Product Overview
The ABB CI871AK01 (CI871A) 3BSE092693R1 is a high-performance communication interface module designed for integration into ABB’s AC 800M control system, enabling seamless connectivity between the controller and external devices via PROFINET IO. As part / the S800 I/O series, it acts as a gateway between the AC 800M controller and field devices or I/O systems that utilize PROFINET industrial Ethernet protocols.
Built to withstand demanding industrial conditions, the CI871AK01 provides real-time communication, deterministic performance, and robust data exchange in automation environments. It /fers a reliable and scalable solution for distributed control applications, enabling flexible plant expansions and seamless integration into existing PROFINET architectures.
Technical Specifications
| Parameter | Value |
|---|---|
| 型号 | CI871AK01 (CI871A) |
| System Compatibility | AC 800M / S800 I/O |
| Communication Protocol | PROFINET IO |
| 支持ed Standards | IEEE 802.3, IEC 61158 |
| Ports | 2 x RJ45 Ethernet ports |
| Baud Rate | 100 Mbps (Full Duplex) |
| Redundancy 支持 | Yes, system and network redundancy |
| Diagnostics | Extensive self-diagnostics with LED indicators |
| Addressing Method | DHCP, DCP, Manual configuration |
| Configuration Tool | Control Builder M |
| Power Supply | 24 VDC (supplied via backplane) |
| Mounting Type | DIN rail |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| Relative Humidity | 5% to 95%, non-condensing |
| Dimensions | 127.5 × 186 × 59 mm |
| 重量 | 0.7 kg |
| Housing Material | Polycarbonate / ABS blend |
| Certifications | CE, RoHS, UL, Marine certifications (DNV/GL, LR) |
Applications
The ABB CI871AK01 module is designed to facilitate high-performance Ethernet communication in a variety / industrial settings, including:
-
Discrete Manufacturing – Enabling machine-to-machine communication in automotive and electronics industries.
-
Process Automation – Connecting sensors, drives, and field instruments in oil & gas, chemicals, and pharmaceuticals.
-
Power Plants – Integrating PROFINET-based protection relays, switchgear, and turbine controllers.
-
Water and Wastewater – Enabling distributed and remote I/O access across pump stations and treatment plants.
-
Material Handling Systems – Controlling conveyors, robotic systems, and sorters with deterministic performance.
-
Food & Beverage – Facilitating real-time data transfer in fast-paced, hygiene-critical environments.
Key Advantages
-
High-Speed Communication: Dual Ethernet ports provide fast, full-duplex data exchange across PROFINET networks.
-
System Redundancy: 支持s AC 800M controller redundancy for enhanced availability and fault tolerance.
-
Easy Integration: Seamlessly integrates into existing ABB automation architectures using Control Builder M.
-
Modular and Scalable: Fits within the modular S800 I/O design, allowing system growth and adaptability.
-
Reliable Performance: Built to operate in challenging environments with wide temperature and humidity tolerances.
-
Diagnostic Transparency: Real-time diagnostics with status LEDs for link, activity, and module health.
-
Secure Communication: Compliant with industrial Ethernet security standards and safe configuration practices.
-
Certified for Harsh Environments: Approved for marine and heavy industry applications, ensuring versatility.
常见问题 (FAQ)
-
What is the function / the CI871AK01 module?
It acts as a communication bridge between the AC 800M controller and field devices via PROFINET IO. -
What types / devices can connect to CI871AK01?
Any PROFINET IO-compatible devices such as sensors, actuators, VFDs, and distributed I/O modules. -
Does the module support redundancy?
Yes, both controller and network redundancy are supported for high availability systems. -
Is this module compatible with earlier ABB systems?
It is specifically designed for the AC 800M and S800 I/O series. -
What s/tware is used for configuration?
ABB Control Builder M is used for parameter setting, diagnostics, and monitoring. -
How is the module mounted?
It is DIN rail mountable and integrates into the S800 I/O backplane. -
Can this module operate in marine environments?
Yes, it holds certifications for use in marine and /fshore applications. -
What diagnostic features are included?
LED indicators for power, communication status, and fault diagnostics are available. -
Is hot-swapping supported?
Yes, the module supports hot-swap functionality within the S800 I/O system. -
What kind / cables are required for PROFINET?
Standard Cat 5e/6 Ethernet cables with RJ45 connectors are used for PROFINET connections.
Recommended Related or Series 型号s
| 型号 | 描述 |
|---|---|
| CI860V1 | Redundant Ethernet interface for S800 I/O systems |
| CI870K01 | FOUNDATION Fieldbus interface module for AC 800M |
| CI854AK01 | PROFIBUS DP communication interface for AC 800M |
| CI820V1 | CEX-bus communication interface for S800 I/O |
| TB840A | ModuleBus modem for remote S800 I/O connectivity |
| BC810K02 | Basic CEX bus interconnection module |
Popular ABB 型号s
| 型号 | 描述 |
|---|---|
| CI854K01 | PROFIBUS DP communication interface module |
| CI855K01 | S100 I/O communication interface for AC 800M |
| CI856K01 | S800 I/O interface module for AC 800M |
| CI857K01 | Redundant communication interface for S800 I/O |
| CI858K01 | High-speed fieldbus communication module |
| CI859K01 | Industrial Ethernet communication interface |
