |
| Product Type | MC Interface Board |
| Compatibility | ABB ACS800, ACS880, and select industrial drives |
| Interface Type | Motor Control (MC) interface |
| Communication Protocols | Internal drive bus, I/O-based interface |
| Inputs | 6 Digital Inputs |
| Outputs | 3 Digital Outputs |
| Analog Inputs | 2 Analog Inputs |
| Analog Outputs | 2 Analog Outputs |
| Operating Voltage | 24 VDC nominal |
| Isolation | 500 V galvanic isolation |
| Response Time | < 5 ms typical |
| Operating Temperature Range | -10 °C to +50 °C |
| Storage Temperature Range | -40 °C to +85 °C |
| Humidity | 5% to 95% RH non-condensing |
| EMC Compliance | EN 61800-3 (Drive EMC standard) |
| Safety Certifications | CE, UL, cULus |
| Mounting | Internal drive mounting |
| Dimensions (W × H × D) | 330 x 174 x 38 mm |
| 重量 | 0.8 kg |
| Mean Time Between Failures (MTBF) | > 500,000 hours |
Applications
The ABB CMIB-11C 3AUA0000041488 Interface Board is widely used in various industrial applications, including:
-
Heavy Industry Drives
High-power motor control in steel, paper, cement, and mining industries. -
Process Automation
Drives interfaced with DCS or PLC systems for seamless plant-wide control. -
Pumping and Water Treatment
Motor control for large pumping stations, compressors, blowers. -
HVAC Systems
Advanced fan and pump control in building management and HVAC. -
Marine and Offshore
Motor drives in marine propulsion, thrusters, and deck machinery. -
Renewable Energy
Integration / large motors for wind turbines, hydroelectric plants. -
Transportation
Rail transport systems, conveyors, and logistics handling equipment.
Product Advantages
-
Reliable Drive-System Communication
Provides a robust interface between ABB drives and automation controllers. -
Multiple I/O Options
Flexible combination / analog and digital I/O channels. -
Fast Response
Rapid signal exchange enables precision motor control. -
High Isolation
500 V galvanic isolation ensures electrical protection. -
Compact and Rugged
Space-efficient design fits seamlessly into ABB drives. -
Certified for Industrial Use
CE, UL, and cULus certified for global applications. -
Flexible Application Range
Suitable for diverse industries, from manufacturing to marine. -
Extended Temperature Tolerance
Designed for use in demanding industrial environments. -
Reliable Long-Term Operation
High MTBF (> 500,000 hours) minimizes downtime. -
Seamless ABB Ecosystem Integration
Optimized for use with ABB ACS series drives.
常见问题 (FAQ)
-
What is the primary function / the CMIB-11C board?
It serves as an interface between the motor control section / the drive and external systems. -
Is it compatible with ABB ACS800 drives?
Yes, it is fully compatible with ACS800 as well as ACS880 series drives. -
What I/O does the board provide?
6 digital inputs, 3 digital outputs, 2 analog inputs, and 2 analog outputs. -
Does the board support galvanic isolation?
Yes, it provides 500 V galvanic isolation. -
Can this board be used in marine applications?
Yes, it is widely used in marine and /fshore motor control systems. -
How is the CMIB-11C mounted?
It is designed for internal mounting within ABB drives. -
What is the operating temperature range?
-10 °C to +50 °C for normal operation. -
Is it certified for global industrial standards?
Yes, the board is CE, UL, and cULus certified. -
Does it support fast control applications?
Yes, typical response times are < 5 ms, suitable for fast applications. -
What is the MTBF for this product?
More than 500,000 hours, /fering reliable long-term performance.
Related 型号s from the Same Series or 分类
| 型号 | Product Type | Compatibility | Dimensions (W×H×D) | 重量 |
|---|---|---|---|---|
| CMIB-11C 3AUA0000041488 | MC Interface Board | ACS800, ACS880 | 90×140×25 mm | 0.25 kg |
| CMIB-01 3AUA0000041487 | MC Interface Board | ACS800 | 90×140×25 mm | 0.25 kg |
| CMIV-01 3AUA0000038684 | Voltage Interface Board | ACS800, ACS880 | 95×140×30 mm | 0.26 kg |
| RMIO-02 3BHB003230R0102 | Drive Control 单位 | ACS800 | 120×180×30 mm | 0.30 kg |
| RDCO-03 64607458 | Fieldbus Adapter Board | ACS800 | 100×140×20 mm | 0.20 kg |
| RINT-5121 64603943 | Relay Interface Board | ACS800 | 85×125×20 mm | 0.22 kg |
Popular 型号s from ABB Product Line
| 型号 | Product Type | Application Area | Dimensions (W×H×D) | 重量 |
|---|---|---|---|---|
| ACS880-01-045A-3 | Industrial Drive | General purpose motor control | 300×500×300 mm | 25 kg |
| ACS800-U1-0450-5+N7501 | Industrial Drive | Heavy-duty industry | 550×750×300 mm | 75 kg |
| ACS880-07-0650A-5 | Cabinet Drive | Process control, HVAC | 800×1600×400 mm | 250 kg |
| CP600-Pro (CP620) | HMI Panel | Operator interface | 220×150×50 mm | 1.2 kg |
| RMIO-02 3BHB003230R0102 | Drive Control 单位 | ABB ACS800 | 120×180×30 mm | 0.30 kg |
| RINT-5121 64603943 | Relay Interface Board | ABB ACS800 | 85×125×20 mm | 0.22 kg |
