Product Introduction
The Woodward 5462-750 Power Supply is a high-quality, industrial-grade power module designed to provide reliable and stable power to Woodward control systems and other industrial equipment. Known for its robustness and consistent performance, this power supply unit is a critical component in many Woodward engine control and automation products.
This power supply is engineered to deliver regulated DC voltage output with high efficiency and excellent transient response. It ensures continuous, clean power delivery in demanding environments such as power plants, oil and gas installations, marine vessels, and industrial automation facilities. The Woodward 5462-750 supports uninterrupted system operation and contributes to the overall reliability and longevity of connected devices.
Built to Woodward’s stringent quality standards, the 5462-750 combines advanced electronics with rugged construction to withstand harsh environmental conditions, including vibration, temperature extremes, and electrical noise.
Product Parameters
| Parameter | Specification |
|---|---|
| Model Number | 5462-750 |
| Type | Power Supply Module |
| Input Voltage Range | 85 – 264 VAC, 47 – 63 Hz |
| Output Voltage | 24 V DC |
| Output Current | 10 A |
| Output Power | 240 W |
| Efficiency | >85% |
| Voltage Regulation | ±1% |
| Ripple and Noise | <1% RMS |
| Operating Temperature | -20 °C to +70 °C |
| Storage Temperature | -40 °C to +85 °C |
| Humidity Range | 5% to 95% non-condensing |
| Cooling | Convection cooled |
| Protection Features | Overvoltage, overcurrent, short circuit |
| Dimensions (HxWxD) | 125 × 95 × 230 mm |
| Weight | 0.61 kg |
Product Applications
The Woodward 5462-750 Power Supply is widely applied in industrial settings that demand reliable power delivery to control and automation systems. Typical applications include:
-
Power Generation: Provides stable power for Woodward turbine and generator control units, ensuring continuous operation of power plants.
-
Oil & Gas Industry: Powers engine control systems on rigs, platforms, and processing plants where reliable control is crucial.
-
Marine & Offshore: Supports shipboard control electronics and propulsion systems that require durable and vibration-resistant power sources.
-
Industrial Automation: Supplies power to critical control panels and PLC systems in manufacturing plants, ensuring stable operations and process control.
-
Transportation: Used in heavy machinery and locomotives for powering engine control modules.
-
Renewable Energy: Provides power to wind turbine controllers and solar farm automation systems.
Product Advantages
-
High Reliability: Designed and tested to withstand demanding industrial conditions, ensuring minimal downtime and consistent power output.
-
Wide Input Voltage Range: Capable of handling a broad input voltage range, allowing flexible installation in diverse power environments worldwide.
-
Compact and Lightweight: The compact design enables easy integration into control panels with limited space while maintaining a lightweight profile.
-
Robust Protection: Built-in overvoltage, overcurrent, and short circuit protection safeguards connected devices and the power supply itself from damage.
-
Stable Output: Tight voltage regulation and low ripple provide clean, steady power essential for sensitive electronic controls.
-
Efficient Operation: High efficiency reduces heat generation and energy consumption, contributing to system sustainability.
-
Convection Cooling: Silent, maintenance-free cooling without the need for fans increases reliability and reduces mechanical failures.
-
Durable Build Quality: Rugged casing and high-grade components ensure long service life even under harsh conditions such as vibration, temperature extremes, and humidity.
-
Global Compatibility: Suitable for a variety of electrical standards thanks to universal input voltage and frequency compatibility.
-
Ease of Maintenance: Simple installation and maintenance procedures minimize downtime and operational costs.
Frequently Asked Questions (FAQ)
-
What is the primary function of the Woodward 5462-750 Power Supply?
It converts AC input power into regulated 24 V DC output power to supply Woodward control systems and other industrial devices. -
What input voltage range does the 5462-750 support?
It supports a wide input range of 85 to 264 VAC at 47 to 63 Hz, allowing for flexible installation worldwide. -
What is the maximum output current?
The module can deliver up to 10 A continuous current at 24 V DC output. -
Is the power supply protected against electrical faults?
Yes, it has built-in overvoltage, overcurrent, and short circuit protection to prevent damage. -
What are the physical dimensions of the power supply?
It measures 125 × 95 × 230 mm. -
Can it operate in harsh environmental conditions?
Yes, it functions reliably within temperatures from -20 °C to +70 °C and humidity levels from 5% to 95% non-condensing. -
Does it require a fan for cooling?
No, it uses convection cooling, which is silent and maintenance-free. -
What kind of efficiency can be expected from this power supply?
Efficiency is greater than 85%, reducing energy loss and heat output. -
Is the output voltage regulated?
Yes, the output voltage is regulated within ±1% for stable power delivery. -
What industries commonly use the 5462-750 Power Supply?
It is widely used in power generation, oil & gas, marine, industrial automation, transportation, and renewable energy sectors.
Related Models from the Same Series or Family
| Model Number | Description | Output Voltage | Output Current | Dimensions (HxWxD) mm | Weight (kg) |
|---|---|---|---|---|---|
| 5462-740 | Power Supply Module | 24 V DC | 5 A | 125 × 95 × 180 | 1.2 |
| 5462-760 | Power Supply Module | 24 V DC | 15 A | 130 × 100 × 240 | 1.6 |
| 5462-730 | Power Supply Module | 12 V DC | 10 A | 125 × 95 × 210 | 1.3 |
| 5462-770 | Power Supply Module | 48 V DC | 10 A | 140 × 100 × 230 | 1.7 |
| 5462-755 | Power Supply Module | 24 V DC | 7 A | 125 × 95 × 200 | 1.4 |
| 5462-765 | Power Supply Module | 24 V DC | 20 A | 150 × 110 × 250 | 2.0 |
Popular Models from the Same Brand (Woodward)
| Model Number | Description | Output Voltage | Output Current | Dimensions (HxWxD) mm | Weight (kg) |
|---|---|---|---|---|---|
| 5462-750 | Power Supply Module | 24 V DC | 10 A | 125 × 95 × 230 | 1.4 |
| 2301-063 | Generator Control Module | 12 V DC | N/A | 180 × 120 × 300 | 2.5 |
| 8440-145 | Fuel Control Actuator | N/A | N/A | 210 × 160 × 110 | 3.0 |
| 9905-360 | Electronic Governor Module | 24 V DC | N/A | 130 × 110 × 200 | 1.5 |
| 2301-029 | Voltage Regulator Module | 24 V DC | N/A | 170 × 140 × 240 | 2.0 |
| 8440-130 | Hydraulic Actuator | N/A | N/A | 200 × 180 × 150 | 4.0 |
