产品介绍
The ABB ATMB-01C 68908574B Temperature Measuring Board is engineered for precise temperature monitoring within ABB inverter drives. This module plays a critical role in safeguarding inverter components by continuously measuring internal temperatures, thereby preventing overheating and ensuring optimal performance. Its robust design and compatibility with ABB systems make it a reliable choice for industrial applications requiring accurate thermal management.
产品规格
| Parameter | Specification |
|---|---|
| 型号 Number | ATMB-01C 68908574B |
| 制造商 | ABB |
| Product Type | Temperature Measuring Board |
| Function | Internal temperature monitoring for ABB inverter drives |
| Sensor Configuration | 2-wire, 4-terminal connection |
| Temperature Range | -40°C to +100°C |
| Resolution | 0.1°C |
| Input Channels | 8 Analog Inputs |
| Input Signal Types | 0-10V, 4-20mA |
| Output Channels | 4 Analog Outputs |
| Output Signal Types | 0-10V, 4-20mA |
| Power Supply | 24 V DC |
| Mounting Type | DIN Rail Mount |
| Operating Temperature | -20°C to +60°C |
| Communication Protocol | Fieldbus, Serial Communication |
| Diagnostics | LED Indicators for Status Monitoring |
| Protection Features | Over-voltage, Short-circuit, Overload |
| Certifications | CE, RoHS, UL |
| Dimensions (W x H x D) | 135 x 65 x 110 mm |
| 重量 | 0.01 kg |
Product Applications
The ABB ATMB-01C 68908574B is utilized in various industrial sectors where precise temperature monitoring is essential:
-
Power Generation: Monitoring temperatures in turbines and generators to prevent overheating.
-
Chemical Processing: Ensuring temperature stability in reactors and processing 件s.
-
Oil and Gas: Managing temperatures in drilling equipment and pipelines.
-
Manufacturing: Controlling thermal conditions in production machinery.
-
HVAC Systems: Regulating temperatures in heating, ventilation, and air conditioning systems.
-
Renewable Energy: Monitoring temperatures in solar inverters and wind turbine converters.
Product Advantages
-
High Precision Monitoring: Offers accurate temperature readings with a resolution / 0.1°C, ensuring reliable thermal management.
-
Robust Design: Built to withstand harsh industrial environments, providing durability and longevity.
-
Easy Integration: Seamlessly integrates with ABB inverter drives, simplifying installation and reducing setup time.
-
Multi-Channel Input: 支持s multiple analog inputs and outputs, allowing for comprehensive temperature monitoring across various components.
-
Diagnostic Features: Equipped with LED indicators for real-time status monitoring and fault detection.
-
Protection Mechanisms: Includes over-voltage, short-circuit, and overload protection to safeguard both the module and connected equipment.
-
Compliance with Standards: Certified with CE, RoHS, and UL, meeting international safety and quality standards.
-
Compact Form Factor: Space-efficient design suitable for installations with limited space.
-
Versatile Communication: 支持s Fieldbus and serial communication protocols for flexible system integration.
-
Wide Operating Range: Functions effectively across a broad temperature range, accommodating various industrial environments.
常见问题 (FAQ)
-
Q: What is the primary function / the ATMB-01C 68908574B?
A: It monitors internal temperatures within ABB inverter drives to prevent overheating and ensure optimal performance. -
Q: How does the module connect to the inverter system?
A: It utilizes a 2-wire, 4-terminal connection for accurate temperature sensing integration. -
Q: What temperature range can the module accurately measure?
A: It measures temperatures ranging from -40°C to +100°C. -
Q: What is the resolution / the temperature measurements?
A: The module provides high-resolution temperature readings with a precision / 0.1°C. -
Q: How many input and output channels does the module support?
A: It supports 8 analog input channels and 4 analog output channels. -
Q: What types / signals are compatible with the input and output channels?
A: The module supports 0-10V and 4-20mA signal types for both inputs and outputs. -
Q: What are the protection features included in the module?
A: It includes over-voltage, short-circuit, and overload protection mechanisms. -
Q: What certifications does the module have?
A: The module is certified with CE, RoHS, and UL standards. -
Q: What is the recommended mounting method for the module?
A: It is designed for DIN rail mounting. -
Q: What communication protocols does the module support?
A: It supports Fieldbus and serial communication protocols for system integration.
Related 型号s (Same Series or Function)
| 型号 | Function 描述 | Channels | Compatibility |
|---|---|---|---|
| ATMB-02C | Enhanced temperature measurement module | 8 | ABB Inverter Drives |
| AX521 | Analog input module with universal sensor support | 16 | ABB Advant Controller |
| TB820V2 | Redundant termination 件 | — | Advant Controller 450 |
| TU810V1 | Analog signal interface module | 8 | S800 I/O |
| AI810 | 8-channel analog input module for 4–20 mA sensors | 8 | S800 I/O |
| AI820 | High accuracy analog input for RTD and thermocouple | 8 | ABB Freelance/S800 I/O |
Popular ABB Modules (Same 品牌, Widely Used)
| 型号 | 描述 | System Compatibility | Application |
|---|---|---|---|
| CI854AK01 | PROFIBUS DP-V1 communication interface | Control Builder AC 800M | Fieldbus communication |
| PM864AK01 | CPU module with Ethernet, serial, and PROFIBUS | AC 800M | Distributed control systems |
| AI810 | 8-channel analog input, 4–20mA | S800 I/O | Process instrumentation |
| DI810 | 16-channel digital input | S800 I/O | General-purpose digital sensing |
| DO810 | 16-channel digital output | S800 I/O | Actuator control |
| PM573-ETH | Compact PLC with Ethernet communication | ABB AC500 | Machine automation, OEM applications |
